  • Page 1 Smart Lifter Sectional Door Opener smart openers WARNING: IT IS VITAL FOR THE SAFETY OF ALL PERSONS INSTALLING AND USING THIS OPENER TO FOLLOW THE INSTALLATION INSTRUCTIONS AND SAFETY WARNINGS. FAILURE TO COMPLY MAY RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY INSTALLATION MANUAL DAMAGE AND FAILURE OF THE OPENER SYSTEM.

  • Page 2: Table Of Contents

    INFORMATION FOR THE USER WARRANTY To the extent that they may be lawfully excluded, Smart Openers Pty Ltd hereby expressly excludes all conditions and warranties, statutory or otherwise, which may be implied by law as conditions or warranties of purchase of a Smart Openers Pty Ltd Garage Door Opener. Smart Openers Pty Ltd hereby further...

  • Page 3: Contents

    Rail Extrusion 1 Set Important Safety Warnings The Smart Lifter garage door opener described in this essential that the installer also installs the equipment in manual is designed for the automation of residential accordance with all local and Australian regulations.

  • Page 4: Operating Controls

    Operating Controls 1 (UP button) Limit mode set. smart openers 2 (DOWN button) Reversing sensitivity set 3 (SET Button) Confirm set 4 (CODE Button) Transmitter code set Circuit Board Connectors 5 Coupling for connecting the backup battery. 6 Coupling for connecting the motor. 7 Coupling for the power transformer.

  • Page 5: Installation Instructions

    Remember the unit has mains voltage running through it (electrocution hazard, fire hazard). 1.10) When installing the Smart Lifter opener, strictly follow all the instructions given in the instruction 1.4) Take care with the control unit; parts may be manual.

  • Page 6: Shortening The Track

    Tilting Overhead Door 5) Install a 240V, adequately protected 3-pin socket near H max. 2600mm where the Smart Lifter opener is going to be installed Fig. 2 CHAIN SHUTTLE ASSEMBLY For ease of installation the Smart Lifter is delivered with the chain and chain index already assembled in the track.
  • Page 7 Do not over tighten the chain, just enough Fig. 6 to remove the slack. 2.5) Fix the Smart Lifter opener to the lintel or to the ceiling with the correct fixing (Fig. 5), maintaining a minimum gap of 30mm from the top panel’s maximum height (Fig.

  • Page 8: Installing Shuttle Stop

    Australian standards. transmitter. = Push Button terminal Whoever installs and uses the Smart Lifter sectional door 2) GND & PE = Photo Beam terminal. opener will be held responsible for any damage caused.

  • Page 9: Setting Of Open And Close Positions

    Setting Open and Close Function Modes The Smart Lifter has two selectable functioning modes: Positions PHOTO BEAM and AUTO-CLOSE. Photo Beam mode should only be actived when a photo beam is connected. smart smart The opener will not function correctly if a photo beam is...

  • Page 10: Photo Beams

    It is important for the installer to show their clients correct operational use of the Smart Lifter including the use of the manual disengagement cord. Inform the owner about the need for regular and accurate maintenance, especially regarding a regular check of the safety and reversing devices.

  • Page 11: Manual Disengagement

    Manual Disengagement The Smart Lifter is equipped with a manual release cord to disengage shuttle and move door by hand while holding the handle down (Fig. 9). To operate pull on the handle to disengage the shuttle. To re-engage the door simply run opener in automatic mode or move door by hand until the trolley engages in the chain shuttle.

  • Page 12: Warranty

    6. To the extent permissible by statute, Smart Openers disclaims any liability of whatsoever nature in respect of any claim or demand for loss or damage which arises out of: accidental or deliberate damage to, or normal wear and tear to, the product or to the product’s components;...
