LAUNCH TREADMILL

OWNER'S MANUAL AND ASSEMBLY GUIDE

Table of Contents

Need help?

Do you have a question about the LAUNCH TC3-DA-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for True Fitness LAUNCH TC3-DA-35

Page 1 LAUNCH TREADMILL OWNER’S MANUAL AND ASSEMBLY GUIDE...
Page 2: Important-Please Read
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 3: Reporting Freight Claims Or Parts Damage
Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.
Page 4: Table Of Contents
ASSEMBLY STEPS................12 PRODUCT FEATURES BASE OVERVIEW................25 CONSOLE OVERVIEW..............26 CARE AND MAINTENANCE INSPECTION................28 CLEANING THE EQUIPMENT............28 LEVELING THE MACHINE...............29 RUNNING BELT ALIGNMENT............30 TENSIONING THE RUNNING BELT..........31 LUBRICATING THE TREADMILL.............32 PREVENTATIVE MAINTENANCE............33 LONG TERM STORAGE..............33 © 2025 TRUE Fitness All Rights Reserved.
Page 5: Safety Instructions
Use a TRUE AC power cord or AC/DC adapter only. • This stationary training equipment is not suitable for high accuracy purposes. • Position this product so the power cord plug is accessible to the user. © 2025 TRUE Fitness All Rights Reserved.
Page 6 • While the treadmill is in use, proceed at a speed that the user can safely maintain with the ability to immediately engage the safety key to stop the treadmill belt if necessary. © 2025 TRUE Fitness All Rights Reserved.
Page 7: Power Requirements
Line Voltage Frequency Rated Current Number of Units Model Plug/Outlet* Dissipation (Hz) (Amps) per Circuit (Watt) NEMA 5-15 Dedicated TC3-DA-35 50/60Hz 1230 *The plug configuration for the power adapter may vary by country. © 2025 TRUE Fitness All Rights Reserved.
Page 8: Space Requirements
DIMENSIONS (L X W X H) 79” x 32” x 60.5” / 212.09cm x 81.2cm x 153.67cm • MACHINE WEIGHT 349 lbs 158.3 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2025 TRUE Fitness All Rights Reserved.
Page 9: Warning Decals
While using, ensure all hands, legs, and feet remain within the boundary box of the treadmill belt. Treadmill Exit When getting off the treadmill, wait until the belt comes to a full stop, then step on the side rails (straddle covers) and then onto the floor. © 2025 TRUE Fitness All Rights Reserved.
Page 10: Assembly Instructions
INCLUDED TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX IN BOX IN BOX 5mm and 6mm Allen #2 Phillips Screwdriver Level Wrench 7/16” and 17mm Wrench Adjustable Wench 8mm T-Handle Allen Wire Cutters Wrench © 2025 TRUE Fitness All Rights Reserved.
Page 11 PS0100 SHCS, M8-1.25 X 25MM TPS8123 SCREW, M8 X 90MM TI0076 TRUSS PHILLIPS BOLT M4XP0.7X12 TCS0024 SCREW, SEMS, M4-0.7X12MM, NYLOK, BLK ST1024 SAFETY KEY ASSEMBLY TCS0028 CORD LOCK, SAFETY KEY 00349000 SILICONE LUBRICATION © 2025 TRUE Fitness All Rights Reserved.
Page 12: Assembly Steps
C. Using a #2 Phillips screwdriver, remove and set aside the seven screws securing the left and right motor trim covers. securing the motor cover. B. Remove and set aside the left and right motor trim covers. D. Remove and set aside the motor cover. © 2025 TRUE Fitness All Rights Reserved.
Page 13 IMPORTANT! DO NOT fully tighten the hardware until step 6. I/O data and power verify the bolts do not interfere with the pedestals and the frame— if the bolts interfere, use a 17mm wrench to loosen them © 2025 TRUE Fitness All Rights Reserved.
Page 14 Coaxial Cable 110V power NOTE: To fully tighten the coaxial cable inlet nut, use a 7/16” wrench. network assembly coaxial cable cable CAUTION: AVOID DAMAGE! connection connection ALWAYS KEEP CABLES AWAY FROM MOVING PARTS! © 2025 TRUE Fitness All Rights Reserved.
Page 15 G. Snip excess cable tie material. CAUTION: AVOID DAMAGE! ROUTE CABLE UNDER THE INCLINE MOUNTING BRACKET—ALWAYS KEEP CABLES AWAY FROM MOVING PARTS! CAUTION: AVOID DAMAGE! ROUTE CABLE UNDER THE INCLINE MOUNTING BRACKET—ALWAYS KEEP CABLES AWAY FROM MOVING PARTS! © 2025 TRUE Fitness All Rights Reserved.
Page 16 B. Finger tighten or use a 5mm allen wrench to loosely attach the handrail assembly to the pedestal assemblies. C. Using a 5mm allen wrench, evenly tighten the four hex screws, ensuring the holes remain aligned. © 2025 TRUE Fitness All Rights Reserved.
Page 19 (00567800). heart rate D. Insert the power cord into the power inlet. ground E. Power on the treadmill and verify the TC39400 console powers up. safety power I/O data © 2025 TRUE Fitness All Rights Reserved.
Page 20 E. Using a #2 Phillips screwdriver, reattach the two screws securing the left and right motor trim covers. B. Reattach the motor cover. C. Using a #2 Phillips screwdriver, reattach the seven screws securing the motor cover. © 2025 TRUE Fitness All Rights Reserved.
Page 21 A. Press the lower cover up against the bottom of the upper assembly. IMPORTANT! DO NOT pinch the cables. B. Using a #2 Phillips screwdriver and 11 screws, secure the lower cover in place. © 2025 TRUE Fitness All Rights Reserved.
Page 22 C. Attach the safety key clip to the metal tab. D. If applicable, remove protective film from safety key attachment point on the console assembly. E. Attach the safety key to the console assembly. © 2025 TRUE Fitness All Rights Reserved.
Page 23 C. Verify both wing nuts on the leveling feet are securely tightened—wing nuts should be flush against the bottom of the frame. NOTE: You should be able to loosen and tighten the wing nuts by hand. If not, use an adjustable wrench. wing nut wing nut leveling feet © 2025 TRUE Fitness All Rights Reserved.
Page 24 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 25: Product Features Base Overview
Allows users or faculty to turn the power on or off to the treadmill. H. Power Cord Delivers power from the wall outlet to the treadmill. Leveling Feet An adjustable system used to aid in the leveling the treadmill. © 2025 TRUE Fitness All Rights Reserved.
Page 26: Console Overview
CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
Page 28: Care And Maintenance
CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any part of the treadmill. Allow the treadmill to dry completely before using. Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation of the unit.
Page 29: Leveling The Machine
NOTE: You should be able to loosen and tighten the wing nuts by hand. If not, use an adjustable wrench. wing nut wing nut leveling feet © 2025 TRUE Fitness All Rights Reserved.
Page 30: Running Belt Alignment
C. Turn the treadmill on and start the belt at 3 mph (5 kph) keeping off the unit. Move the Belt to D. Allow 2 minutes for the belt to self adjust. the Left Side Repeat these steps if additional adjustment is necessary. © 2025 TRUE Fitness All Rights Reserved.
Page 31: Tensioning The Running Belt
E. When both sides are measuring within range, turn the treadmill on and start the belt at 3 mph (5 kph) keeping off the unit. F. Allow 2 minutes for the belt to self adjust. G. Check to see if the belt is still slipping. Repeat these steps if additional tensioning is needed. © 2025 TRUE Fitness All Rights Reserved.
Page 32: Lubricating The Treadmill
6. Walk on the treadmill at 3 mph (5 kph) for approximately one minute to spread the lubricant evenly through the belt and deck. Please contact your dealer or TRUE product support to obtain the proper lubrication. © 2025 TRUE Fitness All Rights Reserved.
Page 33: Preventative Maintenance
TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
Page 34: Additional Information Troubleshooting
Rubbing sound from treadmill when in operation Contact TRUE product support Drive belt may be misaligned Slats may be loose or broken Interference with anti-pinch bracket Adjust belt tension See Tensioning the Running Belt © 2025 TRUE Fitness All Rights Reserved.
Page 35 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.
Page 36: Wiring Diagram
WIRING DIAGRAM—110V TCL4018 TCS0025 TCS4019 RB0086 TCL4010 TPS8250 PST005 PST006 00319600 TCS4032 TCS4032 TCSX005 TR9502 TCS4031 TCS4033 TR9503 PS0079 TPS8254 PS0079 TPSWIR006 TPSWIR004 PS0026A TPSWIR005 TCWIR002 PS0040 TCWIR002 PS0022A PS0032A Safety Key TCWIR004 © 2025 TRUE Fitness All Rights Reserved.
Page 37: Warranty Information Commercial Warranty
Coax/TV, HDMI, USB, mirroring or 1 Year Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.
Page 38: Limited-Use Commercial Warranty
LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...
Page 39: Warranty Details
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.
Page 40: Warranty Registration
St. Louis, MO 63366 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
Page 42 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-TC3-DA-35 Owner’s Manual and Assembly Guide REV04 © 2025 TRUE Fitness All Rights Reserved.
