Page 11: Chapter 1 Introduction
Please refer to Chapter 4 “System Configuration”, section titled “Microsoft Windows License Agreement (First Boot)” for instruction. The “VX5 User’s Guide” is directed toward the VX5 user. It is delivered on the LXE Documentation CD. It contains safety warnings, descriptions of the controls and connectors, instruction on installing antennas, and day to day operation.
Page 12: When To Use This Guide
Use this guide as you would any other source book -- reading portions to learn about the VX5, and then referring to it when you need more information about a particular subject.
Page 13: Document Conventions
Keyword that indicates a potentially hazardous situation, which, if not avoided, WARNING could result in death or serious injury. Keyword that indicates an imminent hazardous situation, which, if not avoided, DANGER will result in death or serious injury. E-EQ-VX5RG-A VX5 Reference Guide...
Page 14: Quick Start
1. Install Vehicle Mounting Bracket (and keyboard mounting bracket) on vehicle. 2. Secure VX5 in Mounting Bracket Assembly. 3. Connect power cable to the VX5. The power cable can also be connected to a UPS battery pack, which is then connected to the VX5.
Page 15: Components
T10A, 125V Connector 12. Cable Strain Relief Bracket and Clips Figure 1-1 VX5 Components COM1 is configured with Pin 9 +5V. COM2 is configured with Pin 9 RI. Refer to Chapter 4, “System Configuration” for more information. E-EQ-VX5RG-A VX5 Reference Guide...
Page 16: Figure 1-2 Vx5 Control Panel
Components 1. Power LED 2. Power Switch 3. Brightness Increase 4. Brightness Decrease Figure 1-2 VX5 Control Panel 1. COM Port DIP Switches 2. USB Connector COM1 COM2 IDE DRIVE SCANNER CARD BUS A SERIAL CARD BUS B 3. ATA Slot...
Page 17: Data Entry
The keyboard is used to manually input data that is not collected otherwise. Almost any function that a full sized computer keyboard can provide is duplicated on the LXE VMT keyboard but it may take a few more keystrokes to accomplish a keyed task.
Page 18: Touchscreen Entry
(touch) of up to 4 oz. of pressure. The touch screen can be used in conjunction with the keyboard and scanner and an input/output device connected to one of the VX5's serial ports. • Touch the stylus to the field of the data entry form to receive the next data feed.
Page 19: Virtual Keyboard
<Shift> key on the virtual keyboard toggles the characters displayed on the keys between upper and lower case. Note: When the virtual keyboard is displayed, the physical keyboard is still active, if attached. Therefore it is possible to input data from both keyboards. E-EQ-VX5RG-A VX5 Reference Guide...
Page 20: Getting Help
LXE website. Contact your LXE representative to obtain the LXE Manuals CD. You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals CD, in the file titled "Contacting LXE". This information is also available on the LXE website www.lxe.com.
Page 21 9000A062CBLD9COMTEC Power Cables Cable, Input Power, 12 FT, VX5 VX6 VX7 9000A073CBLPWR12FT Power Supplies Power Supply, External, AC, W/US Power Cord VX5 VX6 VX7 9000A317PSACUS Power Supply, External, AC, No Power Cord VX5 VX6 VX7 9000A318PSACWW UPS Battery and Cables...
Page 22 Scanner, Powerscan LR 12’ Cbl, US 8310A327SCNRPWRLR12DA9F Scanner, Powerscan, LR, 12’ Cbl, PS/2, US 8310A330SCNRPWRLR11PS2 Scanner, Powerscan, XLR, 8’ Cbl, WW 8320A326SCNRPWRXLR8DA9F Scanner, Powerscan XLR, 12’ Cbl, US 8320A327SCNRPWRXLR12DA9F Scanner, Powerscan XLR, 12’ Cbl, PS/2, US 8320A330SCNRPWRXLR11PS2 VX5 Reference Guide E-EQ-VX5RG-A...
Page 23: Chapter 2 Physical Description And Layout
Chapter 2 Physical Description and Layout Hardware Configuration System Hardware The VX5 hardware configuration is shown in the following figure. Any Type PCMCIA Card or I, II or III Compact Flash w/ PCMCIA Adapter Card Antenna Connector Slot 0 &...
Page 24: Central Processing Unit
Central Processing Unit The LXE VX5 contains an Intel Pentium III 933 MHz CPU. AT Compatible Core Logic The LXE VX5 utilizes AT-compatible core logic. The VX5 supports the following I/O components: • Two 9-pin RS-232 serial ports configured as: COM 1 - 03F8h;...
Page 25: Video Subsystem
2MB of system memory. Power Supply Vehicle power input for the VX5 is 12V to 80V DC nominal and is accepted without the need to perform any manual operation within the VX5. If 12V to 60V DC power is not available – for example, in an office environment – an optional external Universal Input Power Supply can be used to convert AC wall power to an appropriate DC level.
Page 26: Physical Controls
The power (on/off) switch is a toggle switch located on the front control panel of the VX5. The switch is a momentary switch. If the VX5 is Off, pressing the power switch turns the VX5 On. If the VX5 is On, Windows determines the results of a power button press. For example, the VX5 may be configured to: •...
Page 27 Physical Controls The VX5 shutdown may be initiated in any of the following ways: • Selecting the “Shut Down” option from the Windows Start Menu. • Selecting the “Shut Down” option from the Windows Task Manager. The Windows Task Manager is displayed by pressing Ctrl-Alt-Del.
Page 28: External Connectors
Audio connects to a mono telephone headset/microphone. Other external connectors are located as follows: • Antenna connectors are located on the top of the VX5. VX5’s can be configured for a single antenna or dual antennas. • A USB port is available inside the access panel.
Page 29: Scanner Serial Connector (Com1)
Barcode Scanner Power – 400mA max (Default) Ring Indicator – Input Shell CGND Chassis Ground Pin 9 of the COM port can be switched between +5V and RI. See Chapter 4: “System Configuration” section titled “Serial Port Pin 9”. E-EQ-VX5RG-A VX5 Reference Guide...
Page 30: Printer/Pc Serial Connector (Com2)
Bar Code Scanner Power – 400mA max Shell CGND Chassis Ground Pin 9 of the COM port can be switched between +5V and RI. See Chapter 4: “System Configuration” section titled “Serial Port Pin 9” for instruction. VX5 Reference Guide E-EQ-VX5RG-A...
Page 31: Keyboard/Mouse Connector
An LXE VMT keyboard without integrated pointing device • A dongle cable providing PS/2 connections for a standard PS/2 keyboard and mouse. Figure 2-5 VX5 Keyboard Connector and External Keyboard Cable Connector The +5V supply available from the connector is current limited at 400mA. Pinout...
Page 32: Ps/2 Keyboard/Mouse Dongle Cable
External Connectors PS/2 Keyboard/Mouse Dongle Cable The PS/2 keyboard/mouse dongle cable allows a standard PS/2 keyboard and/or mouse to be attached to the VX5. The PS/2 connectors on the dongle cable are labeled for keyboard and mouse. D9 Connector PS/2 Keyboard Connector...
Page 33: Ps/2 Keyboard Connector
CGND Chassis Ground PS/2 Mouse Figure 2-9 PS/2 Mouse Connector Pinout Signal Description MSDAT_A Mouse Data – Not Connected DGND System Ground KBD_PWR Keyboard Power, 5V MSCLK_A Mouse Clock – Not Connected Shell CGND Chassis Ground E-EQ-VX5RG-A VX5 Reference Guide...
Page 34: Ethernet/Usb Connector
External Connectors Ethernet/USB Connector The VX5 Ethernet/USB connector accepts a dongle cable that provides a USB port and an Ethernet port. The connector is shown below. Figure 2-10 VX5 USB Connector and External USB Adapter Cable Connector Pinout Signal Description USB2N_A USB D –...
Page 35: Ethernet/Usb Dongle Cable
External Connectors Ethernet/USB Dongle Cable D15 Connector RJ45 Connector USB Connector Figure 2-11 VX5 Ethernet/USB Dongle Cable D15 Female Connector Figure 2-12 D15 Female Connector Pinout Signal Description USB2N_A USB D – – Not Connected – Not Connected Receive + Receive –...
Page 36: Usb Connector
1 2 3 4 5 6 7 8 Figure 2-14 Dongle Cable Ethernet Port Pinout Signal Description Transmit + Transmit – Receive + – Not Connected – Not Connected Receive – – Not Connected – Not Connected VX5 Reference Guide E-EQ-VX5RG-A...
Page 37: Audio Connector
External Connectors Audio Connector The VX5 audio connector accepts a headset with a 2.5mm plug, such as a mono telephone headset with microphone. Figure 2-15 VX5 Audio Jack for External Speaker or Headphones Note: The VX5 is not configured for standard PC speakers.
Page 38: Power Supply Connector
The VX5 internal power supply can accept DC input voltages in the range of 12 to 80 Volts. Figure 2-16 The Power Connector...
Page 39: Ups Battery Pack Connectors
Not used Chassis Ground Not used DC Negative (–) Output Figure 2-18 The UPS Battery Pack Output Connector Pinout Signal DC Positive (+) UPS Battery Positive (+) Chassis Ground UPS Battery Negative (–) DC Negative (–) E-EQ-VX5RG-A VX5 Reference Guide...
Page 40: Ups Battery Extension Cable Connectors
Chassis Ground UPS Battery Negative (–) DC Negative (–) Output Figure 2-20 The UPS Battery Extension Cable Output Connector Pinout Signal DC Positive (+) UPS Battery Positive (+) Chassis Ground UPS Battery Negative (–) DC Negative (–) VX5 Reference Guide E-EQ-VX5RG-A...
Page 41: Antenna Connector
VX5’s equipped with a radio require an external antenna. A VX5 without a radio does not use an antenna. Some VX5’s may be equipped with a dual antenna option. For these VX5’s, an external antenna must be connected to each antenna connector.
Page 42: Internal Usb Port
An internal USB port can be accessed by removing the access panel cover. This port conforms to USB 1.0 specifications. Figure 2-23 Dongle Cable USB Port Pinout Signal Description 5V_USB_23 USB Power, Current Limited USB2N_A USD D – USB2P_A USB D + DGND USB Power Return Shell CGND Chassis Ground VX5 Reference Guide E-EQ-VX5RG-A...
Page 43: The Keyboards
• A standard PS/2 keyboard via an adapter cable attached to the “Keyboard/MOUSE” port on the VX5. The adapter cable also provides a connector for a PS/2 mouse. • A software keyboard, or virtual keyboard, can be displayed on the touch screen. The virtual keyboard can be used in place of, or in addition to, a physical keyboard.
Page 44: The 95-Key Qwerty Keyboard With Pointing Device
Designed for ease of use with Windows operating systems, the 95-key keyboard with pointing device connects via a cable to the keyboard port on the VX5. Additional Windows keys (the Windows log key and the Application key) and an integrated pointing device are provided for ease of use with Windows operating systems.
Page 45: Keyboard Backlight
“backlight” key in the upper right hand corner of the keyboard. Pressing the backlight key cycles the keyboard backlight through the levels of backlight intensity: • • Maximum intensity • Medium intensity • Low intensity. E-EQ-VX5RG-A VX5 Reference Guide...
Page 46: The 60-Key Qwerty Keyboard
The hidden keys supported by the VX5 are listed in Appendix A, "Key Maps". Unused Key Functions There are several key functions on the 60-key keyboard that are not used on the VX5. These include: •...
Page 47: Numlock And The Vx5
The 60-key keyboard does not have a NumLock indicator or key. NumLock can be toggled On or Off using the <2 > <SHIFT> <F10> keypress sequence. Keyboard Backlight The LXE keyboard keys are backlit with LEDs. The backlight is manually controlled using the <2 > + <CTRL> + <F10> keypress sequence. Keyboard LEDs The VX5 keyboard has three (2) LED indicators.
Page 48: Secondary Keys Led
> and <F1> to turn CapsLock on and off. Press <2 > and <↑> to initiate the PgUp command. Press <2 > and <Q> to type the “!” key. Press <2 > and <BkSp> to enter the Insert (Ins) mode. VX5 Reference Guide E-EQ-VX5RG-A...
Page 49: Control Keys
The Keyboards Control Keys The VMT keyboard has several control keys. Because of the construction of the VX5 and the Microsoft Windows operating system, many of the Control Keys are not used on the VX5. Note: The 2 functions of the <F4> and <F5>keys are not used as the display brightness is adjusted via the buttons on the control panel.
Page 50: General Windows Keyboard Shortcuts
The Keyboards General Windows Keyboard Shortcuts Use the keyboard shortcuts in the chart below to navigate with any VX5 keyboard. These are standard keyboard shortcuts for Windows applications. Press these keys … To … CTRL + C Copy CTRL + X...
Page 51: Ps/2 Keyboard/Mouse
The Keyboards PS/2 Keyboard/Mouse A standard PS/2 keyboard and mouse can be attached to the VX5 using the appropriate dongle cable. The dongle cable attaches to the VX5 and provides two PS/2 connectors, one labeled “Keyboard” and one labeled “Mouse”. Please refer to documentation provided with the PS/2 keyboard and mouse for more information on their operation.
Page 52: The Display
Always use the point of the stylus for tapping or making strokes on the display. Never use an actual pen, pencil or sharp object to write on the touch screen. An extra or replacement stylus may be ordered from LXE. See the "Accessories" section for the stylus part number.
Page 53: Pcmcia/Cardbus And Ata Slots
PCMCIA/CardBus and ATA Slots The VX5 has two PCMCIA/CardBus slots and one ATA slot. The PCMCIA slots are stacked on top of each other and located on the right hand side of the opening. The ATA is located on the left hand side of the opening.
Page 54: Pcmcia Pinout
PCMCIA/CardBus and ATA Slots PCMCIA Pinout Signal Signal 12V_RF_POWER -CDI -CE1 -CE2 n.c. or VS1# -IORD -IOWR RDY/-IREQ SLOT_VCC SLOT_VCC SLOT-VPP SLOT_VPP n.c. or VS2# RESET -WAIT -INPACK -REG BVD2/-SPKR BDV1/-STSCHG WP/A_-IOIS16 -CD2 VX5 Reference Guide E-EQ-VX5RG-A...
Page 55: Install Pcmcia Cards
Install the 2.4GHz Type II PCMCIA Radio Caution The LXE Model VX5 Vehicle Mount Computer is specifically for use with LXE Model Numbers 480628-4096, 480824-3300 and LXE 6526 2.4GHz Type II PCMCIA radios. Substitution of other PCMCIA radios will void the FCC, Industry Canada and other international radio certifications for the Model VX5 Vehicle Mount Computer and is strictly prohibited.
Page 56: Figure 2-34 Cisco Antenna Cable Connections
9±1 inch pounds (1.016±.11 N/m). The screws must be fastened to 9 inch pounds each. The screws require a Phillips size 1 driver head. Re-connect the power cord/cable and turn the VX5 on. VX5 Reference Guide E-EQ-VX5RG-A...
Page 57: Ata Slot
ATA Slot The ATA slot is connected to the secondary IDE controller. The slot accepts a PCMCIA card or a compact flash card via a PCMCIA adapter. The VX5 must be powered down before inserting or removing an ATA card.
Page 58 PCMCIA/CardBus and ATA Slots VX5 Reference Guide E-EQ-VX5RG-A...
Page 59: Chapter 3 Power Supply
AC to DC power input for the VX5 is delivered via an optional external power supply. See “External Power Supply”. Vehicle power input for the VX5 is 12V to 80V DC nominal and is accepted without the need to perform any manual operation within the VX5. See “Vehicle 12-80VDC Direct Connection.” An optional uninterruptible power supply (UPS) battery can be used with the vehicle DC power supply.
Page 60: Specifications
+/- 8%, measured at the end of the output Tolerance power cable Output Current 0 Amps min, 1.87 Amps max Safety and Emissions FCC, Part 15, Radio Frequency Devices, Compliance Class B. EN 55022 UL1950 and IEC 950 VX5 Reference Guide E-EQ-VX5RG-A...
Page 61: Environmental Specifications
Per IEC 801-1 CMOS Battery The LXE VX5 has a permanent 190 mAh Lithium battery installed to maintain time, date and CMOS setup information. The lithium battery is not user serviceable and should last five years with normal use before it requires replacement.
Page 62: Vehicle 12-80Vdc Direct Connection
Note: Correct electrical polarity is required for safe and proper installation. Connecting the cable to the VX5 with the polarity reversed will cause the VX5’s fuse to be blown. See the following table for wire color-coding specifics. Wiring color codes for LXE supplied DC input power cabling:...
Page 63: Vx5 Input Power Specifications
SPST 6 Amp 125VDC Fuse The VX5 uses a 100V, 10A time delay (slow blow), high current interrupting rating fuse that is externally accessible and user replaceable. Should it need replacement, replace with same size, rating and type of fuse – Littlefuse 0234010 or Optifuse MSC-10A (5x20mm).
Page 64 Fuse VX5 Reference Guide E-EQ-VX5RG-A...
Page 65: Chapter 4 System Configuration
Chapter 4 System Configuration Introduction Like any personal computer, there are many aspects to the setup and configuration of the VX5. Much of the setup and configuration of the VX5 is dependent upon the optional features (both hardware and software) installed on the computer. Since the VX5 uses the Microsoft Windows Plug and Play operating system, much of the hardware setup is automatic.
Page 66: Windows Management Instrumentation
VX5 BIOS includes support for Windows Management Instrumentation (WMI). The information displayed by selecting Programs|Accessories|System Tools|System Information from the Windows Start Menu identifies the System Manufacturer as “LXE Inc.” and the System Model as “VX5”. Windows Management Instrumentation (WMI) is a component of the Microsoft Windows operating system and is the Microsoft implementation of Web-Based Enterprise Management (WBEM).
Page 67: Accessing The Bios Setup
BIOS Setup Accessing the BIOS Setup When you turn the VX5 on, the unit starts to boot. Watch the bootup sequence and when the following is displayed: Press F2 to Enter Setup Press the [F2] key. Note: The “Press F2 to Enter Setup” message may be disabled in the BIOS. The F2 key still has the same function when the display of the message is disabled.
Page 68: Bios Setup Default Values By Option
CMOS RAM when Exit With Save is selected and the BIOS setup program closes. Changed parameter values take effect when the VX5 reboots upon exiting BIOS Setup. If the VX5 does not automatically reboot upon exit, please reboot the VX5.
Page 69: Main Menu Options
Legacy Diskette (A and B) This option is used to indicate if a floppy disk drive is attached to the VX5. The VX5 does not have a provision for a standard floppy drive; however, a USB floppy may be attached to the USB interface cable.
Page 70: Primary And Secondary Master And Slave Drives
Auto Note: The secondary drive is the enabled ATA slot on the side of the VX5. This drive may be either a PCMCIA or Compact Flash (via PCMCIA adapter) ATA drive. Please see “ATA Secondary Drive” later in this chapter for more details.
Page 71: Advanced Menu Options
CMOS RAM when “Save and Exit” is selected and the BIOS Setup program closes. Changed and saved parameter values take effect after the VX5 is rebooted. Advanced Chipset Control Parameters in this menu have been selected for best performance from your VX5. Changes are not recommended. PCI Configuration Parameters in this menu have been selected for best performance from your VX5.
Page 72: Keyboard Features
Use this option to set NumLock at boot time. When NumLock is On, the keypad is locked in numeric mode. When NumLock is Off the numeric keys are inoperable. Whether NumLock at Boot is Off or On, no LED is illuminated on the VX5. Values:...
Page 73: I/O Device Configuration
Controlled by OS Default: Disabled Note: There is no parallel port (LPT1) on a VX5. Disabling the LPT1 port allows IRQ7 to be used by other devices. USB Port / USB Host Controller These parameters determine if the USB port is active.
Page 74: Security
BIOS Setup Security This menu can be used to set security features as desired. Power BIOS power management is disabled in the VX5. Microsoft Windows handles all power management. Boot Floppy Check This parameter determines if the floppy drive is verified on boot. Disabling provides a faster boot.
Page 75: Boot Device Priority
Bootable Add-In Cards Primary Master ATAPI CD-ROM Drive Network Boot This is the default boot order delivered with your VX5. Valid functions are: • Highlight a device and press <+> to move it up the list of devices. • Highlight a device and press <-> to move it down the list of devices.
Page 76: Exit Menu Options
This option is used to reset the Setup values to the original, default values that were set at the factory, before suppliers or end users made changes. The next time the VX5 is turned on or rebooted, those saved values are in effect. Save this change by selecting “Save and Exit.”...
Page 77: Serial Port Pin 9
Note: Torquing tool is not supplied by LXE. Turn the VX5 off and remove the power supply before opening the access cover located on the top of the VX5. Loosen the three (3) Phillips screws securing the access cover so the cover can be removed.
Page 78: Vmt Keyboard Backlighting
VMT Keyboard Backlighting 95-key Keyboard This LXE keyboard has keys that are backlit with LEDs. The backlight is manually controlled using the “backlight” key in the upper right hand corner of the keyboard. Pressing the backlight key cycles the backlight through the levels of backlight intensity: •...
Page 79: Microsoft Windows License Agreement (First Boot)
If you ordered multiple VX5’s, a separate key code decal is included for each VX5. Each key code is to be used on only one VX5. Be sure to store the key codes in a safe place. Pressing “Next” finishes the licensing/registration process.
Page 80: Drive C Directory Structure
• RFTerm software. Note: If your VX5 was ordered with the no OS option, please refer to “VX5 with No OS”, later in this chapter. The software installed on the VX5 is summarized below. Note: Due to the complex directory structure and System Registry under Microsoft Windows, software should not be removed manually.
Page 81 Windows guides. Radio Software If a radio is ordered with a VX5, the VX5 is delivered with the radio software installed. Because the VX5 is uses a Microsoft Windows operating system, the radio installation includes Windows device drivers.
Page 82: Microsoft Windows Configuration
After the system files are processed, Microsoft Windows begins to load. Windows maintains a System Registry and INI files. Standard Windows configuration options apply to the VX5. Configuration options are located in either the System Tray or the Control Panel: •...
Page 83: Touchscreen
The calibration utility displays a red cross on the screen. Touch the center of the cross with the stylus and hold for a few seconds. Release and repeat with the next cross. After all twelve locations have been touched, either press <Enter> or click the Calibration button. E-EQ-VX5RG-A VX5 Reference Guide...
Page 84: Figure 4-3 Touchscreen Calibration
Touchscreen Figure 4-3 Touchscreen Calibration To save the new calibration settings, click on the Save & Exit button or press <Enter>. To discard the new calibration settings, click Cancel & Exit or press <Esc>. VX5 Reference Guide E-EQ-VX5RG-A...
Page 85: Configuring Right Click On The Touchscreen
Devices there is a listing for Fujitsu Touch Panel (USB). Right click on this listing and select Disable from the menu. To enable the touchscreen, follow the same process, selecting Enable from the right click menu. E-EQ-VX5RG-A VX5 Reference Guide...
Page 86: Network Configuration
Please refer to Chapter 5, “RF Network Configuration” for details on configuring the 2.4 GHz wireless radio cards. Ethernet Connector When the VX5 is networked using the Ethernet connector, the VX5’s networking options are set via the Microsoft Windows Control Panel. The same networking configuration options are available as in a standard PC.
Page 87: Vx5 Delivered With No Hard Drive
(0.9±.11 N/m). The VX5 accepts 2.5” IDE flash or rotating hard drives. 5. Insert the hard drive into the VX5. Slide the assembly into the opening from which the empty bracket was removed. Do not slide it all the way in.
Page 88: Vx5 Delivered With No Os
Additionally, a Microsoft Windows image can be created on a hard drive before it is installed in the VX5. See “VX5 Delivered with No Hard Drive” earlier in this chapter for information on installing a hard drive in the VX5.
Page 89 8. Once the image has been copied, power the VX5 down and remove the secondary drive. 9. Restart the VX5 and edit the BIOS to return the Primary IDE to the top of the boot order. 10. Save the change and reboot the VX5.
Page 90: Microsoft Windows Xp
VX5 Delivered with No OS Microsoft Windows XP To use the Norton Ghost utility to install an OS, there must be a blank drive connected to the Primary IDE and a Compact Flash or ATA drive with a ghost image connected to the Secondary IDE.
Page 91 “Out of box experience” process detailed earlier in this chapter. Please refer to “Microsoft Windows License Agreement” for more details. 11. Restart the VX5 and edit the BIOS to return the Primary IDE to the top of the list (to boot into Microsoft Windows).
Page 92: Installing Microsoft Windows Over A Network
This section details installing the operating system over the network. This procedure assumes the VX5 has a formatted blank hard drive installed as the Primary IDE drive. You will also need software to enable the PCMCIA slot in which the Ethernet card will reside. For this example, that software will be Enabler that is delivered with the Socket LP-E Ethernet card.
Page 93 VX5 Delivered with No OS 11. After connecting to the network, perform all necessary installations. 12. Restart the VX5 and edit the BIOS to return the primary IDE to the top of the boot order. 13. Save the change and reboot the VX5.
Page 94 VX5 Delivered with No OS Sample Files for Installation Procedure Note: The example files shown below are examples only. Your files may differ depending on the Ethernet card used. NET.CONFIG Link Driver NE2000 Port 340 Int 7 ; Remove the semi-colon in front of the frame type you will use.
Page 95: Using The Ethernet Port
8. When the message is displayed, press F12 to connect to the RIS server. 9. When the file transfer is complete, reboot the VX5 and enter the BIOS by pressing F2. 10. Set “Onboard LAN RPL ROM” to disabled. Return primary IDE to the top of the boot order list.
Page 96: Installing Microsoft Windows From A Cd
VX5 Delivered with No OS Installing Microsoft Windows From a CD This section details installing the Microsoft Windows XP operating system from a CD-ROM. This procedure assumes the VX5 has a formatted blank hard drive installed as the Primary IDE drive. Hardware Required •...
Page 97: The Vx5 Drivers Cd-Rom
\Win2K – This directory contains the radio driver and radio firmware for the VX5 with a Cisco radio and Microsoft Windows 2000 operating system. Click on the IWSetup.exe icon and follow the on screen direction for the driver.
Page 98 \Win_2K Contains drivers for use with the Microsoft Windows 2000 operating system: \TouchScreen – Provides the touchscreen driver used on the VX5. The drivers are loaded by running FTSETUP.EXE. \Display – This file provides an update to the display driver.
Page 99: Chapter 5 Rf Network Configuration
The VX5 radios rely on Microsoft Windows network configuration via the Windows Control Panel and configuration software that depends on the type of radio installed in the VX5. The VX5 has all necessary radio software and drivers installed before it is shipped. The radio software includes a configuration utility and a status monitor or diagnosis utility.
Page 100: Cisco Radio
To access the configuration utility, select Programs|Cisco Aironet|Aironet Client Utility (ACU) from the Microsoft Windows Start menu. Figure 5-1 Cisco Aironet Client Utility If profiles have already been created, a profile can be selected by clicking on the Select Profile icon. VX5 Reference Guide E-EQ-VX5RG-A...
Page 101: Figure 5-2 Cisco Profile Selection Screen
Highlight an available profile name and click <<Add to add it to the auto selection list. To remove a profile from automatic selection, highlight the profile name and click Remove>>. Figure 5-3 Cisco Profile Selection Management Screen More details on the Profile Manager are available in Cisco’s online help. E-EQ-VX5RG-A VX5 Reference Guide...
Page 102: Figure 5-4 Cisco Profile Manager Screen
You can use the Import/Export buttons to backup profiles or transfer profiles between computers: • Import a profile from a selected drive/directory, such as a floppy. • Export a profile to a selected drive/directory, such as a floppy. VX5 Reference Guide E-EQ-VX5RG-A...
Page 103: Profile Properties Screens
Network type – The default is Infrastructure. Infrastructure mode is used to connect to a wired network, such as an Ethernet, via access points. Ad hoc mode is used to connect two or more computers in a small temporary network. E-EQ-VX5RG-A VX5 Reference Guide...
Page 104: Figure 5-6 Cisco Properties - Rf Network
Access Point and switch to that Access Point. The default is selected. The time period of association before scanning and the signal strength can be configured. LXE recommends 10 seconds for the association time before scanning and 40% for the signal strength.
Page 105: Figure 5-7 Cisco Properties - Advanced (Infrastructure)
RTS packet. Smaller packets use more bandwidth, but allow for faster recovery from interference or data collisions. The default is 2312. • RTS Retries – The number of times the radio re-sends the RTS packet if a CTS is not received. The default is 16. E-EQ-VX5RG-A VX5 Reference Guide...
Page 106: Figure 5-8 Cisco Properties - Advanced (Ad Hoc)
• Beacon Period – Specifies the duration between beacons, which are used to help clients find each other in Ad Hoc mode. VX5 Reference Guide E-EQ-VX5RG-A...
Page 107: Encryption
Select “None” in the top two boxes for no security. • Select “None” and check “Static WEP” to use static WEP. Click the Static WEP Keys… button to configure the keys. • Select “LEAP” and click on Configure LEAP… to use LEAP. E-EQ-VX5RG-A VX5 Reference Guide...
Page 108: Static Wep
Click on “Transmit Key” to the left of the key used to transmit packets. Only one WEP key can be selected as the transmit key. • When a WEP Key has been set, the Already Set box is checked and the WEP key is not displayed on screen. VX5 Reference Guide E-EQ-VX5RG-A...
Page 109: Leap
• LEAP Authentication Timeout Value – The amount of time (in seconds) before a LEAP Authentication is considered failed. An error message is then displayed. The range is 10 to 300 seconds. The default is 90. E-EQ-VX5RG-A VX5 Reference Guide...
Page 110: Diagnostics
Status – List values for radio parameters and displays information about the current Link Quality. • Link Test – Tests the performance of the radio with an Access Point (specified by IP Address). • Site Survey – Monitors the signal strength, beacons received, link speed and link quality. VX5 Reference Guide E-EQ-VX5RG-A...
Page 111: Updating Firmware
To automatically load new firmware when a new radio driver is installed, click on the Preferences icon on the main Cisco screen. Make sure the checkbox for “Automatically load new firmware when NDIS driver is updated” is checked. Figure 5-13 Cisco Preferences E-EQ-VX5RG-A VX5 Reference Guide...
Page 112: Symbol Radio
The Up and Down buttons move the highlighted profile up or down in the list. The order of the profiles (as displayed in the list) corresponds to the order in which the profiles are searched if association with the current profile is lost. VX5 Reference Guide E-EQ-VX5RG-A...
Page 113: Figure 5-15 Symbol Profile – Mode
Use the Country pulldown to select the country of operation. When this is selected, the radio uses the country code information compatible with the country code of the access point. Select worldwide if the radio is used with a non-Symbol (or pre AP- 4131 model Symbol access point). E-EQ-VX5RG-A VX5 Reference Guide...
Page 114: Figure 5-16 Symbol Profile – Ip Configuration
The leftmost position uses the least power, but at the expense of network performance. The rightmost position provides the best network performance, but consumes the most power. VX5 Reference Guide E-EQ-VX5RG-A...
Page 115: Encryption
(there are two five-digit boxes per key) and click the OK button to enable 40-bit encryption. Use the Reset Keys button to clear any entered keys. Figure 5-18 Symbol Profile – 40 bit Encryption E-EQ-VX5RG-A VX5 Reference Guide...
Page 116: Figure 5-19 Symbol Profile – 128 Bit Encryption
If the access point is using a passkey, then the active profile must use one too. The passkey is a plain text representation of the WEP keys, providing an easy way to enter WEP data without remembering the entire WEP key. VX5 Reference Guide E-EQ-VX5RG-A...
Page 117: Diagnostics
Fewer retries indicate a better signal and this condition is represented by a green indicator. If the indicator is red, associating with a different access point may reduce the number of retries and improve the signal. E-EQ-VX5RG-A VX5 Reference Guide...
Page 118: Figure 5-21 Symbol Status – Information
Figure 5-22 Symbol Status – IP Status This screen displays the IP information for the radio. Note: This screen is read only and cannot be changed by the user. To change IP settings, use the configuration screen covered earlier in this chapter. VX5 Reference Guide E-EQ-VX5RG-A...
Page 119: Figure 5-23 Symbol Status – Ping Test
When this option is selected, an M appears above the icon. Selecting “Set Roaming” allows the radio to associate with any access point with a better signal. Note: These setting are temporary. They are not saved to the registry. E-EQ-VX5RG-A VX5 Reference Guide...
Page 120: Updating Firmware
The signal strength of the WLAN is indicated from one bar (weakest) to five bars (strongest). Encrypted networks are indicated with a “key” icon. Updating Firmware Symbol radio firmware is automatically updated when the Dario driver is updated. VX5 Reference Guide E-EQ-VX5RG-A...
Page 121: Troubleshooting
Connection icon in the Windows Control panel. Right click on the wireless network icon and select Properties. Figure 5-26 Windows Wireless Network Properties Make sure the “Use Windows to configure my wireless network setting” checkbox IS NOT checked. E-EQ-VX5RG-A VX5 Reference Guide...
Page 122 Troubleshooting VX5 Reference Guide E-EQ-VX5RG-A...
Page 123: Chapter 6 Troubleshooting
Hardware Problems - (i.e. power source, keyboard, display, hard drive, PCMCIA cards, optional devices, etc.) • Radio Problems • Software Related problems • Memory The following sections provide more detailed troubleshooting information about each of these areas. E-EQ-VX5RG-A VX5 Reference Guide...
Page 124: Startup Problems
This section lists some of the configuration error messages that may appear at system startup and their possible solutions. Note: If you press the power switch and the VX5 remains off, refer to the “Power Source” section of this chapter. Problem...
Page 125: Bypassing Microsoft Windows Startup
Windows with a minimum number of drivers. The Windows Start Up Menu Allows several choices that aid in diagnosing a problem. To access the start-up menu: Turn on the VX5. Press and hold the <F5> key. When the Windows Start Up Menu appears, select the desired choice: Normal Logged (\BOOTLOG.TXT)
Page 126: Verifying Boot Order
Startup Problems Verifying Boot Order During bootup, the <F2> key may be pressed to enter BIOS Setup. Turn on the VX5. Press <F2> immediately. The BIOS Setup Main Menu is displayed. Move the highlight to the Boot Menu. Select “Boot Device Priority” by pressing the <Down Arrow> to highlight it.
Page 127: Hardware Problems
This section lists possible solutions to some common problems with hardware. Power Source The VX5 receives power from either an AC-DC adapter or a vehicle battery. Power source problems are usually interrelated. For example, a malfunctioning AC-DC adapter or vehicle battery will not power the computer.
Page 128: Keyboard
> key on the keyboard Press the <SP> key or an arrow key to release the <2 > remains active and does not toggle state. If the problem continues, contact LXE Customer on and off when another key is Support department. pressed.
Page 129: Pcmcia Cards
Microsoft Windows controls memory management. If you experience a problem with memory management, please refer to Windows help files or a commercially available Windows guide. If a particular program causes the memory error, refer to the documentation for that program. E-EQ-VX5RG-A VX5 Reference Guide...
Page 130: Irq Assignments
Hardware Problems IRQ Assignments The VX5 has 16 IRQs, numbered 0 through 15, many of which are already assigned as follows: IRQs Device(s) Windows 2000 Device(s) Windows XP IRQ0 Timer Output Timer Output IRQ1 Keyboard Keyboard IRQ2 Programmable Interrupt Controller...
Page 131: Optional Devices
Optional Devices This section provides information on solving problems related to optional devices. Note: Make sure the VX5 is powered on before you turn on any powered optional devices. To help determine which device is causing the problem: • Check that all connecting cables are correctly and firmly attached. Loose cables can cause erroneous or intermittent signals.
Page 132: Radio And Network Problems
• Configuration of radio card/network All VX5 radios include utilities to aid in diagnosing transmission problems. Please refer to Chapter 5, “RF Network Configuration” for details on using the diagnostic features. Chapter 5 also includes a “Troubleshooting” section. Please review the information there if experiencing troubles with the 2.4 GHz network.
Page 133: Software Related Problems
Be sure you have enough memory and hard disk space to meet the software requirements. Determining Software Revision The Gnumber of the LXE loaded Windows image on the VX5 can be read in the system registry Use the Microsoft Registry Editor (REGEDIT.EXE) and browse to the following key: HKEY_LOCAL_MACHINE\SOFTWARE\LXE\VX5 The value for is the Gnumber of the LXE loaded Windows image.
Page 134: System Testing
Video memory and controller • Keyboard controller POST Error Messages The following table lists the POST error messages for the VX5. If problems persist, contact LXE’s Customer Support. 0200 Failure Fixed Disk Possible Cause The fixed disk is not properly identified in BIOS.
Page 135 Action Contact LXE’s Customer Support for CMOS battery replacement. 0251 System CMOS checksum bad – Default Configuration Used Action CMOS has been corrupted. The VX5 is loading with default settings. Run Setup to modify values. 0260 System timer error Action Contact LXE’s Customer Support.
Page 136 02B2/02B3 Incorrect Drive A/B type – Run Setup Action Run the BIOS Setup utility. 02D0 System cache error – Cache disabled Action Contact LXE's Customer Support. 02F0 CPU ID: Possible Cause Contact LXE’s Customer Support. 02F4 EISA CMOS not writeable Possible Cause Cannot write BIOS to CMOS.
Page 137: Post Informational Messages
Server BIOS2 test error: Fail-safe timer takes too long. Action Contact LXE’s Customer Support. POST Informational Messages The following table lists the POST informational messages for the VX5. Message Meaning nnn kB System RAM Passed The amount of base memory that tested successfully.
Page 138: If You Need Further Assistance
Before You Call Since some problems you experience may be related to the operating system or software, it is important to investigate other sources of assistance first. Try the following before contacting LXE. • Review the troubleshooting information in commercially available Microsoft Windows documentation.
Page 139: Appendixa Key Maps
Ctrl Enter Figure A-1 95-Key VMT QWERTY Keyboard The key map table that follows lists the commands used for the VX5. Note that since the VX5 uses a Microsoft Windows operating system, no DOS Terminal Emulation keypress sequences are provided.
Page 140: 60-Key Standard Keypad
Home PgDn ´ Figure A-2 60-Key VMT QWERTY Keyboard The key map table that follows lists the commands used when running LXE's VX5. The “VX5 User’s Guide” contains connection and vehicle mounting instructions for the VMT keyboard. VX5 Reference Guide...
Page 141: Key Map 101-Key Equivalencies
The Brightness Adjustment keys have no function. Brightness is adjusted via the buttons on the VX5 control panel. The Contrast Adjustment keys have no function because the VX5 is equipped with a TFT display that has no provision for these adjustments.
Page 142 Left Arrow Insert Ins/BkSp Delete (numeric) Home Left Arrow Right Arrow Page Up Up Arrow Page Down Down Arrow Right Shift Right Alt Right Ctrl ScrollLock NumLock Press <Ctrl> then <2 > then <F2> to produce Ctrl-Break. VX5 Reference Guide E-EQ-VX5RG-A...
Page 143 Key Map 101-Key Equivalencies Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock E-EQ-VX5RG-A VX5 Reference Guide...
Page 144 2 (numeric) 3 (numeric) 4 (numeric) 5 (numeric) 6 (numeric) 7 (numeric) 8 (numeric) 9 (numeric) 0 (numeric) DOT (numeric) < > / (numeric) / (alpha) - (numeric) - (alpha) + (numeric) + (alpha) * (numeric) VX5 Reference Guide E-EQ-VX5RG-A...
Page 145 Key Map 101-Key Equivalencies Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock * (alpha) : (colon) ; (semicolon) _ (underscore) , (comma) ‘ (apostrophe) ~ (tilde) “ & E-EQ-VX5RG-A VX5 Reference Guide...
Page 146 Key Map 101-Key Equivalencies VX5 Reference Guide E-EQ-VX5RG-A...
Page 147: Appendixb Technical Specifications
Sealed power switch Beeper Minimum loudness greater than 95dBm at 10 cm in front of unit Dimensions Length: 12.2 in (30.98 cm) Width: 9.5 in (24.13 cm) Depth: 4.3 in (10.92 cm) Battery for CMOS Internal lithium Battery E-EQ-VX5RG-A VX5 Reference Guide...
Page 148: Environmental Specifications
External AC Adapter 120-240VAC to 12VDC Power Supply Environmental Specifications The VX5 will withstand the following environmental characteristics and has been tested in accordance with applicable sections of MIL-STD-810E. Feature Specification Altitude Operational to 10,000 ft. (3048 meters) Operating Temperature Standard w/rotating drives: 5 °C to +45 °C (41 °F to +113 °F)
Page 149: Display Specifications
-40 °C to +70 °C (-40 °F to +158 °F) Water, Sand and Dust IP66 per IEC60529 Humidity 10-90% Non-condensing at 40°C (104°F) Vibration Bounce loose cargo for 0.5 hour duration. Common carrier transportation, transit face. 15 kV E-EQ-VX5RG-A VX5 Reference Guide...
Page 150: Radio Specifications
11 Mbps RF Power Level: 100 mW Channels 11 US, 13 Europe, 4 France, 1 Japan Operating Temperature see VX5 Environmental Specs Storage Temperature see VX5 Environmental Specs Connectivity: Novell, TCP/IP, Ethernet, ODI PCMCIA Symbol 11Mb 2.4GHz Type II Bus Interface: PCMCIA 2.0, Type II slot...
Page 151: Index
COM 2 ............18, 20 Verifying............116 COM 2 - 02F8h..........14 Bypass Configuration Files ......... 115 Component Locations.......... 5, 6 Condition, Restore..........66 Configuration Device drivers ........... 87 CAPS LOCK Mode LED Indicator....... 37 Ethernet............. 76 E-EQ-VX5RG-E VX5 Reference Guide...
Page 152 Set System Time and Date ......116 Configuration ............ 76 Toggle 2nd key on and off ........ 38 Exit Toggle Caps-Lock on and off ......38 w/o Save............66 Type <!> ............38 with Save............66 Exit and Save............66 Exit Menu VX5 Reference Guide E-EQ-VX5RG-A...
Page 153 NET.CFG parameter ........111 LPT ports Install setup ..............63 Equipment Needed..........45 LXE Customer Support ........128 Fuse..............53 Type II 2.4GHz Radio Card......45, 47 Installation Device drivers ........... 87 Internal Flash Array (IFA) and Bootup ....57 Manuals ..............
Page 154 Power Source Software Troubleshooting ..........117 Troubleshooting ..........123 Power Status LED ..........16 Software Loaded by LXE........70 Power Supply Speaker Jack, Location........5, 6 CMOS Battery ..........15 Speaker Volume Control Keys ......39 CMOS NiCd Battery......... 51 Speaker/Beeper, Location........
Page 155 Enabling in BIOS..........63 Power Management .......... 15 Using the Keypad Product Key ..........1, 69 BIOS ..............57 Software Key ..........1, 69 Windows Management Instrumentation (WMI) ... 56 Wire Color Cable Wiring............. 52 WMI Support............56 E-EQ-VX5RG-E VX5 Reference Guide...
Page 156 Index VX5 Reference Guide E-EQ-VX5RG-A...

LXE VX5 Reference Manual

Chapter 1 Introduction

Chapter 2 Physical Description and Layout

Chapter 3 Power Supply

Chapter 4 System Configuration

Chapter 5 RF Network Configuration

Chapter 6 Troubleshooting

Appendix A Key Maps

Quick Links

Troubleshooting

Related Manuals for LXE VX5

Summary of Contents for LXE VX5

Table of Contents
