LevelOne ProCon GSW-2496 Specifications

8-Port TP + 16-Port SFP Gigabit L2 SNMP Switch
Product Overview
The GSW-2496 is a feature rich 24-port Gigabit L2 Managed Switch is a high
performance platform network switch designed for mission critical network
environments to accommodate high bandwidth applications and is suitable for
both metro-LAN and office applications. It also provides flexible network
connectivity for both copper and fiber optic connections, is virtual stackable with
up to 16 network switches and features comprehensive and powerful
management functions.
Flexible Network Connectivity
The 24-ports of the GSW-2496 are made up of 8 10/100/1000Mbps Auto-
negotiation Gigabit Ethernet TP ports and 16 1000Mbps SFP fiber ports, combining
copper and fiber optic connectivity within one device. The 16 SFP fiber ports
allow for optional SFP modules with a variety of network connection choices.
Optional modules are used for high-speed network connection expansion.
Network Management
The GSW-2496 SNMP network switch can be managed through a built-in RS-232
serial port or through an Ethernet port using CLI or the Web-based user interface.
Through the SNMP agent management, the network administrator can configure
and control each port's activity as well as manage the network switch to
accommodate high bandwidth applications.
Network Functions
The GSW-2496 network switch also features a comprehensive range of network
functions such as QoS (Quality of Service), Spanning Tree, VLAN, Port Trunking,
Bandwidth Control, Port Security, SNMP/RMON, IGMP Snooping capability and
Illegal Access Report via its intelligent software.
QoS: Supports IEEE 802.1P Quality of Service with two priority queue and packet
transmission schedules.
Spanning Tree: Supports IEEE 802.1D, IEEE 802.1w (RSTP: Rapid Spanning Tree
Protocol) standards.
VLAN: Supports Q-in-Q VLAN, Port-based VLAN and IEEE802.1Q Tag VLAN. Support
256 active VLANs and VLAN ID 1~4094.
Port Trunking: Supports static port trunking and port trunking with IEEE 802.3ad
LACP.
Bandwidth Control: Supports ingress and egress per port bandwidth control.
Port Security: Supports IEEE802.1X port-based network access control, allowed,
denied forwarding and port security with MAC address.
SNMP/RMON: SNMP agent and RMON MIB. In the device, SNMP agent is client
software which operates over SNMP protocol to receive commands from the
SNMP manager and echo corresponding data.
This network switch supports RMON (Remote Network Monitoring) MIB-2 (RFC
1213), Bridge MIB (RFC 1493), RMON MIB (RFC 1757)-statistics Group 1,2,3,9, VLAN
MIB (802.1Q, RFC2674) and Ethernet MIB (RFC 1643).
IGMP Snooping: Support IGMP version 2 (RFC 2236)
ProCon L2 SNMP Network Switch
GSW-2496
one world_one brand_one level_
GSW-2496
Key Features
• High performance L2 SNMP
network switch for mission-
critical network environments
• Combines copper and fiber
network for flexible network
connectivity within
device
• Virtual stacking
with up to 16 devices
• Features comprehensive and
powerful
management functions
• Supports DHCP Broadcasting
Suppression
• Supports port mirroring, rapid
spanning tree (802.1w RSTP)
and 802.1X port security on a
VLAN
• Supports IEEE802.1Q
and programmable
802.1P QoS
• Provides Full-duplex
control (IEEE802.3x) and half-
duplex backpressure
• Network modules are hot
swappable
• Features a built-in
based as well
management user-interface
one
capability
network
VLAN
IEEE
flow
Web-
as CLI
