- Page 2 UltraMatrix Single unit Installation The following installation procedure features the 4XE model. Installation for other models (2, 4, or 8 computers) follow the same basic procedure. It is recommended that power to all monitors, computers, and UltraMatrix be off until all connections have been made. The below illustration shows the basic cable connections for UltraMatrix and the installation steps to properly connect the cables, computers, and KVM stations to UltraMatrix.
-
Page 3: Operating Instructions
Operating Instructions With all cabling in place and power applied to all equipment, the video monitor connected to KVM port #1 should display the video from computer #1 (default). Switching to other computers is accomplished by: 1. Keyboard commands (press and release left Ctrl key + CPU #) (LCtrl + 3 switches to port #3) 2. - Page 4 Turns scan “Off” Table 1 - Keyboard Commands Copyright Rose Electronics 2007. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transcribed in any form or any means, electronic or mechanical, including photocopying and recording, without the prior written permission of Rose Electronics.
