24-Port + 2 Slide-in Slots SNMP Switch
1.
Introduction
Welcome to the World of Switching-Network.
In modern society, communication and information sharing are
fundamental to our lifestyle. Computer networks are one of the
fastest means of communication.
As your company grows, your network demands will increase. ...
LevelOne
GSW-2490TXM
1

Advertisement

Table of Contents
loading

Related Manuals for LevelOne GSW-2490TXM

Summary of Contents for LevelOne GSW-2490TXM

  • Page 1 LevelOne GSW-2490TXM 24-Port + 2 Slide-in Slots SNMP Switch Introduction Welcome to the World of Switching-Network. In modern society, communication and information sharing are fundamental to our lifestyle. Computer networks are one of the fastest means of communication. As your company grows, your network demands will increase. …...
  • Page 2 Ethernet, Fast Ethernet, Gigabit Ethernet connectivity over twisted pair and fiber optic cabling. Two expansion slots on the front panel of the LevelOne GSW-2490TXM SNMP Switches further add to the flexibility of the systems. Figure 1-1. The...

  • Page 3: Package Contents

    Port Priority - 802.1p & TOS (Type of Service ) supported TFTP support for firmware on network upgrade Port Mirror supported Package Contents Unpack the carton of the LevelOne GSW-2490TXM SNMP Switch and verify them against the checklist below. LevelOne GSW-2490TXM SNMP Switch Rubber Feet...

  • Page 4: Management Methods

    Console Management is done through the RS-232 Console Port. Managing the LevelOne GSW-2490TXM SNMP Switch in this method requires a direct connection between PC and the LevelOne GSW-2490TXM SNMP Switch. While Telnet management is done over the network. Once the LevelOne GSW-2490TXM SNMP Switch is on the network, you can use Telnet to Log in and change the configuration.

  • Page 5: Hardware Description

    RJ-45 Ports LED Indicators Console Port Expansion Slots for Optional Figure 2-1. The Front Panel of LevelOne GSW-2490TXM SNMP Switch Module 10/100Base-TX RJ-45 ports ( Auto MDI/MDIX ): 24x 10/100Mbps auto-sensing port for 10Base-T or 100Base-TX devices connection. Note: [ MDI/MDIX means that you can connect...

  • Page 6: Led Indicators

    LED Indicators Figure 2-2 The LED Indicators All LED indicators are located on the front panel of the LevelOne GSW-2490TXM SNMP Switch. They provide a real-time indication of system and operational status. The following table gives descriptions of the LED status and their meanings.

  • Page 7: Rear Panel

    Panel of the LevelOne GSW-2490TXM SNMP Switch. ( The Ventilation fan is located on the side of the Switch ). The Switch will work with AC in the range 100-240V AC, 50-60Hz. Figure 2-3. The Rear Panel of the LevelOne GSW-2490TXM SNMP Switch Power On...

  • Page 8: Connecting To The Network

    LEDs will soon flash red. When the Switch passes the self-test within 15 seconds, the Link /ACT LED turns on. Note : If the Switch fails the self-test, the Diag LED will blink. Connecting to the Network This section provides the installation procedure and instructions for assigning IP address.

  • Page 9: Mounting The Switch

    Air flow around the Switch and through its vents on the rear cannot be restricted. Mounting the Switch The LevelOne GSW-2490TXM SNMP Switch is suitable for use in an office environment where it can be rack-mounted in standard EIA 19-inch racks or standalone.

  • Page 10: Rack-Mounted Installation

    Caution: Do not place objects on top of the Switch. Rack-mounted Installation The LevelOne GSW-2490TXM SNMP Switch come with a rack- mounted kid and can be mounted in an EIA standard size, 19-inch Rack. The Switch can be placed in a wiring closet with other equipment.

  • Page 11: Connecting To The Switch

    The Console configuration ( out of band ) allow you to set your Switch to enable a user at a remote console terminal to communicate with the LevelOne GSW-2490TXM SNMP Switch as if the console terminal were directly connected to it.

  • Page 12: Login In The Console Interface

    Figure 3-4. Connecting the LevelOne GSW-2490TXM SNMP Switch to a terminal via RS-232 cable Login in the Console Interface When the connection between Switch and PC is finished, turn on the PC and run a terminal emulation program or Hyper Terminal...
  • Page 13 After you have finished parameter settings, click “OK“. When the screen shows above, press “admin“ Key for the User name, then the Main Menu of console management appears. Main Menu Figure 3-6. The screen of Main Menu After login you will see the main menu screen as illustrated in the picture.
  • Page 14 Figure 3-7. The System Information Menu The system information screen displays information such as hardware, software versions, and system up time. You can also enter specific information about you and your organization here. 2. Management Setup Figure 3-8. The Management Setup Menu The management setup menu contains 6 submenus and are discussed in the section in the following pages.
  • Page 15 Figure 3-9. The Network Configuration Men This screen is provided to change the IP setting of your switch according to your network configuration. After changing the setting you need to save it so that whatever changes you made can take effect.
  • Page 16 Figure3-11. The SNMP Community Menu In the SNMP Community Menu, you can create different communities and customize their access right. Use <TAB> key to move the highlight bar and select desired community to modify or add a new community (use space bar to toggle the access right and status) 2.4.
  • Page 17 Figure 3-13. The Management Capability setup Menu This is where you can enable / disable Web-Based management capability which in turn allow or disallow the access to management function through the use of a web browser such as Microsoft IE. 2.6.
  • Page 18 3. Device Control Menu Figure 3-15. The Device Control menu Device control menu contains 15 submenus where you get to maneuver most of the functions and features. 3.1. Switch Device Configuration Figure 3-16. The Switch Device Configuration menu Use <Space Bar> key to toggle the Enable / Disable field and type in appropriate value in the Time and Priority field.
  • Page 19 choice (according to IEEE 802.1p) to the four priority levels provided. •There are three different mode of VLAN supported in this system – 802.1Q, Port Base VLAN, MTU/MDU. The choice you made here will ultimately decide the VLAN mode and function for entire system (the configuration of the other two VLAN mode will have no effect to the system behavior).
  • Page 20 Figure 3-18. The Permanent Address Configuration menu There are 128 static unicast groups and 32 multicast supported by the system. Two submenus contains in this section. 3.3.1. Static Unicast Address Configuration You can creat, modify, or delete Static Unicast Address by selecting entries from the following screen.
  • Page 21 Figure 3-19. The Port Statistics menu You can view the statistics information display in this screen regarding a certain port by entering the port number in the port id field. You can also refresh or reset the counter as you wish. 3.5.
  • Page 22 can choose to leave a menu screen without applying any changes you had made at any time by pressing <Esc> key and then confirm with <Enter> key. 3.6. Spanning Tree Protocol Port Configuration Figure 3-21. The Spanning Tree Protocol port Configuration menu In this screen you can assign spanning priority and path cost to any port(s).
  • Page 23 One advantage of the Port-Based VLAN is its simplicity and easy to configure, however, limited security is its drawback – anyone can plug into the port and gain access to the VLAN. Select the VLAN entry to create, modifies, or deletes the VLAN group.
  • Page 24 Figure 3-23. The Port Based VLAN Configuration menu ( ) – Port(s) is not set as static (fixed) member of the VLAN but it can become a member through Dynamic VLAN Registration. (F) – Port(s) is set as static (fixed) member of the VLAN and can be registered as a dynamic VLAN member as well.
  • Page 25 Figure 3-24. The Dynamic VLAN Table menu This screen displays the VLAN mapping for port(s) that join the VLAN(s) through Dynamic VLAN Registration. 3.8.3. VLAN Untagged Configuration Figure 3-25. The Port Untag Configuration menu All ports are set by default as <Untagged> in this switch system, to change port(s) to <Tagged>...
  • Page 26 Figure 3-26. The GARP Configuration menu GARP (Generic Attribute Registration Protocol) defines the architecture, rules of operation, state machines and variables for the registration and de-registration of attribute values. It allows dynamic filter entries for VLAN membership to be distributed among the Forwarding Databases of VLAN-aware switches.
  • Page 27 port then port 1 ~ 25 will be mapped to port 26 - the uplink port, otherwise, port 1 ~ 12 and port 13 ~ 24 will be mapped to uplink port 25 and port 26 accordingly. 3.10. IGMP Snooping Table Figure 3-28.
  • Page 28 Figure 3-29. The Trunk Configuration Menu Multiple links between switches can be grouped (trunk) to work as one virtual, aggregate link. You can create 4 trunks at a time; each trunk can hold up to 8 ports - only ports of the same speed can belong to a single trunk.
  • Page 29 User Authentication Figure 3-31. The User Authentication Menu You can change the password setting as in the user authentication menu. You can also create user and assign different privilege to suit your needs. After selecting an entry to add or modify, type in user name and password, toggle the user privilege with <Space Bar>...
  • Page 30 System Utility 5.1 System Restart Figure 3-32. The System Restart Menu As mention earlier, you need to perform either a <Cold Start> or <Warm Star> to have the changes you made written into the NVRAM so that changes are really saved and keep in effect until you make change to them again.

  • Page 31: Web-Based Management

    Figure 3-34. The Login Timeout Interval You can set up the time you need for the automatic log-out in anytime. 5.4 System Download Figure 3-35. The System Download Menu Use TFTP download the code you need, and two code as Boot code and System Software code for upgrading.

  • Page 32: About Web-Based Management

    This section introduces the configuration and functions of the Web- Based management. About Web-based Management Inside the CPU board of the switch exists an embedded HTML web site residing in flash memory. It offers advanced management features and allow users to manage the switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.

  • Page 33: System Information

    System Information 24-Port with 2 Slide-in Slots SNMP Switch Figure 4-2 The System Information Menu You can manage the Switch using third-party’s SNMP ( Simple Network Management Protocol ) agent. Access rights to the SNMP agent are controlled by community strings. To set system name, system location and system contact, you can type the desired text string in the corresponding edit box.
  • Page 34 Click the "Change Password" checkbox Enter the user name in "Username" edit box Enter the same password in "Password" and "Confirm Password" edit box Press the "Apply" button You should reboot system to let your settings take effect if you have changed one of the IP address, subnet mask and default gateway.
  • Page 35 Figure 4-5. The SNMP Community Setup Menu Public Community ( Read-only access right ) means that member of community can view the information but can not make changes to the configuration. Private Community ( Read/Write access right ) allow the member of the community to view and make change to the configuration.
  • Page 36 Management Capability Setup Figure 4-7. The Management Capability Setup Menu This is where you can enable / disable Web-Based management capability which in turn allow or disallow the access to management function through the use of a web browser such as Microsoft IE. Trap Filter Setup Figure 4-8.

  • Page 37: Device Control

    The system can generate a set of SNMP traps upon the occurrence of those events. By checking a filter event, you are turning off the filter and enabling the trap associated with that event. Device Control Switch Configuration Figure 4-9. The Switch Configuration upper Menu 1.
  • Page 38 Switch Port Configuration Figure 4-11. The Port Administration in Switch Port Configuration Menu The Ports (24+2) of the system are divided and displayed in three separated pages. In the port Administration menu, select a port that you can configure the common characteristics such as speed negotiation, flow control, and VLAN ID as well as the following special features provided with the system: •...
  • Page 39 Figure 4-12. The Trunk Group in Switch Port Configuration Menu Port trunking is the ability to group several ports to increase the bandwidth between this switch and another compatible switch. This is an inexpensive way to increase bandwidth. We define port trunking as the ability to group set of ports (up to 4 groups).
  • Page 40 Figure 4-14. The Static Unicast Address in Permanent Address Configuration Menu You can Add, modify, or delete Static Unicast Address by selecting entries from the following screen. Enter the MAC address of a system you wish to set as static unicast address the port associated with the system.
  • Page 41 Figure 4-15. The Static Multicast Address Configuration in Permanent Address Configuration Menu In the Static Multicast Configuration Menu screen, you can add member(s) to the group by checking the port(s). Spanning Tree Protocol Configuration Spanning tree is a link management protocol that provides path redundancy while preventing undesirable loops in the network.
  • Page 42 Figure 4-17. The Spanning Tree Protocol Configuration lower Menu Spanning Tree Protocol Port Configuration Figure 4-18. The Spanning Tree Protocol Port Configuration upper Menu In this upper and lower menu, you can assign spanning priority and path cost to any port(s). A port with higher priority, lower path cost is less likely\to be blocked if Spanning Tree Protocol is detecting network loop.
  • Page 43 Figure 4-19. The Spanning Tree Protocol Port Configuration lower Menu Port Statistics Figure 4-20. The Port Statistics Menu You can view the statistics information display in this screen regarding a certain port by entering the port number in the port id field.
  • Page 44 Figure 4-21. The Static VLAN Configuration Menu (S) – Port(s) is set as static (fixed) member of the VLAN. (D) – Port(s) is set as static (fixed) member of the VLAN and can be registered as a dynamic VLAN member as well. (C) –...
  • Page 45 Figure 4-23. The Untagged Configuration Menu All ports are set by default as Untagged in this switch system, to change port(s) to Tagged just pick the port number you need and select “No” from the Port Map. Figure 4-24. The MTU/MDU Per Port VLAN Table in The VLAN Configuration Menu This screen as above only reflects the setting you made in Switch Device Configuration menu - there is no change can be made here.
  • Page 46 Figure 4-25. The Port Based VLAN Configuration in The VLAN Configuration Menu Select the VLAN entry to create, modifies, or deletes the VLAN group. Choose the port(s) to the VLAN group GARP Configuration Figure 4-26. The GARP Configuration Menu GARP (Generic Attribute Registration Protocol) defines the architecture, rules of operation, state machines and variables for the registration and de-registration of attribute values.

  • Page 47: User Authentication

    Figure 4-27. The IGMP Configuration Menu Multicasting is used to support real-time applications such as video conferencing or streaming audio. IGMP (Internet Group Multicast Protocol) allows you to query for any attached hosts who want to receive a specific multicast service. The switch looks up the IP Multicast Group used for this service and adds any port, which received a similar request to that group.

  • Page 48: System Utility

    You can change the password setting as in the user authentication menu. You can also create user and assign different privilege to suit your needs. After selecting an entry to add or modify, type in user name and password, toggle the user privilege and then update the changes System Utility System Restart...
  • Page 49 All selections in this menu are separate to be setup their own default. Login Timeout Interval Figure 4-31. The Login Timeout Interval Menu You can set up the time you need for the automatic log-out in anytime. System Download Figure 4-31. The System Download Menu Use TFTP download the code you need, and two code as Boot code and System Software code for upgrading.

  • Page 50: Network Configuration

    You can save current settings by click the "Submit" checkbox .You should reboot the system so that your current settings will take effect. Network Configuration This section provides you a few samples of network topology in which LevelOne GSW-2490TXM SNMP Switch ( UTP/MT-RJ/VF- 45, Intelligent ) is used.

  • Page 51: Collapsed Backbone Application

    The Switch provides versatile configuration options for the network. It is ideally suited as a workgroup or segment Switch in a network; it has the flexibility to provide Switched 10Mbps to the desktop or shared hubs, aggregate traffic from workgroup Switches, or provide dedicated 100Mbps or 1000Mbps ( Gigabit ) to servers with bandwidth-intensive applications.
  • Page 52 For enterprise networks where large data broadcasts are constantly processed, this Switch is an ideal solution for department users to connect to the corporate backbone. The LevelOne GSW-2490TXM SNMP Switch used as segment Switch can alleviate user contention for bandwidth and eliminate server and network bottlenecks.
  • Page 53 Figure 5-2: Departmental Bridge Application Full-duplex operation only applies to point-to-point access NOTE: (for example, when attaching the Switch to a workstation, server, or another Switch). When connecting to hubs, use a standard cascaded connection set for half-duplex operation. High Performance Switched Workgroup This Switch is also a good solution for connecting two workgroups, supporting the throughput, for example, of 800Mbps.
  • Page 54 implement more expensive administration procedures. The Switch can provide the same bandwidth of FDDI and ATM at much lower costs. In addition, all current adapters and network devices can still be used. The Switching cross-domain connection is better than bridge and router because users can retain LAN structure in which any node can freely communicate with any other node.
  • Page 55 VLAN groups can be modified at any time to add, move or change users without any re-cabling. Figure 5-4: VLAN Workgroup Application Shared Server The Switch compliant to the IEEE802.1Q tagging VLAN standard allows ports to exist in multiple VLANs for shared resources, such as servers, printers, and Switch-to-Switch connections.

  • Page 56: Product Specifications

    VLAN port members of VLAN3. Product Specifications This section provides the specifications of LevelOne GSW- 2490TXM SNMP Switch, and the following table lists them. Standards Compliance IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX and 100BASE-FX IEEE802.3ab 1000BASE-T IEEE802.3z 1000BASE-SX IEEE802.3x Flow Control IEEE802.1p Priority Support IEEE802.3ac Frame Extension for VLAN Tagging...
  • Page 57 MAC Address 8K MAC address with auto learning function Data Buffer 6Mb share memory System Power, per port Link/active, FDX/Col,10/100Mbps Gigabit Module Link/active, FDX/Col Dimension 440mm(W)*225mm(D)*44.5mm(H) Power 100~240 VAC 50/60HZ EMI & Safety FCC Class A, CE, UL...
