Operating Controls
1 LCD Display - displays operating parameters and
functions.
2 MENU Button - used to access set up menu and to
change parameter settings.
3 MODE Button - used to save settings and exit to
normal operation.
4 SET Button - used to save settings changes and
move to next parameter.
5 CODE Button - used to store transmitter code.
© February 2009 Smart Openers Pty Ltd
2
1
4
6
6 PB (Push Button) - used to operate the door.
7 Manual Release Cord - used to engage/disengage
8 Input Terminal Block - used for connecting photo
-4-
3
5
(open/stop/close)
the door for automatic/
manual operation.
electric safety beam or
external push button trigger.
+24V
PE
8
GND
PB
GND
7
