JBL AC15/-WH Technical Manual

Technical Manual
JBL AC15/-WH

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impediance:
• System Input Power Rating:
• Frequency Response:
• Frequency Range:
• System Sensitivity:
• Maximum SPL:
• Crossover Frequency:

SYSTEM COMPONENTS:

• Cabinet:
• Grille:
• Low Frequency
Transducer:
• DC Resistance:
• High Frequency
Transducer:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
16 Ohms
150W Continuous Pink Noise,
300W Program, 600W Peak
90 Hz - 18 kHz (±3 dB)
80 Hz - 20 kHz (–10 dB)
91 dB SP (1 Watt @ 1 Meter)
113 dB SPL Continuous
3.3 kHz
Enclosure (Not for Sale)
364944-001,364944-101 (WH)
225J, 135 mm (5.25 in) Cone
Transducer
9.62 ohms
201J, 25 mm (1 in.) Dome
Tweeter
Warranty 59660
Specification Sheet
365233-001
Carton
365063-001
Filler
365075-001
PKG,Microfoam (2)
49790P
20" x 18" sheets
SYSTEM COMPONENTS:
• DC Resistance:
• Crossover Network:

AURAL SWEEP TEST SPECIFICATIONS:

A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:

PHYSICAL SPECIFICATIONS:

• Enclosure Dimensions:
• Shipping Weight:

WARRANTY INFORMATION:

• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, Low Freq
225J
Horn Tweeter
(365232-002)
201J
(364954-001)
YEL/BLK
GRN/BLK
GRN
SEE NETWORK SCHEMATIC PAGE
NOTE: INDIVIDUAL PARTS FOR THE ABOVE CROSSOVER ARE NOT AVAILABLE.
A COMPLETE REPLACEMENT ASSEMBLY SHOULD BE ORDERED.
(CONT'D)
9.7 ohms
365057-001
10.0V Input, 20 Hz to 20 kHz
7.0V Input, 20 Hz to 2 kHz
0.75V Input, 500 Hz to 20 kHz
241.3mm x 150.3mm x 177.8mm D
(9.5 x 5.9 x 7.0 in D)
10.5 lb (4.7 kg)
YEL
Network
365057-001
04-10
