- Page 1 Kodak Scanners Cleaning and Consumable Replacement Instructions i100/i200/i260 Versitec is a division of Cranel, Inc.
- Page 3 INSTRUCTION MANUAL FOR KODAK i100/i200/i260 Scanner Versitec 1- 888 - 722 - 6548 www. versitec.com...
- Page 4 TABLE OF CONTENTS I. i200 Scanner Maintenance Step One: Cleaning the scanner........2 Step Two: Cleaning the separator module....3 - 4 Step Three: Cleaning the feed module......4 - 5 Step Four: Cleaning drive rollers & transport area..6 - 7 Step Five: Cleaning the imaging guides......7 Step Six: Cleaning the paper path........8 II.
-
Page 5: Cleaning The Scanner
Wash your hands with soap and water after performing maintenance procedures. Refer to the Material Data Safety Sheet (MSDS) for more information. The MSDS is available on the Kodak web site at www.kodak.com/go/MSDS. Allow all rollers to dry completely before using the scanner. -
Page 6: Cleaning The Separator Module
Cleaning the separator module Power down the scanner. Remove any documents from the feeder area. Lift up the scanner door release to unlatch the scanner door. Pull up to open the scanner door. Remove the separator module by pulling it down and lifting it off. Separator module Versitec 1- 888 - 722 - 6548... -
Page 7: Cleaning The Feed Module
Manually rotate and wipe the separator module rollers with a roller cleaning pad. Inspect the rollers. If the separator roller tires show signs of wear or damage, replace the tires or the separator module. Insert the separator module and align the shaft ends. Press until the separator module clicks into place. - Page 8 Remove the feed module by pushing it to the right and lifting it out. Feed module Manually rotate and wipe the feed module rollers with a roller cleaning pad. Inspect the feed module. If the feed module tires show signs of wear or damage, replace the tires or the feed module.
- Page 9 Cleaning the Drive Rollers and Transportation Area Manually rotate and wipe the drive rollers with a roller cleaning pad. Clean any dust or debris in the slots around the drive rollers. Wipe the upper and lower transport areas with a roller cleaning pad. Dry the transport area with a dry Staticide Wipe.
-
Page 10: Cleaning The Imaging Guides
Rear roller cover Remove any dust or debris under the rear roller cover. Re-install the rear roller cover. Go to the next section to clean the imaging guides. Cleaning the Imaging Guides Clean the exposed (top side) surfaces of the imaging guides. You do not need to remove the imaging guides for cleaning. -
Page 11: Cleaning The Paper Path
Cleaning the Paper Path Remove the wrapping from the Transport Cleaning Sheet. Adjust the paper feeder guides to fit the cleaning sheet. Feed the cleaning sheet (adhesive side up) through the scanner in portrait orientation until all residue is removed from the drive rollers. Adjust the feeder guides to fit, then feed the cleaning sheet (adhesive side up) through the scanner in landscape orientation until all residue is removed from the drive rollers. - Page 12 Item CAT No. 124-1066 KODAK Feeder Consumables Kit for i260 Series Scanners (1 complete feed module, 1 complete separator module, 2 pre-separation pads, 18 roller tires) KODAK Extra-Large Feeder Consumables Kit for 821-5808 i200 Series Scanners (5 complete feed modules, 5 complete separator modules, 10 pre-separation pads, 90 roller tires) Use only these replacement parts in your scanner.
-
Page 13: Corporate Headquarters
www.versitec.com Corporate Headquarters 8999 Gemini Parkway Columbus, OH 43240 Fax: 614.431.8388 Repair Center Western Region Office 908 Boston Turnpike Road 8001 Irvine Center Drive, 4th Floor Shrewsbury, MA 01545 Suites 411, 412, 413 Fax: 508.460.1890 Irvine, CA 92618 For inquiries on consumables, call Versitec at: 888.722.6548...
