E5 Sensor Error (without belt movement):
If the upper control board does not see adequate feedback from the
speed sensor when the belt is being commanded to move this error
will occur.
This error can occur for different reasons which we have listed
below.
First, if there is a break in the main data cable, the speed feedback
information will not make it back to the upper board.
Check to see if there is speed feedback in the upper board while
in calibration.
Next check continuity on the data cable to verify there is no break
in the connection.
If the upper board command signal is not being received at the lower
board there will be no belt movement.
