Theory of Operation Ver. 1.0 Apr. 2005
12.4 Toner Bottle Home Position Detection
• The Toner Supply Port is on the upper side whenever the Toner Bottle is at its home posi-
tion. The Toner Bottle Home Position Sensor (PC7) detects the Toner Bottle at its home
position.
12. Toner replenishing
Toner Supply Port
Toner Bottle Home Position
Sensor (PC7)
4021M024AA
37
