VAPOR STRYKER SLAT TREADMILL
OWNER'S MANUAL AND ASSEMBLY GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAPOR STRYKER TC1-SA-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for True Fitness VAPOR STRYKER TC1-SA-35

  • Page 1 VAPOR STRYKER SLAT TREADMILL OWNER’S MANUAL AND ASSEMBLY GUIDE...
  • Page 2: Important-Please Read

    Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
  • Page 3: Reporting Freight Claims Or Parts Damage

    Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.
  • Page 4: Table Of Contents

    ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................14 PRODUCT FEATURES BASE OVERVIEW................32 CONSOLE OVERVIEW..............33 CARE AND MAINTENANCE INSPECTION................35 CLEANING THE EQUIPMENT............35 MOVING THE MACHINE..............36 LEVELING THE MACHINE..............37 TENSIONING THE SLAT BELT............38 PREVENTATIVE MAINTENANCE............39 LONG TERM STORAGE..............39 © 2025 TRUE Fitness All Rights Reserved.
  • Page 5: Safety Instructions

    Use a TRUE AC power cord or AC/DC adapter only. • This stationary training equipment is not suitable for high accuracy purposes. • Position this product so the power cord plug is accessible to the user. © 2025 TRUE Fitness All Rights Reserved.
  • Page 6 • Avoid the possibility of bystanders being struck or caught between moving parts by making sure that they are out of reach of the equipment while it is in motion. © 2025 TRUE Fitness All Rights Reserved.
  • Page 7: Power Requirements

    Number of Units Model Plug/Outlet* Dissipation (Hz) (Amps) per Circuit (Watt) NEMA 5-20 Dedicated 50/60Hz 1650 TC1-SA-35 NEMA 6-15* Dedicated 50/60Hz 1650 *The plug configuration for the power adapter may vary by country. © 2025 TRUE Fitness All Rights Reserved.
  • Page 8: Space Requirements

    DIMENSIONS (L X W X H) 72” x 35” x 64” / 182cm x 89cm x 163cm • MACHINE WEIGHT 599 lbs / 271.7 kg • MAXIMUM USER WEIGHT 500 lbs / 226.7 kg © 2025 TRUE Fitness All Rights Reserved.
  • Page 9: Warning Decals

    865 HOFF RD. ST. LOUIS, MO 63366, USA 24-TC1SA35001A base serial 226.7kg/500lbs number location +UKCA COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. ST1000 Treadmill ETL-Serial Number Sticker 8/31/22 © 2025 TRUE Fitness All Rights Reserved.
  • Page 10: Proper Training Position And Treadmill Safety

    While using, ensure all hands, legs, and feet remain within the boundary box of the treadmill belt. Treadmill Exit When getting off the treadmill, wait until the belt comes to a full stop, then step on the side rails (straddle covers) and then onto the floor. © 2025 TRUE Fitness All Rights Reserved.
  • Page 11: Assembly Instructions

    800.883.8783). TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX 5mm Allen Wrench #2 Phillips screwdriver 6mm Allen Wrench Pliers 8mm Allen Wrench Level 10mm T-Handle Allen Wrench © 2025 TRUE Fitness All Rights Reserved.
  • Page 12: Box Contents

    ASSEMBLY INSTRUCTIONS *The 220V Power Cord and 220V Power Inlet Assembly are only included with this product if the unit is being used on a circuit having a nominal rating of more than 110-V. © 2025 TRUE Fitness All Rights Reserved.
  • Page 13: Hardware Pack Contents

    SCREW, M8X0.8X15 TCS0024 POWER CORD RETAINER TC0033 SCREW, M5X0.8X6 FE0091 HEX SOCKET BOLT, M10X1.5X20 TCS0024 SEMS SCREW, M4X0.7X12 TPS8123 SEMS HEX SOCKET BOLT, M8X1.25X90 FT0047 HEX SOCKET BOLT, M8X1.25X20 FT0014 SPLIT LOCK WASHER, M8 © 2025 TRUE Fitness All Rights Reserved.
  • Page 14: Assembly Steps

    DO NOT get pushed back into the base as this might cause them to be damaged by the slat belt. DO NOT PUSH CABLES BACK INTO THE BASE AS THIS MIGHT CAUSE THEM TO BE DAMAGED BY THE SLAT BELT © 2025 TRUE Fitness All Rights Reserved.
  • Page 15 PEDESTAL TUBE TRIM, LEFT ST1025R PEDESTAL TUBE TRIM, RIGHT Slide the pedestal tube trim pieces down the pedestal upright assemblies. NOTE: Do not place the pedestal tube trims in their final resting location until step 6. © 2025 TRUE Fitness All Rights Reserved.
  • Page 16 D. Verify all cables have been securely connected and then carefully tuck all cables back inside the right pedestal upright assembly. E. Using a 5mm allen wrench, fully tighten the M8 hex bolts. © 2025 TRUE Fitness All Rights Reserved.
  • Page 17 ST1017L HAND RAIL COVER, LEFT ST1004L-35 HAND RAIL ASSEMBLY, LEFT ST1017R HAND RAIL COVER, RIGHT ST1004R-35 HAND RAIL ASSEMBLY, RIGHT Slide the hand rail cover assemblies onto the hand rail assemblies as shown. © 2025 TRUE Fitness All Rights Reserved.
  • Page 18 C. Align the holes of the hand rail assemblies with the holes on the console assembly and pedestal assemblies. D. Using 5mm and 6mm allen wrenches, evenly tighten all hardware ensuring the hardware holes remain aligned. © 2025 TRUE Fitness All Rights Reserved.
  • Page 19 M5 screws. C. Press the top screw covers into place. D. Using a #2 Phillips screwdriver secure the front M4 screws to the console assembly. © 2025 TRUE Fitness All Rights Reserved.
  • Page 20 B. Using a #2 Phillips screwdriver secure the left and right side trim plastics to the base using the identified hardware. C. After all hardware has been fully tightened, press the left and right pedestal tube trim pieces into place. © 2025 TRUE Fitness All Rights Reserved.
  • Page 21 SCREW, M4X0.7X12 ST1013 INNER HAND RAIL COVER ST1020 OUTER HAND RAIL COVER Using a #2 Phillips screwdriver secure the inner and outer hand rail covers to the hand rail assemblies using the identified hardware. © 2025 TRUE Fitness All Rights Reserved.
  • Page 22 SCREW, M4X0.7X12 ST1006R INNER PEDESTAL COVER, RIGHT ST1018R OUTER PEDESTAL COVER, RIGHT Using a #2 Phillips screwdriver secure the inner and outer pedestal covers to the pedestal upright assemblies using the identified hardware. © 2025 TRUE Fitness All Rights Reserved.
  • Page 23 C. Attach the safety key clip to the metal tab. D. If applicable, remove protective film from safety key attachment point on the console assembly. E. Attach the safety key to the console assembly. © 2025 TRUE Fitness All Rights Reserved.
  • Page 24 (00567800). safety D. Using a #2 Phillips screwdriver, network power center I/O data attach the rear console cover. NOTE: Depending on the installation, ERP and PVS power may not be used. © 2025 TRUE Fitness All Rights Reserved.
  • Page 25 ST1045 POWER CORD CLOSURE ST1085R FRONT ROLLER COVER TI0065 SCREW, M5X0.8X15 Using a #2 Phillips screwdriver, remove the power cord closure, power cord retainer, power cord (if already attached), and front roller cover. © 2025 TRUE Fitness All Rights Reserved.
  • Page 26 Tools Used in this Step Item Part Description #2 Phillips Screwdriver ST1245 POWER INLET ASSEMBLY (110V) TC0033 SCREW, M5X0.8X6 Using a #2 Phillips screwdriver, remove the power inlet assembly (110V) as shown below. © 2025 TRUE Fitness All Rights Reserved.
  • Page 27 Move the green cable to the green dot. • Move the blue cable to the blue dot. • Move the brown cable to the brown dot. Power Inlet Assembly (110V) Power Inlet Assembly (220V) © 2025 TRUE Fitness All Rights Reserved.
  • Page 28 Tools Used in this Step Item Part Description #2 Phillips Screwdriver 00604600-35 POWER INLET ASSEMBLY (220V) TC0033 SCREW, M5X0.8X6 Using a #2 Phillips screwdriver, secure the power inlet assembly (220V) as shown below. © 2025 TRUE Fitness All Rights Reserved.
  • Page 29 SCREW, M5X0.8X15 00363100 220V POWER CORD Using a #2 Phillips screwdriver, secure the front roller cover, power cord, power cord retainer, and power cord closure. use top mounting holes for 220V power cord © 2025 TRUE Fitness All Rights Reserved.
  • Page 30 C. Using a #2 Phillips screwdriver, secure the power cord retainer. D. Using a #2 Phillips screwdriver, re-secure the power cord closure. right front roller cover right front use middle mounting roller cover holes for 110V power cord © 2025 TRUE Fitness All Rights Reserved.
  • Page 31 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
  • Page 32: Product Features Base Overview

    Allows users or faculty to turn the power on or off to the Slat Treadmill. Power Cord Delivers power from the wall outlet to the Slat Treadmill. J. Leveling Feet An adjustable system used to aid in the leveling the Slat Treadmill. © 2025 TRUE Fitness All Rights Reserved.
  • Page 33: Console Overview

    CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
  • Page 34 UNITE LED Eight Dedicated Data Points Manually Adjust Incline Manually Adjust Speed Dedicated Message Center Bright White LEDs Keypad Choose Workout © 2025 TRUE Fitness All Rights Reserved.
  • Page 35: Care And Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any part of the treadmill. Allow the treadmill to dry completely before using. Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation of the unit.
  • Page 36: Moving The Machine

    D. Using the 10mm T handled allen wrench, rotate cord the bolt to the RIGHT to RAISE the transport wheels. Once the bolt becomes easy to turn, the transport wheels are no longer on the ground. transport wheels lowered © 2025 TRUE Fitness All Rights Reserved.
  • Page 37: Leveling The Machine

    NOTE: You should be able to should be flush against the bottom of the frame). loosen and tighten the wing nuts by hand. If not, using pliers can help. wing nut wing nut leveling feet © 2025 TRUE Fitness All Rights Reserved.
  • Page 38: Tensioning The Slat Belt

    NOTE: If a slipping, skipping, or jerking sensation is present, check the drive belt. The drive belt is separate from the slat belt. If the drive belt is slipping you will need to replace the drive belt. Contact TRUE product support. 10 15 25 10 12  INCLINE SPEED power ON/OFF switch bottom © 2025 TRUE Fitness All Rights Reserved.
  • Page 39: Preventative Maintenance

    TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
  • Page 40: Additional Information Troubleshooting

    Rubbing sound from treadmill when in operation Contact TRUE product support Drive belt may be misaligned Slats may be loose or broken Interference with anti-pinch bracket Adjust belt tension See Tensioning the Slat Belt © 2025 TRUE Fitness All Rights Reserved.
  • Page 41 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.
  • Page 42: Warranty Information Commercial Warranty

    Coax/TV, HDMI, USB, mirroring or Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.
  • Page 43: Limited-Use Commercial Warranty

    LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...
  • Page 44: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.
  • Page 45: Warranty Registration

    ETL-Serial Number Sticker 8/31/22 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
  • Page 46 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-TC1-SA-35 Owner’s Manual and Assembly Guide REV05 © 2025 TRUE Fitness All Rights Reserved.
