- Page 1 Series WBV/WV ™ Boilers As an ENERGY STAR ® Partner, PB Heat, LLC has determined that this product meets the ENERGY STAR guidelines for energy efficiency. I n s t a l l a t i o n , O p e r a t i o n & M a i n t e n a n c e M a n u a l...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS USING THIS MANUAL 5. BURNER SETUP & BOILER OPERATION A. INSTALLATION CLEARANCE ... . .1 A. BURNER INSTALLATION ....13 B. -
Page 3: Using This Manual
USING THIS MANUAL USING THIS MANUAL Indicates a condition or hazard which DANGER A. INSTALLATION CLEARANCE will cause severe personal injury, death or major property damage. Follow the installation instructions provided in this manual in the order shown. The order of these Indicates a condition or hazard which WARNING instructions has been set in order to provide the installer... -
Page 4: Preinstallation
PREINSTALLATION 1. PREINSTALLATION Read carefully, study these instructions before beginning work. It will save time. Study the included drawings. Save these instructions for reference. This boiler must be installed by a qualified contractor. The boiler warranty can be voided if the boiler is not installed, maintained and serviced correctly. The equipment shall be installed in accordance with those installation regulations in force in the NOTICE local area where the installation is to be made, including the current edition of NFPA-31, Standard... -
Page 5: Chimney / Vent And Draft Control
PREINSTALLATION For Example: C. CHIMNEY / VENT AND DRAFT CONTROL An oil-fired unit shall be connected Comments CAUTION Installation Installation to a flue having sufficient draft at all times, to assure safe proper No change, but older operation of the unit. Chimney chimneys (especially unlined -.04"... -
Page 6: Boiler Placement And Assembly
BOILER PLACEMENT AND ASSEMBLY 2. BOILER PLACEMENT AND ASSEMBLY A. SETTING THE BOILER C. JACKET ASSEMBLY (KNOCKDOWN BOILERS) 1. Provide a level foundation, located as close as possible to the center of the heating system. 1. If the boiler is to be installed with a rear flue outlet, remove the square knock-out in the back panel. - Page 7 BOILER PLACEMENT AND ASSEMBLY Figure 2.1: Steam boiler Figure 2.2: Water boiler (See Table 8.1 for parts identification).
-
Page 8: Piping And Controls
PIPING AND CONTROLS 3. PIPING AND CONTROLS Do not pipe boiler before jacket is NOTICE 4. When the return temperature from the system will be installed. below 150°F on oil boilers for extended periods (heat pump systems, outdoor reset, snow melt, etc.), provide piping and controls to protect the boiler from A. -
Page 9: Tankless Heater Or Coverplate
PIPING AND CONTROLS 2. If not using a tankless coil, cover the heater opening E. TANKLESS HEATER OR COVERPLATE with cover plate (item 7 or 16). 1. If a tankless coil is used (item 9), install as pictured. Be sure rubber gasket is in place On water boilers, install in opening in front section. - Page 10 PIPING AND CONTROLS Figure 3.5: Piping to Isolate Boiler from Chilled Medium on Chiller Systems Figure 3.7: Float Low Water Cut-off Figure 3.6: Piping with Peerless ® Indirect Water Tank...
-
Page 11: Electrical
ELECTRICAL 4. ELECTRICAL A. GENERAL All electrical wiring shall be done in accordance with the National Electrical Code and Local Requirements. Single pole switches including those of safety controls or protective devices shall not be wired in a grounded line. IMPORTANT In accordance with Section 325 (f) (3) of the Energy Policy and Conservation Act, water boilers are equipped with a feature that saves energy by reducing the boiler water temperature as the heating load decreases. - Page 12 ELECTRICAL Figure 4.2: Junction Box Wiring, Knockdown Water Boilers Figure 4.3: Junction Box Wiring, Steam Boilers...
- Page 13 ELECTRICAL Figure 4.4: Water Boilers, Beckett 7600A Limit Control Figure 4.5: Water Boilers, Hydrolevel 3250 Limit Control...
- Page 14 ELECTRICAL Figure 4.6: Steam with Float Low Water Cut-off Figure 4.7: Steam with Probe Low Water Cut-off...
-
Page 15: Burner Setup & Boiler Operation
BURNER SETUP & BOILER OPERATION 5. BURNER SETUP & BOILER OPERATION Burn only #2 Fuel Oil in this CAUTION 2. Adjust burner and barometric draft control for appliance. Do not use gasoline, highest CO ² (Maximum 13%) while maintaining a 0 crankcase drainings or any oil Smoke and -.01 to -.02"... -
Page 16: Clean The Boiler (Steam Boilers Only)
BURNER SETUP & BOILER OPERATION Do not leave boiler unattended while CAUTION E. CLEAN THE BOILER firing burner. Operating boiler with (STEAM BOILERS ONLY) water below minimum permissible water level may fracture sections. 1. Clean the boiler within one week after initial start-up. Cleaning will be more effective if boiler operates a 7. - Page 17 BURNER SETUP & BOILER OPERATION Table 5.1: Beckett Burner Specifications BECKETT BURNER SPECIFICATIONS Start-up Settings Boiler Burner Burner Static Pump Head Nozzle Size Model No. Model No. Head Plate Pressure Setting Air Shutter Air Band WBV-03-085 AFG-F3¹ 3-3/8" 0.75 80° B HAGO³ 140 PSI WBV-03-105 AFG-F4...
-
Page 18: Maintenance
MAINTENANCE 6. MAINTENANCE WARNING Product Safety Information Refractory Ceramic Fiber Product This appliance contains materials made from refractory ceramic fibers (RCF). Airborne RCF, when inhaled, have been classified by the International Agency for Research on Cancer (IARC), as a possible carcinogen to humans. After the RCF materials have been exposed to temperatures above 1800°F, they can change into crystalline silica, which has been classified by the IARC as carcinogenic to humans. -
Page 19: General
MAINTENANCE A. GENERAL C. WEEKLY MAINTENANCE (WITH BOILER OPERATING) 1. Check pipes adjacent to cold walls or in unheated spaces. Insulate and tape them if necessary to be 1. Flush float-type low-water cut-off (if used) to remove sure they can't freeze up. Keeping the water moving sediment from the float bowl as stated in the at all times will reduce the likelihood of freezing. -
Page 20: If A Long Shutdown Is Required
MAINTENANCE 2. To thoroughly clean the boiler it must be brushed G. IF A LONG SHUTDOWN IS REQUIRED down from the top. Alternatively, for limited space or minimum clearance to combustible installations, 1. To take boiler out of service if the boiler and system cleaning the heat exchanger from the combustion are not to be used when temperatures are below chamber side is acceptable. -
Page 21: Boiler Dimensions & Ratings
BOILER DIMENSIONS & RATINGS 7. BOILER DIMENSIONS & RATINGS Boiler Jacket Rear of Jacket to Model Depth C/L of Top Flue Flue Size Number "A" Outlet "B" "C" WBV-03-085/110 14-1/8" 7-1/16" 6" WBV-04-125/150 18-1/8" 9-1/16" 6" WV-05-175/200 22-1/8" 11-1/16" 7" Figure 7.1: Boiler Dimensions, Water Boiler Boiler Rear of Jacket to... - Page 22 BOILER DIMENSIONS & RATINGS Table 7.1: Boiler Ratings SERIES WBV/WV™ BOILER RATINGS Series WBV/WV™ Heating Minimum Capacity AFUE, Water Content, Stack Input Net Ratings Boiler Draft Model Steam, Steam, Water, Required, Number GPH¹ Water Steam sqft MBH³ MBH² Water Steam Water Steam in.
-
Page 23: Repair Parts
REPAIR PARTS 8. REPAIR PARTS Repair parts are available from your installer or by contacting PB Heat, LLC, 131 S. Church St, Bally, PA 19503. Note: Remember to include boiler model number and serial number when ordering parts. Table 8.1 Item Additional Stock... - Page 24 Series WBV/WV ™ Boilers I n s t a l l a t i o n , O p e r a t i o n & M a i n t e n a n c e M a n u a l TO T H E I N S TA L L E R : This manual is the property of the owner and must be affixed near the boiler for future reference.
