i100 Series Scanners
Image Processing Guide
User's Guide
A-61517

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kodak i100 Series

Summary of Contents for Kodak i100 Series

  • Page 1 Series Scanners Image Processing Guide User’s Guide A-61517...
  • Page 2 ISIS is a registered trademark of Pixel Translations, a division of Input Software, Inc. Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 3 You can use the applications based on the ISIS Driver or TWAIN Data source to enable image processing (both are available on the CD included with the scanner). Kodak Capture Software is also available as a choice for your scanning application.

  • Page 4: About This Manual

    NOTE: The scanned images used in this guide were selected for the challenges presented to a typical scanner due to the low-contrast characteristics of the images. The following documentation supports the Kodak i100 Series Scanners. These publications are available on the CD that came with your scanner, or go to www.kodak.com/go/DI...
  • Page 5 Image outputs A-61517 October 2004 i100 Series Scanners can return bi-tonal, grayscale or color images to the host. Below is a description of the valid combinations. The i150 Scanner is a simplex scanner. This means that only one side of the document may be captured.
  • Page 6 FB.tif (front bi-tonal) A-61517 October 2004 These image files can be controlled through the application independently. FC.jpg (front color) RB.tif (rear bi-tonal) Another example of a simultaneous output where all four images are returned to the host would create the following four files: Front grayscale: FG.jpg.
  • Page 7 These image files can be controlled through the application independently. FG.jpg (front FB.tif (front RG.jpg (rear RB.tif (rear grayscale) bi-tonal/binary) grayscale) bi-tonal/binary) A-61517 October 2004...

  • Page 8: Best Practices

    This chapter provides you with recommendations for program logic, which will allow you to interact efficiently with the i100 Series Scanner. This high-level information is not intended to be used as a programming guide. The following information is provided in this chapter: Basic image capture Controlling image transfer order –...
  • Page 9 Image Processing parameter changes remain in effect until one of the following conditions occur: The scanner is powered down using the power switch. New imaging parameters are sent from the host. 4. Prepare documents according to the instructions found in the Kodak i100 Series Scanners, User’s Guide.
  • Page 10 For more information see the sections entitled, “Controlling image transfer order” and “Image header information” later in this chapter. Feed documents according to the instructions found in the Kodak i100 Series Scanners, User's Guide. Scanning is disabled to allow the host to download configuration/ setup changes between jobs and to handle certain types of errors.
  • Page 11 The scanner recognizes and reports a variety of error conditions. Some errors are reported to the host (via the 1394 interface) or via the LEDs on the scanner while others are reported to both the host and the LEDs. An error (via the 1394 interface) is defined as either a current or deferred error.

  • Page 12: Transfer Order

    End loop This job stream is available for all i160 Scanners. 1. Prepare documents. 2. Start the scanner to do color duplex scanning (front color and rear color). 3. Setup the scanner to retrieve color images. 4. Enable the scanner and start polling.
  • Page 13 This job stream is available for i160 Scanners. 1. Prepare documents. 2. Start the scanner to do simultaneous output duplex scanning by selecting front bi-tonal, front color, rear bi-tonal and rear color. 3. Setup the scanner to retrieve bi-tonal images first.
  • Page 14 Read rear grayscale image header Read rear grayscale image End loop This job stream is available for all i100 Series Scanners. 1. Prepare documents. 2. Start the scanner to do bi-tonal scanning. 3. Setup the scanner to retrieve bi-tonal images.
  • Page 15 Simultaneous output bi-tonal and color simplex A-61517 October 2004 This job stream is available for all i100 Series Scanners. 1. Prepare documents. 2. Start the scanner to do color scanning. 3. Setup the scanner to retrieve color images.
  • Page 16 Jam and fault recovery A-61517 October 2004 This job stream is available for all i100 Series Scanners. 1. Prepare documents. 2. Start the scanner to do simultaneous output bi-tonal and grayscale scanning (front bi-tonal, front grayscale).

  • Page 17: Bar Code Recognition

    Unlike some Kodak scanners the i100 Series Scanners do not include a bar code accessory. Bar code functionality is the responsibility of the host system. The main imaging parameter, which may affect bar code read rates, is resolution.
  • Page 18 When using Adaptive Threshold Processing, there are four imaging parameters which effect electronic color dropout: Threshold Value/Filter Threshold, Background Value/Background, Contrast %, and Threshold. The default settings are: Contrast% = 50 Threshold = 90 Color Filter = 175 Background = 245 If the values above do not give you the desired results, you may need to vary these values accordingly.
  • Page 19 100 U 129 U 101 U 130 U 102 U 134 U Yellow U 135 U 106 U 136 U 107 U 137 U 108 U 1345 U 109 U 1355 U 113 U 1365 U 114 U 1375 U 115 U 141 U 116 U...
  • Page 20 100 U 113 U 101 U 114 U 102 U 120 U Yellow U 1205 U 106 U 1215 U 107 U 127 U 108 U 134 U 121 U 2975U 148 U 304 U 100 U 256 U 1205 U 2562 U 217 U 263 U...
  • Page 21 Image header information A-61517 October 2004 An image header is associated with every image captured by the scanner. Following is a list of information available in the image header. Image length size of the image data in bytes. Image identifier...

  • Page 22: Zone Processing

    Zone processing A-61517 October 2004 Zone processing is available on the i100 Series Scanners. Some applications have a requirement to store part of an image in color or grayscale and the rest of the image in bi-tonal format (this saves storage space by not storing the entire image in color or grayscale).
  • Page 23 A-61517 October 2004 3. Setup the scanner to retrieve bi-tonal images first. 4. Setup front bi-tonal for auto cropping. 5. Setup front color for relative cropping and define the appropriate area. 6. Enable the scanner and start polling. Loop Read front bi-tonal image header...

  • Page 24: Using The Twain Data Source

    Windows directory\twain_32\ kodak\kds_i100, includes information you need to setup the TWAIN Data Source to simulate an i100 Series Scanner in order for you to begin development work without a physical scanner. This is also documented...
  • Page 25 Imaging>Scan Validation Tool. Enter the filename or choose Browse to locate the ScanValidation.exe file. 2. Select TWAIN for the Driver Type and the Kodak Scanner i100 as the Driver. The Scan Validation Tool dialog box will be displayed. 3. Double-click the Scanner icon to access the Kodak Scanner...

  • Page 26: Scan Validation Tool Dialog Box

    Enables the scanner to feed one page. This button is only available when the scanner is enabled. When selected, will disable the scanner. Displays the License Key window. This option should only be used when directed by a Kodak representative. Closes the image viewer.

  • Page 27: Kodak Scanner Properties Dialog Box

    Scan Validation Tool session. The Kodak Scanner Properties dialog box consists of the following tabs. Each tab will be described within this chapter. Click on each tab to set all the desired values. You do not have to click OK until you have made all selections on all of the tabs.

  • Page 28: Buttons On The Kodak Scanner Properties Dialog Box

    Buttons on the Kodak Scanner Properties dialog box A-61517 October 2004 Following are descriptions of the buttons located at the bottom of the dialog box. Defaults when you select Defaults, the message Reset all values to factory defaults? will be displayed. Clicking Yes will reset all values on all tabs to the factory default settings.

  • Page 29: The Imaging Tab

    The Imaging tab A-61517 October 2004 The Imaging tab allows you to define image processing values that can be applied to your scanner. Camera Selection box lists the available sides (front and rear) of any document where you can define individual image processing values.
  • Page 30 Available binarization options are: iThresholding: selecting iThresholding allows the scanner to dynamically evaluate each document to determine the optimal threshold value to produce the highest quality image. This allows scanning of mixed document sets with varying quality (i.e., faint text,...
  • Page 31 A-61517 October 2004 When Adaptive Thresholding is selected, Contrast values may range from 1 to 100. Fixed thresholding ATP disabled Fixed Processing used for black-and-white and other high contrast documents. A single level is set to determine the black-and-white transition. The threshold is programmable over the entire density range. Fixed thresholding sets Contrast to 0.
  • Page 32 A-61517 October 2004 Noise Filter occasionally small dots or specks appear in the background of a scanned image. These specks increase file compression size and usually contain no image information. Using the Noise Filter on documents containing very fine detail (e.g., the dot on an "i"...
  • Page 33 A-61517 October 2004 Contrast % sets the image contrast by adjusting the difference between black and white, thereby making an image sharper or softer. In a low-contrast setting, the difference between black and white is small, so the image is softer. In a high-contrast setting, the difference between black and white is large, so the image is clearer.
  • Page 34 200 dpi; 80 Threshold; 20 Contrast 200 dpi; 80 Threshold; 100 Contrast Resolution or dots per inch (dpi) indicates the scanning resolution, which largely determines the quality of the scanned image. The greater the resolution, the better the reproduction. However, scanning at a higher resolution also increases scanning time and file size.
  • Page 35 Not applicable for bi-tonal images. See the next section “Scanning color images”. Paper Source provides the following option: ADF: select this option when using the scanner in continuous feed mode. Calibrate calibration optimizes the optical system in your scanner in order to achieve the best overall quality of scanned images.
  • Page 36 You can choose from the three Kodak default color tables: Pictures, Text and Text with Pictures, or if you have created your own custom color tables using the Brightness and Contrast Control Reference Guide, A-61506, these tables will also be available.
  • Page 37 A-61517 October 2004 Paper Source provides the following option: ADF: select this option when using the scanner in continuous feed mode. Calibrate calibration optimizes the optical system in your scanner in order to achieve the best overall quality of scanned images. Frequent calibration is not needed or recommended.
  • Page 38 You can choose from the three Kodak default color tables: Pictures, Text and Text with Pictures, or if you have created your own custom color tables using the Brightness and Contrast Control Reference Guide, A-61506, these tables will also be available.
  • Page 39 Convert Color to Grayscale captured image to be 8-bit grayscale instead of 24-bit color. Paper Source provides the following option: ADF: select this option when using the scanner in continuous feed mode. Calibrate calibration optimizes the optical system in your scanner in order to achieve the best overall quality of scanned images.

  • Page 40: The Paper Tab

    The Paper tab A-61517 October 2004 The Paper tab allows you to define values relating to image output (i.e., cropping values, rotation, paper size and units of measure). Camera selection box lists the available sides of an image that you can define individual image processing values.
  • Page 41 Cropping values A-61517 October 2004 Cropping allows you to capture a portion of the document being scanned. You can define the cropping area by the x and y offset values, width and length. Cropping options can be used independently with color/grayscale and bi-tonal images and are also front/rear independent.
  • Page 42 Enter the x and y offset which defines the upper left corner of the zone relative to the upper left corner of the desired document. Enter the length and width of the zone to be captured. Original Bi-tonal image Relative to Document You can enter the desired values in the fields or use the arrow keys to define the desired area.
  • Page 43 X-Offset for Fixed to Transport cropping this is the distance from the left end of the scanner to the left edge of the scanning area. For Relative to Document cropping this is the distance from the left edge of the document to the left edge of the zone.
  • Page 44 In addition to cropping and overscan values that can be applied using the Paper tab, the following options are available: Preset Front/Rear Size the default paper size is set when a scanner is first selected. You can choose a different paper size using the drop-down list box.

  • Page 45: The Compression Tab

    For more information about these selections, see the section entitled “Image outputs” in Chapter 1. Compression the i100 Series Scanners can be configured via the host to output bi-tonal, grayscale, and color images in various supported formats and resolutions independent of each other and each side of the image.
  • Page 46 A-61517 October 2004 The following color/grayscale compression options are available: JPEG JPEG compression offers a JPEG quality of Draft, Good, Better, Best, Superior. Draft: smallest file size with draft image quality Good: larger file size with good image quality Better: larger file size with better image quality Best: larger file size with the best image quality Superior: largest file size with superior image quality (none)

  • Page 47: The Dropout Tab

    (through OCR and ICR technology) read pertinent data without interference from the lines and boxes of the form. The i100 Series Scanners can dropout either red, green or blue. The Dropout tab allows you to select the desired dropout color and alter the filter threshold and background.
  • Page 48 For iThresholding, the scanner will automatically determine the value for this. If the value the scanner determined is lower than the one you entered, that value will be used. Therefore, if using iThresholding, it is suggested that you leave the value at the default.

  • Page 49: The Multifeed Tab

    The Multifeed tab A-61517 October 2004 Multi-feed Detection aids in document processing by detecting documents that may go through the feeder overlapped. Multi-feeds can occur due to stapled documents, adhesives on documents, or electrostatically charged documents. Multi-feed Detection combines ultrasonics (amplitude and phase) with physical length detection to virtually eliminate the chance of losing data due to multi-feeds.
  • Page 50 A-61517 October 2004 Document Ultrasonic Monitor scanner will work to determine if more than one document is fed into the transport. Multi-feeds are triggered by detecting air gaps between documents. This allows multi-feed detection to be used with applications containing documents with mixed thicknesses. You may set the Multi-Feed Detection to high, medium or low sensitivity.

  • Page 51: The Options Tab

    Transport Timeout allows you to set a transport timeout value. This value is the amount of time the scanner will wait after the last document enters the transport before the transport timeout action is taken. You can specify a time delay setting from 3 to 30 seconds. The default is 8 seconds.

  • Page 52: The Setup Tab

    The Setup tab is only available when running the Scan Validation Tool, via the TWAIN Data Source. Package the scanner firmware runs your Kodak i100 Series Scanner. The value displayed in the Current field is the version of firmware currently in use by your scanner. Periodically Kodak releases updated versions of firmware which are available through Kodak Service and Support.

  • Page 53: The Info Tab

    The Info tab A-61517 October 2004 The Info tab allows you to have access to the Scanner Data. Info shows the following information about your scanner: Scanner Model, Serial Number, Firmware Revision, Accessories, Date/Time, Power-On, Lamp, First Scan, Total Pages scanned and the Name and Company of the person who installed the scanner.

  • Page 54: Using The Isis Driver

    4 Using the ISIS Driver Installation A-61517 October 2004 The ISIS driver is included with the scanner. You can install the driver from the CD. 1. Insert the CD into the drive. 2. Follow the instructions on each screen as prompted.
  • Page 55 A-61517 October 2004 2. Select the ISIS driver for the Drive Types and the Kodak Scanner i160 as the Driver. The Scan Validation Tool dialog box will be displayed. NOTE: If you are using the TWAIN Data Source go to Chapter 3.
  • Page 56 This button is only available when the scanner is enabled. When selected, will disable the scanner. Displays the License Key window. This option should only be used when directed by a Kodak representative. This is valid only for TWAIN. Closes the image viewer.
  • Page 57 A-61517 October 2004 Button Description Opens the image viewer to display one image at a time. Opens the image viewer to display two images at a time. Opens the image viewer to display four images at a time. Opens the image viewer to display eight images at a time.

  • Page 58: Scanner Settings Dialog Box

    This main dialog box provides high-level access to the functionality of the scanner giving you the ability to control the characteristics of all possible imaging combinations. NOTE: For the purpose of this manual, all displayed dialog boxes assume the features available on the Kodak i160 Scanner.

  • Page 59: Buttons On The Scanner Settings Dialog Box

    Following are descriptions of the buttons located at the bottom of the dialog box. More displays the More Scanner Settings dialog box. This dialog box provides additional image processing settings unique to i100 Series Scanners. Area displays the Scan Area dialog box.
  • Page 60 Calibrate calibration optimizes the optical system in your scanner in order to achieve the best overall quality of scanning images. Frequent calibration is not necessary or recommended. To calibrate the scanner: 1. Click Calibrate. The following message is displayed: 2. Place the 12- x 12-inch calibration target in the feeder and click OK.
  • Page 61 For example, if you are scanning front color and front binary and you select Binary First the scanner will return the front binary image, then the front color image.

  • Page 62: Image Processing Settings

    Simplex – Back indicates that only one side (back side) of the document will be scanned. Duplex indicates that both sides of the document will be scanned. select this option when using the scanner in continuous feed mode. Dots per inch (dpi) or Resolution which largely determines the quality of the scanned image.
  • Page 63 Available binarization options are: iThresholding: selecting iThresholding allows the scanner to dynamically evaluate each document to determine the optimal threshold value to produce the highest quality image. This allows scanning of mixed document sets with varying quality (i.e., faint text,...
  • Page 64 You can choose from the three Kodak default color tables: Pictures, Text and Text with Pictures, or if you have created your own custom color tables using the Brightness and Contrast Control, these tables will also be available.
  • Page 65 A-61517 October 2004 Cropping allows you to capture a portion of the document being scanned. All cropping options can be used with color/grayscale and binary images. Front and Rear cropping are independent, however, for simultaneous output scanning color/grayscale and binary cropping must be the same per side.
  • Page 66 This option may be used in conjunction with auto cropping where a separate color or binary area to be saved is desired. It is very useful in applications where a photograph, signature, embossment or seal appears in a consistent area for an application (you may want that small area in color and the rest in binary).
  • Page 67 The Page Layout area allows you to select paper size and viewing orientation. The default paper size is set when a scanner is first selected. You can choose a different paper size using the drop-down list box. Use Scanner’s Maximum to enable auto cropping.
  • Page 68 Scan the document to check the contrast. Automatic not available for i100 Series Scanners. Threshold thresholding is used to convert a grayscale image into a binary (1 bit/pixel) image. The thresholding value ranges from 0 to 255.

  • Page 69: More Scanner Settings Dialog Box

    More Scanner Settings dialog box A-61517 October 2004 Additional image processing values unique to the i100 Series Scanners are available when you choose More on the Scanner Settings dialog box. 4-16...
  • Page 70 For example, if you are scanning front color and front binary and you select Binary First the scanner will return the front binary image, then the front color image.
  • Page 71 Image Control options A-61517 October 2004 JPEG Quality JPEG compression offers a JPEG quality of Draft, Good, Better, Best and Superior. Draft gives you the smallest file size with draft image quality. Good gives you the smallest file size with good image quality. Better gives you a larger file size with better image quality.
  • Page 72 Polarity the host computer provides information to the scanner defining whether the image should be stored in standard or reverse polarity. The default polarity is Black on a White background. Reverse polarity is White on a Black background. Black on White polarity...
  • Page 73 Noise Filter A-61517 October 2004 Occasionally small dots or specks appear in the background of a scanned image. These specks increase file compression size and usually contain no image information. Using the Noise Filter on documents containing very fine detail (e.g., the dot on an "i" in 4-point type) may cause information to be lost.
  • Page 74 ICR technology) read pertinent data without interference from the lines and boxes of the form. You can select the desired dropout color, and alter the filter threshold and background. The i100 Series Scanners can drop out red, green or blue. None is the default.

  • Page 75: Scanner Control Dialog Box

    Scanner Control dialog box A-61517 October 2004 When you select the Scanner Control button on the More Scanner Settings dialog box, the Scanner Control dialog box will be displayed. This dialog box allows you to set multi-feed detection, Energy Saver values and transport timeout.
  • Page 76 Stop Scanner on Multi-Feed If the option is disabled, the scanner will display and log the condition but continue to operate. If enabled, the scanner will display, log the condition and stop the feeder. When an overlap or multi-feed is detected, the scanner stops the feeder, clears the transport of all pages and then the document can be refed.
  • Page 77 A-61517 October 2004 Ultrasonic Detection Sensitivity scanner will work to determine if more than one document is fed into the transport. Multi-feeds are triggered by detecting air gaps between documents. This allows multi-feed detection to be used with job sets containing documents with mixed thicknesses.

  • Page 78: Defining The Scan Area

    A-61517 October 2004 The Scan Area dialog box is only available for images when the Cropping option selected on the Scanner Settings dialog box is either Fixed to Transport cropping or Relative To Document cropping. NOTE: Select the side and image to be defined by highlighting Front...
  • Page 79 Height — the height of the scanning area. If Overscan is not selected, the scanner will not continue capturing beyond the trail edge of the document. For example, if you set up the scanner for portrait-fed 8 ½” x 11” documents, and you scan an 8 ½ x 4”...
  • Page 80 A-61517 10/04 Eastman Kodak Company, 2004 EASTMAN KODAK COMPANY Document Imaging Rochester, New York 14650 Kodak is a trademark of Eastman Kodak Company. Printed on recycled paper.

This manual is also suitable for:

I150I160
