Array Application Guide
A Guide to Assist in the Specifying of JBL Installed Sound Products
Featuring 44 Pre-Designed Arrays of Application Engineered
TM
Series and
Precision Directivity
TM
5000 Series Products With Array Optimization Tips
Rev. C
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Application Engineered Series and is the answer not in the manual?

Questions and answers

Related Manuals for JBL Application Engineered Series

Summary of Contents for JBL Application Engineered Series

  • Page 1 Array Application Guide A Guide to Assist in the Specifying of JBL Installed Sound Products Featuring 44 Pre-Designed Arrays of Application Engineered Series and Precision Directivity 5000 Series Products With Array Optimization Tips Rev. C...

  • Page 2: Table Of Contents

    Table of Contents Page Introduction Suspending Loudspeaker Arrays Array Applications: Speech Systems Combination Speech & Music Systems High-Impact Music Systems Array Tips: 10-12 Modeling Arrays in Rooms Optimizing Long-Throw/Downfill Systems Signal Processing Low Frequency Pattern Control Planar Array Frames Array Types: A series –...

  • Page 3: Introduction

    Many of the arrays take advantage of the available hardware developed to rig some of the more popular configurations. This includes the PAF Planar Array Frames. A further description of this hardware can be found in the JBL publication: AE Series Bracket and Array Frame Handbook available on the JBL Professional website.

  • Page 4: Suspending Loudspeaker Arrays

    None of the information presented herein is intended as a representation or warranty on the part of JBL. Anyone making use of this information assumes all liability arising from such use.
  • Page 5 JBL is not responsible for the application of its products for any purpose or the misuse of this information for any purpose. Furthermore, JBL is not responsible for the abuse of its products caused by avoiding compliance with inspection and maintenance procedures or any other abuse.

  • Page 6: Array Applications

    Array Applications The arrays described in this guide are developed to meet the performance goals of a wide variety of applications. Array recommendations are largely dictated by the intended function of the sound system along with the size and shape of the room. For this discussion, we will divide the function of the sound system into three broad categories: Speech, Speech &...

  • Page 7: Combination Speech & Music Systems

    Figure 3: Array G4 (p. 34) used as an exploded cluster in a fan-shaped room For larger center clusters, consider the D or E series of arrays. For three- and four-cluster systems as described above (see Figure 3), the G series of arrays are particularly useful given their low profile and excellent polar characteristics.
  • Page 8 Figure 4: Array G4 (p. 34) used in an exploded configuration in an auditorium Figure 5: Array E3 (p. 25) used in an exploded configuration in a fan-shaped room Some of the array types described have subwoofers integrated into the array; others do not.

  • Page 9: High-Impact Music Systems

    High-Impact Music Systems While these systems are also sometimes used for speech, their primary purpose indicates that the arrays must produce high SPL Levels and have extended bandwidth by integrating subwoofers – whether flown or ground supported – into the system. Rectangular and auditorium shapes can have enhanced L/R only systems or exploded cluster systems –...

  • Page 10: Array Tips

    – multiple arrays and fills – combine to produce the complete solution. EASE models for selected arrays are available on the JBL web site. Optimizing Long-throw/Short-throw Loudspeaker Systems Many sound reinforcement applications call for loudspeakers to be arranged in a “long- throw/short-throw”...

  • Page 11: Signal Processing

    DSP. Level differences may be done at the amplifier if required. Loudspeaker DSP settings may be found on the JBL web site. For the crossover between the subwoofers and the low-frequency section, a 24 dB/octave L-R crossover slope on each side is recommended.

  • Page 12: Planar Array Frames

    MORE INFORMATION For more information on designing loudspeaker system arrays, refer to JBL Audio Engineering for Sound Reinforcement by John Eargle and Chris Foreman (Hal Leonard Publications, 2002) Additional system design information, including advanced design concepts, can be found at the "Technical Library”...

  • Page 13: A Series - Two-Element Vertical Array With Vertical Orientation

    Medium Power Solution: 2 ch. 300W [Crown CTs600] Recommended DSP: (2 channels for medium power) 2 channels required . [Crown PIP-USP3, dbx Driverack 260, BSS FDS- 334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -13-...
  • Page 14 Medium Power Solution: AM4315: 1 ch. 600W [Crown CTs1200], AM4200: 1 ch. 300W [Crown CTs600] Recommended DSP: (2 channels for Medium Power) 3 channels required . [Crown PIP-USP3, dbx Driverack, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -14-...
  • Page 15 PD5322: LF: 1 ch. 2000w [Crown I-T4000], PD5322 M/H: 1 ch. 600w [Crown CTs1200] AM6200: 1 ch. 600W [Crown CTs1200] Recommended DSP: 3 channels required. [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -15-...
  • Page 16 2000w [Crown I-T4000], AM6200: 1 ch. 600W [Crown CTs1200] Recommended DSP: 3 channels required. [Crown PIP-USP3, Crown I-Tech, dbx Driverack 260, BSS FDS-334, BSS FDS-366 BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -16-...
  • Page 17 PD5322 LF and PD5122: 2 ch. 2000w (Crown IT4000), M/H: 1 ch. 600w (Crown CTs 1200) Recommended DSP: 2 channels required. [Crown PIP-USP3, dBX Driverack PA, BSS FDS-334, BSS SoundWeb] Processing for both LF sections is identical for standard use. Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -17-...
  • Page 18 DSP processing settings. No additional steps are required Tech to realize the increased vertical directivity offered by this array configuration. Refer to JBL Note V1 #32 for additional information and polar data concerning this array.

  • Page 19: B Series - Two-Element Horizontal Array

    Medium Power Solution: AM4212/64 x 2: 2 ch. 600W [Crown CTs1200] or 1 ch. 1000W [Crown CTs2000] Recommended DSP: (1 channel for Medium Power) 1 channel required . [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -19-...
  • Page 20 1 ch. 1000W [Crown CTs2000 Recommended DSP: (1 channel for Medium Power) 1 channel required . [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -20-...
  • Page 21 Array B3 Two-element Horizontal Array with Subwoofer Application Engineered 2-way 12” loudspeakers horizontally splayed plus subwoofer RRAY VERVIEW This array is a great choice for small to medium-sized rooms as a center cluster. • Provides a cost-effective center cluster solution with excellent coverage at medium SPL levels •...
  • Page 22 Array B4 Two-element Horizontal Array Precision Directivity 2-way 12” loudspeakers horizontally splayed RRAY VERVIEW This array can be used for medium to large-sized rooms as a center cluster, or as part of an • exploded cluster design utilizing multiple arrays. Provides a cost-effective solution with defined coverage at medium to high SPL levels for •...

  • Page 23: C Series - Three-Element Low-Profile Horizontal Array

    Array C1 Three-element Horizontal Array in a Wide Coverage Configuration Application Engineered Mid/High loudspeakers horizontally splayed with Low Frequency Enclosure RRAY VERVIEW This array is a very good choice for small to medium-large rooms as a center cluster speech • system offering very high intelligibility, yet maintaining a low vertical profile.

  • Page 24: D Series - Two-Element Horizontal Array With Subwoofer

    Array D1 Two-element Horizontal Array with Subwoofer Application Engineered 3-way 15” loudspeakers horizontally splayed plus Subwoofer RRAY VERVIEW • This array is a good choice for medium to large rooms as a center cluster or as part of a Left/Right or exploded cluster system. Full bandwidth 4-way system is excellent for high-impact musical program requirements.
  • Page 25 Array D2 Two-element Horizontal Array with Subwoofer Application Engineered 3-way Quad 10” loudspeakers horizontally splayed plus Subwoofer RRAY VERVIEW This array is a good choice for medium to large rooms as a center cluster or as part of a • Left/Right or exploded cluster system.

  • Page 26: E Series - Two-Element Horizontal Array With Single Downfill

    Array E1 Two-element Horizontal Array with Downfill Application Engineered 3-way 15” loudspeakers horizontally splayed with vertically splayed Application Engineered mid-high downfill RRAY VERVIEW This array is a good choice for medium-sized rooms as a center cluster or as part of a Left/Right •...
  • Page 27 Array E2 Two-element Horizontal Array with Downfill Application Engineered 3-way Quad-10” loudspeakers horizontally splayed with vertically splayed Application Engineered mid-high downfill RRAY VERVIEW This array is a very good choice for medium-sized rooms as a center cluster or as part of a •...
  • Page 28 Array E3 Two-element Horizontal Array with Additional LF and Downfill Application Engineered loudspeakers horizontally splayed with vertically splayed Application Engineered mid-high downfill RRAY VERVIEW This array is a good choice for medium-sized rooms as a center cluster or as part of a Left/Right •...
  • Page 29 Array E4 Two-element Horizontal Array with Downfill Precision Directivity 3-way loudspeakers horizontally splayed with vertically splayed Application Engineered mid-high downfill RRAY VERVIEW This array is a very good choice for medium to large rooms as a center cluster or as part of a •...
  • Page 30 • Spaced source 12” drivers (PD5322 + PD5122) create directivity through 125 Hz to improve gain (See JBL Technote Volume 1, No. 32 for before feedback and optimize evenness of coverage. more information about PD5322/PD5122 LF steering. also see page 18.) Array may be augmented ground stacked subwoofers such as the ASB6128V to create a system •...
  • Page 31 Medium Power Solution: AM4215/64 x 2 (top): 1 ch. 1000W [Crown CTs2000]; AM4215/95 (downfill): 1 ch. 600W [Crown CTs1200] Recommended DSP: 2 channels required. [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb, SoundWeb London] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -31-...

  • Page 32: F Series - Two-Element Horizontal Array With Dual Downfill

    Two-element Horizontal Array with Subwoofer and Downfill Array F1 Application Engineered 3-way 15” loudspeakers horizontally splayed plus subwoofer and horizontally splayed mid/high downfills RRAY VERVIEW • This array is a good choice for medium to large rooms as a center cluster or as part of a Left/Right or exploded cluster system.
  • Page 33 4 channels required. [Crown PIP-USP3, Crown I-Tech, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories: The PAF-2K Array Frame may be used to rig the top tier. Refer to the “AE Series Bracket and Array Frame Handbook”. 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -33-...
  • Page 34 4 channels required. [Crown PIP-USP3, Crown I-Tech, dbx Driverack 260, BSS FDS-366, BSS FDS-334, BSS SoundWeb] Available Accessories: The PAF-2K Array Frame may be used to rig the top tier. Refer to the “AE Series Bracket and Array Frame Handbook”. 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -34-...

  • Page 35: G Series - Two-Element Vertical Array With Horizontal Orientation

    Medium Power Solution: AM4212 x 2: 2 ch. 600W [Crown CTs1200] Recommended DSP: (2 channels for Medium Power) 2 channels required . [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -35-...
  • Page 36 Medium Power Solution: AM4215 x 2: 2 ch. 600W [Crown CTs1200] Recommended DSP: (2 channels for Medium Power) 2 channels required . [Crown PIP-USP3, dbx Driverack 260, BSS FDS- 334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -36-...
  • Page 37 Medium Power Solution: AM4315 x 2: 2 ch. 600W [Crown CTs1200] Recommended DSP: 2 channels for Medium Power 4 channels required ( ). [Crown PIP-USP3, dbx Driverack 260, BSS FDS- 334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -37-...
  • Page 38 PD5322 LF x 2: 2 ch. 2000W [Crown I-T4000], PD5322 M/H x 2: 2 ch. 600W [Crown CTs1200] Recommended DSP: 4 channels required. [Crown PIP-USP3, Crown I-Tech, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -38-...
  • Page 39 AM4315: 1 ch. 600W [Crown CTs1200]; AM4215: 1 ch. 600W [Crown CTs1200] Recommended DSP: 2 channels required. [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb, SoundWeb London] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -39-...
  • Page 40 CTs1200]; AM4212: 1 ch. 300W [Crown CTs600] Recommended DSP: 3 channels required. [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb, SoundWeb London] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -40-...
  • Page 41 AM6340 LF x 2: 2 ch. 1250W [Crown CTs3000], AM6340 M/H x 2: 2 ch. 600W [Crown CTs1200] Recommended DSP: 4 channels [Crown PIP-USP3, dbx Driverack 260, BSS FDS-334, BSS FDS-366, BSS SoundWeb] Available Accessories 3 pc. M10 x 35mm Forged Shouldered Eye-Bolt Kit (JBL part #229-00009-01) -41-...
  • Page 42 Two-element Vertical Array in a Long-Throw/Short- Array G8 Throw Configuration Precision Directivity 2-way 12” loudspeakers horizontally configured and vertically splayed RRAY VERVIEW This array is a very good choice for larger L/R or exploded clusters. • High-frequency waveguides are rotated 90 •...

  • Page 43: Ae & Pd Weather Resistant Configurations

    Network Treatment Conformal urethane-coating Delivery – WRC and WRX are Build-to-Order products and not stocked. Lead time (from when the order is cleared by JBL Credit Dept to shipment from JBL factory) is typically 4 to 6 weeks. Custom Extra-Cost Options: •...

  • Page 44: Painting Ae & Pd Enclosures

    –UF suffix and are delivered “paint ready”. JBL recommends that for custom color installations, the unfinished versions (-UF) should be ordered and painted as required. If however, you wish to paint an enclosure over the JBL “Duraflex” finish, the instructions below should be used as a general guide.
  • Page 45 If the backing is damaged in the removal process it will be necessary to order a replacement – either from JBL or from a third-party foam or grille cloth provider -- if indeed a backing is required for your application.

  • Page 46: Ae & Pd Series Connector Pin-Out Guide

    AE/PD Series Connector Pinout Guide Connectors: All models contain one (1) Neutrik Speakon® connector (either NL4 or NL8, specified below) AND one (1) set of terminal strips. Terminal strips are marked with same pinout labels as below (1+ / 1-, etc). Speakon and terminal connections are in parallel with each other and can be used for loop-through purposes.
  • Page 47 JBL Professional 8500 Balboa Blvd. Northridge, CA 91329 www.jblpro.com © 2005 JBL Professional. All rights reserved. AE/PD Array GdC 9/05 -46-...
