Manual Tilt Wheelchair
Model 587
Owner, Operator, and Maintenance Manual
560 Bingemans Centre Drive Kitchener, ON Canada N2B 3X9
Can. /U.S. Phone: (800)-668-0637
Fax: (519) 746-8616
www.seatingisbelieving.com
Email:
sales@brodaseating.com
OM.587V3.10.1.2013

Advertisement

Table of Contents
loading

Related Manuals for broda ComfortTilt 587

Summary of Contents for broda ComfortTilt 587

  • Page 1 Manual Tilt Wheelchair Model 587 Owner, Operator, and Maintenance Manual 560 Bingemans Centre Drive Kitchener, ON Canada N2B 3X9 Can. /U.S. Phone: (800)-668-0637 Fax: (519) 746-8616 www.seatingisbelieving.com Email: sales@brodaseating.com OM.587V3.10.1.2013...

  • Page 2: Table Of Contents

    SECTION 5 - WHEELCHAIR REPAIR AND MAINTENANCE ......25 Broda Chair Inspection/Maintenance Schedule* ......25 Functional Testing ................. 26 Cables and Cable Handles ............27 Rear Wheels .................. 28 Gas Cylinders ................29 APPENDIX 1 - BRODA WARRANTY ..............32 Comfort-Tilt...

  • Page 3: Warning

    BRODA ComfortTilt Manual Wheelchair. Safety measures as described in Section 1 must be observed when operating the wheelchair’s functions or moving the wheelchair. Every person that is involved with the operation and maintenance of the BRODA wheelchair, including the patient’s family members, must read this instruction manual prior to moving or operating the functions of this wheelchair.
  • Page 4 The BRODA ComfortTilt’s intended use is to provide mobility to persons that may be limited to a sitting position. It is highly recommended that someone such as a nurse, nursing home staff or family member operate this device to transport patient(s) on even surfaces for safety and effectiveness.

  • Page 5: Section 1 - Safety Requirements & Detailed Warnings

    SECTION 1 - SAFETY REQUIREMENTS & DETAILED WARNINGS This section must be read by all operators of the BRODA wheelchair before they attempt to use the product. It is the caregiver’s primary responsibility to ensure that only people who are familiar with the information contained in this manual are authorized to operate or move the wheelchair.

  • Page 6: Before First Use Warning

    The ComfortTilt is not to be used in the shower. Use in the shower will void the warranty. BRODA does not recommend that the user of this chair be transported in vehicles while in the wheelchair and that appropriate seating in vehicles is provided for the user as made available by the auto industry.

  • Page 7: Position Of Wheelchair "Danger Of Falling" Warning

    We recommend that a wheelchair only be used on a level surface to minimize the risk of tipping over. All BRODA ComfortTilt’s are equipped with anti-tippers which are removable and adjustable. However, they should remain attached to the chair and pointed downward at all times. The anti-...

  • Page 8: Re-Positioning Of Patient "Danger Of Pinching" Warning

    We recommend that BRODA wheelchairs are located away from stairwells, elevators, and exterior doorways. Placing the patient near handrails, tables or stationary objects while the wheel locks are in place should be done with caution and should be supervised.

  • Page 9: Improper Use Warning

    1.13 Preventative Maintenance WARNING The maintenance on a BRODA wheelchair will vary with the amount of use and the condition of the patient using the wheelchair. We recommend regular visual inspection for signs of wear, damage, loose or missing fittings, and other safety concerns. Also, periodic testing of the wheelchair’s functions is appropriate.

  • Page 10: Patient Specific Instructions Warning

    Inspection We recommend regular visual inspection of signs of wear, damage, loose or missing fittings, and other safety concerns. If a breakage, defect, or operational problem is detected, the chair must be repaired inspected and tested for function before it is returned to service. We recommend that the wheelchair should be inspected as often as each use, if there is any reason to be concerned about the possibility of increased wear or loose or missing fittings.
  • Page 11 This manual describes the most common procedures and techniques involved in the safe handling and maintenance of BRODA chairs. It is important to understand, both conceptually and physically, the handling of the chair in order to prevent any injury to body, or misuse of the chair.
  • Page 12 Stairways BRODA does not recommend that the occupant be seated in the chair when moving the chair between floors when no elevator is available. If there is no other option, two assistants are required.

  • Page 13: Section 2 - Definitions And Technical Informaion

    SECTION 2 - DEFINITIONS AND TECHNICAL INFORMAION Definitions “BRODA” means BRODA Enterprises Inc. doing business as BRODA Seating. “Wheelchair” refers to BRODA Model ComfortTilt Manual Wheelchair. “Long-Term Care Institution” refers to a Nursing Home, Hospital, or other Health Care facility that provides health and personal care to its residents on a long-term basis.

  • Page 14: Shipping And Storage Specifications

    BRODA wheelchairs should be shipped and stored in an upright condition and not stacked higher than 2 boxes. No other materials should be shipped or stored on top of a BRODA box. BRODA boxes should not be placed on pallets.

  • Page 15: Section 3 - Caregiver Management

    At the customer’s request, the initial basic training of the patient’s caregiver(s) will be provided by either the local BRODA representative who supplies the wheelchair or the HME Provider. The caregiver(s) must adhere to the Safety Requirements at all times to ensure the safety of the patient, caregivers, and third parties.

  • Page 16: Section 4 - Wheelchair Operation

    SECTION 4 - WHEELCHAIR OPERATION Armrests The armrests are height adjustable and removable to accommodate various users and facilitate transfers and access to the user. Arm Detent Pin Armrests Removal and Installation 1. Push-in the Arm Detent Pins. 2. Once the Arm Detent Pins are disengaged, remove the Front and Rear Frame Insert by lifting the arm up.

  • Page 17: Wheel Locks

    Wheel Locks Wheel Lock Handle (Push to Lock) Locking/Unlocking the Rear Wheels 1. To lock; push the Wheel Lock Handle towards the front of the wheelchair until the wheel is locked in place. 2. To unlock; pull the Wheel Lock Handle towards the back of the wheelchair until the wheel is unlocked.
  • Page 18 All BRODA ComfortTilt’s are equipped with anti-tippers which are removable and adjustable. However, they should remain attached to the chair and pointed downward at all times and adjusted to the longest possible setting. The anti- tippers can be pointed upward if necessary for traveling over a curb or such, however they must be returned to the standard downward position for standard traveling and when the chair is in a stationary position.

  • Page 19: Seat Tilt

    Seat Tilt The ComfortTilt offers up to 45° of adjustable seat tilt. The gas spring used for the seat tilt feature allows the seat to be tilted to any position within its range. Use seat tilt to safely position the patient, redistribute pressure and increase comfort. Tilt Handle 45°...

  • Page 20: Accessories

    Accessories Broda offers various accessories for the ComfortTilt Tilt Wheelchair, as well as accommodating various after-market accessories. Adjustable Headrest The headrest for the ComfortTilt is very versatile in its adjustability, allowing for a wide variety of positioning needs. Attaching Headrest 1.

  • Page 21: Seat Height Adjustment

    Seat Height Adjustment The seat height is adjustable with the base frame, wheels, and caster forks from 14” to 19”. Seat Height Adjustment: 1) Locate the caster fork adjustment positions on the front 2) Remove the screw and locknut that secure the caster to the fork. 3) Raise or lower the caster to the desired position (See the seat Height combination diagram to determine the desired position) 4) Insert the screw and locknut through the corresponding holes...

  • Page 22: Leg Rests

    Seat Height and Wheel Combinations Matrix: Leg Rests Leg Rest installation and removal is accommodated via sliding the leg rest on to the receiving post at the corner of the seat. The leg res is dropped on and slid back around as lowered, then once seated, pulled forward to latch.
  • Page 23 The leg rests can be adjusted to length using an M4 hex key. The bolt is removed and the length can be extended or shortened via sliding the lower tube inside the upper tube. There are various hole options to select from for reinserting the bolt. The foot plate can be moved fore and aft at the base of the leg rest, as well as adjusting the foot angle, using the same fastener set.
  • Page 24 The lateral angle of the foot plate can be adjusted with an M4 hex key and a 10 mm wrench. Use the wrench to loosen the nut and adjust the hex bolt to reach the desired lateral angle. Tighten the nut with the 10 mm wrench when complete. Comfort-Tilt...

  • Page 25: Section 5 - Wheelchair Repair And Maintenance

    SECTION 5 - WHEELCHAIR REPAIR AND MAINTENANCE Broda Chair Inspection/Maintenance Schedule* Part Initial Inspect/Adjust Inspect/Adjust Inspect/Adjust Inspect/Adjust Inspection Weekly Monthly Periodically Regularly Gas Cylinders: Check to ensure functions operated by cylinders are functioning properly: Cables and Handles: Cables connected to cylinders...

  • Page 26: Functional Testing

    Broda recommends that the chair be inspected as often as each use if there is any reason to be concerned about the possibility of increased wear or loose or missing fittings.

  • Page 27: Cables And Cable Handles

    These can be found on a sticker that is attached to the base on the bottom of the chair. NOTE: Only a person with training on the BRODA chair should attempt to do any repairs or maintenance on the wheelchair. Certain repairs may require a BRODA representative to personally attend to the repair.

  • Page 28: Rear Wheels

    2. Cut the cable ties that secure the cable to the frame of the wheelchair (carefully note the location of the cable ties and how the cable is routed around the frame of the wheelchair.) 3. Unscrew the tilt handle from the frame. 4.

  • Page 29: Gas Cylinders

    Cylinder Stem Actuator The use of gas charged springs on BRODA products allow the caregiver to easily make adjustments to the tilt and recline with a minimum amount of effort. The gas cylinders contain pressurized Nitrogen gas, it is not flammable nor is it toxic. The cylinder(s) provide 800 Newton’s (180 lbs.) of force.
  • Page 30 Troubleshooting the Cylinders Often, when experiencing problems with cylinders on BRODA wheelchairs, the cylinder is not damaged, it usually only requires an adjustment. There are two common adjustments. 1. The pin that the cable handle pulls on at the end of the cylinder is not connected correctly.
  • Page 31 3. Check the function of the cylinder and repeat steps 3 & 4 until the cylinder functions properly. 4. Tighten the lock nut loosened in step 1. Removing and Installing the Cylinders 1. Remove the 5/16” mounting bolt from the end of the cylinder (requires 2 x 1/2” wrenches).

  • Page 32: Appendix 1 - Broda Warranty

    If the defective parts are not returned to BRODA on request, the owner will bear the cost of the replacement parts on invoice from BRODA.
