Model PLRU1777DS .............. All Refrigerator
Model PLFU1777DS ..................... All Freezer
Topic:
• Installation guidlines for pair
• Installation guidlines for single
Electrical Information:
• Recommended practice:
ÿ Plug unit/units directly into their own properly grounded three prong receptacle
protected with a minimum 15 amp time delay fuse or circuit breaker.
ÿ Do Not plug unit/units into a Ground Fault Circuit Interrupter (GFCI) circuit.
ÿ Cord sets are 72" long, and emerge from near the bottom of the unit back. It is
recommended the receptacle be approximately midway between the two units.
*
Receptacle, according to Article 100 of the 2005 NEC, is "a contact device installed at
the outlet for the connection of an attachment plug." A typical wall outlet has two
receptacles.
Location:
• The units must be installed on a floor that is level and strong enough to support a fully
loaded refrigerator and freezer.
• Consider water supply availability for models equipped with an automatic ice maker.
• Do Not block toe grille on the lower front of the units. Sufficient air circulation is essential
for the proper operation of the units.
• Do Not install unit/units over HVAC ducts.
Minimum cut-out dimensions for models with Trim Kit:
• Double wide installation: See Fig A
ÿ Cabinet rough opening – 66" wide x 75" tall
ÿ Depth requirement – 25.25"
• All Refrigerator (single unit) installation: See Fig B
ÿ Cabinet rough opening – 33" wide x 75" tall
ÿ
Depth requirement – 25.25"
Minimum cut-out dimensions for models without Trim Kit:
• Double wide installation: See Fig C
ÿ Cabinet rough opening – 65.125" wide x 65.875" tall
ÿ Depth requirement – 25.25"
• All Refrigerator (single unit) installation: See Fig D
ÿ Cabinet rough opening – 32.75" wide x 65.875" tall
ÿ Depth requirement – 25.25"
Installation Guidelines
*
,
Page 1 of 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Electrolux PLRU1777DS
Summary of Contents for Electrolux PLRU1777DS
-
Page 1: Installation Guidelines
Installation Guidelines HOME PRODUCTS Model PLRU1777DS ………….. All Refrigerator Model PLFU1777DS …..……………. All Freezer Topic: • Installation guidlines for pair • Installation guidlines for single Electrical Information: • Recommended practice: ÿ Plug unit/units directly into their own properly grounded three prong receptacle protected with a minimum 15 amp time delay fuse or circuit breaker. - Page 2 Kitchen Cabinet cut-out dimensions for models with Trim Kit Fig A Fig B Kitchen Cabinet cut-out dimensions for models without Trim Kit KitTrim Kit Fig C Fig D Page 2 of 5...
-
Page 3: Electrical Information
Topic: Installation and Leveling of Stainless Steel All Refrigerator, All Freezer Units with dynamic condensers (PLKU1777DS & PLRU1777DS): Electrical Information: 1. Each unit must be plugged into its own dedicated 115 Volt, 60 Hz., AC circuit. 2. The power cord of each unit is equipped with a three-prong grounding plug for protection against shock hazards. - Page 4 Leveling Instructions for Refrigerator and Freezer: 1. Leveling leg adjustments may require a 1-1/4” wrench. 2. Level door of the refrigerator using all four levelers and slide unit into place. Recheck for levelness and adjust if necessary. 3. Measure distance from floor to bottom of door on the refrigerator. Adjust and level the freezer so door height matches.
- Page 5 Unit Lying on its Back Loosen Front Leg Levelers Remove Four Crating Bolts Fig. A Remove Wood Base Install Rear Leg Levelers 64-3/16” Min. 3/16” Min. Raises Door Fig. B Doors Flush Doors Parallel 65-1/4” Min. Fig. C Freezer Refrigerator Page 5 of 5...
