Operation Manual

Digital Video Recorder
DSR-815/1608

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSR-815 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Inter-m DSR-815

  • Page 1: Operation Manual

    Operation Manual Digital Video Recorder DSR-815/1608...
  • Page 2: Welcome

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. * It can be heated up if you use this product in closed box or ill-ventilated place. DSR-815/1608...
  • Page 3: Table Of Contents

    2-5-2. DDNS ........................30 2-5-3. Service Port ........................31 2-5-4. Event Server .......................31 2-6. System Setup ........................32 2-6-1. System Information......................32 2-6-2. Password Setup ......................33 2-6-3. Date & Time Setup ......................34 2-6-4. Pan/Tilt Setup......................35 2-6-5. System Upgrade ......................36 3. Search Function ...........................37 DSR-815/1608...
  • Page 4 1. Default Screen and Using the Functions ..................40 1. Monitoring Screen........................40 2. Camera Selection........................41 3. Screen Split/Screen Conversion ....................41 4. Two-way Audio (DSR-815/1608 does not Supports it) ...............42 5. Audio Volume Control......................42 6. Index Information Windows ......................42 7. Function Buttons ........................42 7-1.
  • Page 5: Precautions(Warning) In Manipulation Of The Set

    Be cautious that sticker or label attached on the set may become off or damaged will cause a direct fault. Distributor or user should pay attention that this system has been registered for an electromag- netic compliance of business purpose. If wrongly sold or purchased, please exchange it for home use only. DSR-815/1608...
  • Page 6: Before Getting Started

    - A repetition of power on and off without system off during an operation may damage the HDD. - When the system gives out fumes or odor immediately switch off the power supply and then contact your distributor to get a technical support and repair and maintenance. DSR-815/1608...
  • Page 7 Product Number Supplier / Telephone Date of Purchase Guarantee Period Name Customer Address Information Telephone - Please note other terms and conditions may vary with different suppliers. - You should quote the information above when requesting maintenance or service. DSR-815/1608...
  • Page 8: System Components

    Take out the components in a flat and dry area, and then check the following components are all included. Components of System DSR MAIN UNIT USER GUIDE PROGRAM CD MOUSE BATTERY AAA(2) POWER CABLE REMOTE CONTROL RACK BRACKET VOLT & NUT DSR-815/1608...
  • Page 9: System Introduction

    - Outer sensor mounted to survey a movement. MAJOR FUNCTIONS - It can monitor real time video images from 16 cameras.(DSR-1608: 16 channels, DSR-815: 8 channels) - It offers various user control interfaces, including mouse, jog shuttle, and key pad + remote control.
  • Page 10: Front Panel

    In the menu mode, it moves Cursor and changes a value. In the live screen, it selects an audio channel. (Up:1Ch, Right: 2Ch, Down :3Ch, Left 4Ch, Pause: Delete a sound.) In the Pan/Tilt mode, it controls a Pan/Tilt. /In search playback, it is utilized to control a playback. DSR-815/1608...
  • Page 11 RETURN KEY: It is utilized as the button to return to a previous menu or terminate it when set up a menu. 7. AUDIO OUTPUT TERMINAL Audio output terminal(RCA). 8. VIDEO OUTPUT TERMINAL Video output terminal (RCA). 9. USB TERMINAL It is utilized to back up using USB terminal. (USB 2.0 support) DSR-815/1608...
  • Page 12: Rear Panel

    DIGITAL VIDEO RECORDER Rear Panel Rear Panel [DSR-815] [DSR-1608] 1. AC INPUT This is the terminal to connect AC power outlet. 2. VIDEO INPUT This is the terminal to input a camera. (16 channels/8 channels) 3. LOOP OUT This is the Camera Output terminal. (16 channels/8 channels) 4.
  • Page 13 Audio signal output terminal (RCA). (1 channel) 11. VGA VGA video output terminal. 12. MONITOR OUTPUT This is the terminal to output a composite video signal. 13. CAMERA TYPE This is the terminal to set up a camera type. (NTSC/PAL) DSR-815/1608...
  • Page 14: Remote Control

    11. SEARCH It converses into the searching screen.(It will be selected when playback a recorded image.) 12. PTZ It changes PTZ Control Mode. 13. MENU It converses into the menu screen.(It will be selected to modify a system configuration.) DSR-815/1608...
  • Page 15: Dvr Monitoring Program

    When exchange HDD installed in an existing equipment for a new HDD, it will take more time to initialize the new HDD and the system and then to appear a live image. (Based on 25oG, it takes approximately 10 minutes.) Please contact your distributor when a live video will not be output continually. DSR-815/1608...
  • Page 16: Monitoring(Live) View

    Change a save capacity, date, or time indication: Click on the wheel button of the mouse or select RETURN (ESC) Button of the front (remote control). 1-2. Submenu : The following menu will appear when mouse displace in the direction of the bottom of the screen (date and time indication). DSR-815/1608...
  • Page 17: Pan/Tilt Camera Control

    [ Front Key or Remote Control ] : Select “PTZ” key. - Click on the channel you desire to control. [ Front Key or Remote Control ] : Select ENTER key after you displace the key you desire using the lateral direction key - PTZ has the following GUI. DSR-815/1608...
  • Page 18 (It is not an area where to be input from the mouse.) In he front key, “when you click on the II(Pause) button each, it changes mode according to the order [Zoom] [Focus] [Speed] [Preset:001] [Zoom] ... as shown in the following figure. DSR-815/1608...
  • Page 19 If you run Pan/Tilt/Zoom/Focus by utilizing the front key, it will continue the running until you will press button. 3) QUIT the P/T/Z mode. Mouse : Click R-button of mouse. Front key : “Return” key. DSR-815/1608...
  • Page 20: System Setup

    Manipulations of the remote control attached to the product conform with those of the front key. (It was designed to set up and control more easily by supporting the mouse.) If you run DSR-1608/DSR-815 with the same method, camera input channel (16/8 channels) and sensor input (16/8 channels) will be different in the designed values.
  • Page 21 4) Change a changed setting value : To save a changed value, select “ENTER” Key at the position of [T1]. 5) Cancel a changed setting value : To cancel a changed value, select “ENTER” Key at the position of [T2]. DSR-815/1608...
  • Page 22: Camera Setup

    < Figure. 2> 1) Camera Select : Select a camera you desire. [ DSR-1608 : (channel: 1~ 16) ; DSR-815 : (channel : 1 ~8) ] 2) Camera Title : Set up the name of camera in the select channel.
  • Page 23 - Contrast : Adjust the Contrast of the camera image.(default value : 50) - Saturation : Adjust the Saturation of the camera image.(default value : 50) - Hue : Adjust the Hue of the camera image.(default value : 50) DSR-815/1608...
  • Page 24: Record Setup

    ) button, and then select “Enter” button.] <Figure. 5> 1) Camera Select : Select a camera you desire. [ DSR-1608 : (channel : 1~ 16) ; DSR-815 : (channel : 1 ~8) ] 2) Frame Rate : Number of Recording Frame. [ Maximum recording Frame ] NTSC : 352X240(Resolution) : 120FPS;...
  • Page 25 (8) In case that resolution is D1 and a number of camera On is 13~16, select it for 1.9(NTSC), 0.8(PAL) Frames in maximum. [ DSR-815 ] (1) In case that resolution is CIF and a number of camera On is 1~4, select it for 30(NTSC), 25(PAL) Frames in maximum.
  • Page 26: Event & Motion Setup

    On the configuration screen as shown in <Fig. 1>, click on “Event&Action”. [use of the front key and the remote control : Select “Menu” button, displace to corresponding menu with the lateral ( ) button, and then select “Enter” button.] <Figure. 7> DSR-815/1608...
  • Page 27 1. Motion : Select the sensitivity and the area to detect motion. 1) Camera Select : Select a camera you desire. [ DSR-1608 : (channel: 1~ 16) ; DSR-815 : (channel: 1 ~8) ] 2) Area : It sets up motion sensing area.
  • Page 28: Storage & Backup

    2. Sensor : Set up sensor type, advance or post Record, alarm output, etc. 1) Sensor Select : Select a sensor channel you desire. [ DSR-1608 : (channel: 1~ 16) ; DSR-815 : (channel: 1 ~8) ] 2) Sensor type : Set up a sensor kind.
  • Page 29 - It does not support USB CD-RW and DVD-RW. - If it cannot go on backup because it cannot recognize the correct size of a USB storing device, format the storing device in window PC and then go on backup again. DSR-815/1608...
  • Page 30: Network Setup

    4) Gateway : It sets up a Gateway value. (example) : 192.168.10.1) 5) DNS address : It sets up a DNS address. (example) : 168.126.63.1) 2-5-2. DDNS: When the system utilizes flow IP ADDRESS, set up DDNS to connect it from the internet(in remote location). <Figure. 13> DSR-815/1608...
  • Page 31: Service Port

    (When constituting a network using network line sharers or installing more 2 units of DVRs with same model number, change services in each to monitor DVR image from a remote location.) 2-5-4. Event server : When generating an event, it notifies it to the remote system (computer installed with the agent view program) <Figure. 15> DSR-815/1608...
  • Page 32: System Setup

    On the configuration screen as shown in <Fig. 16>, click on “System Information”. [use of the front key and the remote control : Select “Menu” button, displace to corresponding menu with the lateral ( ) button, and then select “Enter” button.] DSR-815/1608...
  • Page 33: Password Setup

    1) Front key locking : Set up whether to lock or unlock front keys. (Enable : Restriction to use the front Key, Disable: No restriction to use the front Key) * When you have finished to authenticate using the front Key, “Front key locking” value is automatically changed into Disable. DSR-815/1608...
  • Page 34: Date & Time Setup

    On the configuration screen as shown in <Fig. 16>, click on “Time & Date”. [use of the front key and the remote control : Select “Menu” button, displace to corresponding menu with the lateral ( ) button, and then select “Enter” button.] <Figure. 19> DSR-815/1608...
  • Page 35: Pan/Tilt Setup

    4) Parity bit : Set up a number of parity bits. 5) Stop bit : Set up a number of stop bits. 6) Pan tilt Type : Set up a kind of pan tilt camera. 7) Camera ID : Set up ID of camera. DSR-815/1608...
  • Page 36: System Upgrade

    2) TFTP IP ADDRESS : When upgrade through the TFTP server, set up a server address. 3) “Upgrade”: When click on “Upgrade” button, it executes the system upgrade. (Firmware file name : DSR-1608 : DSR-1608r.bin, DSR-815 : DSR-815r.bin) (1) Connect USB memory in which firmware was copied to USB TERMINAL.
  • Page 37: Search Function

    - Manual : Indicate data recorded with the manual mode. - All times : Indicate data recorded with the all times (continuous) mode. - Sensor : Indicate data recorded with the sensor mode. - Motion : Indicate data recorded with the motion mode. DSR-815/1608...
  • Page 38 * At [7] item (tap), move to the minute to search for, and then select “ENTER” Key. (On [4] item, the time and minute you have selected will be displayed.) * Move to [8] (playback button), and then select “ENTER” Key. <Figure. 23> DSR-815/1608...
  • Page 39 * Upon a reverse playback, contraction is unzipped on the basis of I-FRAME which is the features of MPEG4 so that the previous image is appeared for a while, which does not mean the system has a problem but is in normal operation. DSR-815/1608...
  • Page 40: Default Screen And Using The Functions

    - UCM program was designed to administrate DVRs in integral, whose functions not supported to other DVR are restricted for some performances. - Some functions of UCM program may be under change according to InterM’s situation. <UCM Default Screen> Function button may not be naturally executed at low line speed depending on the line speed of [UCM Default Screen] network.
  • Page 41: Camera Selection

    [ Screen Conversion ] : Manually reverses the screen. : Manually Forwards the screen. : Automatically switches the screen (default value: 10 seconds) : Fully enlarges the screen (click the right mouse button in the monitoring screen to “enlarge”) DSR-815/1608...
  • Page 42: Two-Way Audio (Dsr-815/1608 Does Not Supports It)

    Environment setup : Sets environment related with UCM (Client Manager System). [Authorization procedure] : Performs authorization procedure for environment setting. (Default password: ”1111”) If authorization is successfully done, following window is displayed. Search function : Executes Search. See the “Search” part in the manual. DSR-815/1608...
  • Page 43: Environment Setup

    - Use: Sets whether re-Connect for use will be done - Reconnect interval: Sets re-Connect trial interval. 5) [Password change] - Previous password: Inputs the password previously used - New password: Inputs a new password. - New password check: Re-inputs to check a new password. DSR-815/1608...
  • Page 44: Server List Management

    - User password : Inputs user password. - Registration is executed if clicking the “OK” button. - Registration is cancelled if clicking the “OK” button. IP/DDNS ID : MAC Address Format : “XX-XX-XX-XX-XX-XX” example) if Mac address is “00:17:5F:00:0A:15”, IP/DDNS ID Item Value is “00-17-5F-00-0A-15”. DSR-815/1608...
  • Page 45 - Modify work is cancelled if clicking “Cancel” button. [Delete]: Delete the already registered group. - Select a list to delete from the group register list. - Click “Delete” button. - Select the “OK” button from a window to check whether “Delete” will be done. DSR-815/1608...
  • Page 46: Function Tab Buttons

    [Camera 2 Group] : Displays Camera, Sensor and Audio Status by Channel. (Channel 17~32) PanTilt control : Click the PanTilt button to activate the control window as shown below. (the control window can be moved with the mouse) : PanTilt control window Button DSR-815/1608...
  • Page 47 - To edit the preset : Specify the relevant number, move to the camera and click the edit button. - To delete the preset : Specify the relevant number and click the delete button. - Click the save button before closing. DSR-815/1608...
  • Page 48 - To delete the touring : Specify the number and click the delete button. - Save the operation before closing. Log Window: Displays log list. : Log status window button Log list is displayed The detailed log window is displayed when you double-click on the list area. DSR-815/1608...
  • Page 49: Connection/Disconnection

    - Password : Inputs password. - “Server Connect” : Clicks the server Connect button. - If succeeding in Connect, image is displayed on the moni- tor screen window. - If failing in Connect, Connect failure error message is dis- played. DSR-815/1608...
  • Page 50: Quit

    - A check window is displayed asking whether Disconnect will be done. - Click the OK button. 10. Quit : Quit program. Clicks the end icon. - The authorization window is displayed. - Click OK button after inputting password. DSR-815/1608...
  • Page 51: Search Function

    - Full screen [Previous screen Settings] : Converse/Return a playback screen into the whole screen. - Reset the channel sequence : Change a channel order into the initial value. - Display an image magnified in single view mode : Converse/Return a playback image into the play- back window size. DSR-815/1608...
  • Page 52: Search Screen Split

    - Click the “Calendar” Icon to display the following window. Move to the previous month Move to the next month - Data in Blue : Recorded data does not exits. - Data in White : Recorded data exits.(“Click” date to play) - Data in Green : Selected data. DSR-815/1608...
  • Page 53 - For the area to enlarge from image, select the area with a red square. - Zoom-In : Reduces the red square to enlarge. - Zoom-Out : Enlarges the red square to enlarge. - For the Play Screen window, only enlarged image area is played. DSR-815/1608...
  • Page 54: Play Control

    [Last Frame Movement] : Moves to last frame of recording image. [First Frame Movement] : Moves to the first frame of the recorded image. [Go Straightly] : Moves to given time. - Sets time to play. - Click “OK” button. DSR-815/1608...
  • Page 55: Time Table

    1. Select date to play. [See item No. 4] 2. Select time to play from the Time Table. [Select time to play the Time Table or use Find button function] 3. Click play button. [Click play button of play buttons] 4. Play control reference. DSR-815/1608...
  • Page 56: Function I

    1) Select “Select a drive” in the system setting, and then select USB drive backup. 2) Select “Backup drive” in the directory setting of the system setting and then “Confirmation” to terminate the setting. 3) The calendar will indicate no load. 4) For detailed playback method, please refer to Page 50. DSR-815/1608...
  • Page 57: Book Mark

    - “Close” : Close the Bookmark Control window. The bookmark only memorises the location value of a recorded image to manage it. If the storage Device is saved in overwritten, only the list remains and users and users can no longer see the image. DSR-815/1608...
  • Page 58: Function Ii

    - Compression Type : Selects from “DX50”, “XVID”. - “Start” : Starts file conversion. - If starting file conversion, time and size are displayed on list. - If conversion time ends, click the Stop button. - “Close” : Close the window. DSR-815/1608...
  • Page 59: Snap Shop

    • Contrast : Adjust the contrast of the image. • Hue : Adjust the Hue f image. • Saturation : Adjust the saturation of the image. • Original Image : Click to restore the default value set in the warehouse DSR-815/1608...
  • Page 60: Panorama

    Stop : Stops play. Play in Forward Direction : Play in forward direction. After Frame : Moves frame by frame forward from the overall frame. Next Page : Moves page by page forward from the overall frame. Quit : Quit panorama window. DSR-815/1608...
  • Page 61: Event(Smart) Search

    This is function to rapidly retrieve time that goods disappear by automatically gener- ating list where motion occurred in the store by checking the area that the goods were laid. [ Quit ] : Quit Search. DSR-815/1608...
  • Page 62: Image Analysis

    - This program is used to authenticate the forgery or alteration of images in external storages. - Program execution method : Start menu All Program “Image Analyst” execution. - Find - Click “Find” and select an image in JPEG in an external storage. DSR-815/1608...
  • Page 63 The authenticated Image means that the data in an external device has not altered. - Authentication Information : If the image has not been forged or altered, the following image should appear when you check the authentication information. If the image has been altered, the following information is not displayed. DSR-815/1608...
  • Page 64 DIGITAL VIDEO RECORDER - Original Image : Click the “Original Image” button to display the following image. If the image has been altered, all the information is deleted and the following message appears. DSR-815/1608...
  • Page 65: Automatic Remote Connect Agentview

    - Connect : Remotely Connectes to the system equivalent to the event currently selected. - Connectes when “double clicking” the event list. Ref) To use remote automatic Connect function, firstly accurately set information concerning network announcement schedule and network setting of the server program. DSR-815/1608...
  • Page 66: Remote Connect Screen Interlocked With Ucm

    DIGITAL VIDEO RECORDER 2. REMOTE CONNECT SCREEN INTERLOCKED WITH UCM - This is function automatically Connected by the remote notice schedule in occurrence of event (sensor, motion). See UCM manual.(For the detailed, please refer to Page 40.) DSR-815/1608...
  • Page 67: Copy(Downloadng) Data In Remote

    2) Input DSR-1608/815 of ADDRESS with the type of ftp://XX.XX.XX.XX” in the window explorer address. (Example : ftp://192.168.48.46) 3) On the log on window, input user name and password. (User name : “root”, password : password of root(the administrator) DSR-815/1608...
  • Page 68 4) It will display the folder list playback. 5) Move to the folder which has playback data to search for, and then select a file to be downloaded. 6) Click on the mouse right button and select “Copy to folder” on the menu. DSR-815/1608...
  • Page 69 If the file to be downloaded was wrongly nominated, you cannot search for it in search program then. 8) It will copy (download) the playback file selected. 9) When it will have finished to copy (download) the playback file selected, you can search recorded images in search program. (For the detailed, please refer to Page 51.) DSR-815/1608...
  • Page 70: Specifications

    DIGITAL VIDEO RECORDER Specifications Specifications DSR-815 DSR-1608 Camera Input 8 CH (BNC) 16 CH (BNC) Loop out 8 CH (BNC) 16 CH (BNC) Monitor Out 1 VGA, 1 BNC (MONITOR OUT) Camera Input Type NTSC/PAL Live Speed [NTSC] : Up to 240FPS...
  • Page 71: Supplement

    DIMS (Dynamic IP Management Server) system. [ Fixed IP Address ] DSR-1608/815 Client [ Dynamic IP Address ] DSR-1608/815 Client Dynamic IP Server Web Server DSR-815/1608...
  • Page 72: Register Flow Ip Server User

    B. REGISTER FLOW IP SERVER USER 1) Run the internet explorer. 2) Input “http://www.inter-mdvr.co.kr” in the internet address window. (The following screen will appear.) 3) Click on the area of “DPR/DSR-Series”. 4) Click on the area of “Available after subscription”. DSR-815/1608...
  • Page 73 DIGITAL VIDEO RECORDER 5) Clock on the area of “Member subscription”. 6) Click on the button of “Agree”. 7) Click on the button of “ID check”. DSR-815/1608...
  • Page 74 8) Input users’ ID in the test box of “Member ID” and click on the button of “Search”. (For an available “User ID”, click on the button “OK”.) (For an unavailable “User ID”, input a new “User ID” and repeat searching to find out an available User ID.) DSR-815/1608...
  • Page 75 “*” After having finished to input all the articles marked *, click on the button of “Member registration”. Select a model number : Select your model number. (DPR-1630, DPR-1615, DSR-1608, DSR-815) MAC address : Input MAC address of your set.
  • Page 76: Install An Additional Hard Disk (Hdd)

    Procedures of installation of additional HDDs 1. Remove the screws of the right and left part (2 ones in each) and rear part (5 ones). 2. Separate the cover from the product. 3. Disassemble the power supply cable and data(IDE)cable connected to HDD. DSR-815/1608...
  • Page 77 • For HDD _2 Jumper newly added : Master of Secondary • For HDD _3 Jumper newly added : Slave of Secondary Jumper Setting IDE Connector Power Connector Jumper [WesterDigital Harddisk jumper] 6. Fix up new HDD on the bracket with screws. DSR-815/1608...
  • Page 78 We recommend you HDD to be newly added will be the same series of an existing HDD. When HDD Jumper and data cable are abnormally connected, the system cannot recognize a HDD, or it does not go on, please contact the service center. DSR-815/1608...
  • Page 79: Recording Time Table

    5.95 160G 5.448 2.724 1.816 1.0896 0.7264 200G 6.81 3.405 2.27 1.362 0.908 MPEG4 250G 8.5125 4.25625 2.8375 1.7025 1.135 Super 320G 10.896 5.448 3.632 2.1792 1.4528 400G 13.62 6.81 4.54 2.724 1.816 500G 17.025 8.5125 5.675 3.405 2.27 DSR-815/1608...
  • Page 80: Recording Size And Recording Size Calculation Method

    MPEG4, Low, File size 1k, 240 frame recording 120FPSx1Kx60secx60secx24hours = 10.4G 6. 250G HDD Recording time calculation : Total 250G recording size/Total recording frame (CH recording frame No.xCH No)/File size(K)/ 60sec/60min Example) CIF, Modified MPEG4, Normal, file size 2K, 120frame recording 237,000,000,000Byte/120FPS/2K/60sec/60min = 274.3hours(Divide 24hour = 11.43day) DSR-815/1608...
  • Page 81 NOTE DSR-815/1608...
  • Page 82 NOTE DSR-815/1608...
  • Page 83 DSR-815/1608...
  • Page 84 MADE IN KOREA www.inter-m.com 2008. 1 9000003320...
