TF
Always turn off and unplug the machine before detaching any parts.
The reason is internal faults may cause shorts to components
that are normally at low voltage presenting a shock hazard.
Electrolux Thailand Co.,Ltd.
1910 Electrolux Building
New Petchburi Rd. Bangkapi
Huaykwang Bangkok , 10310
Tel : +662 725 9000
Service Manual
SAFETY WARNING
When servicing machines, do not remove
ANY detachable parts while the machine is powered.
PINOT
BF
FD
Publication-No.
161021

Advertisement

loading
Need help?

Need help?

Do you have a question about the PINOT TF and is the answer not in the manual?

Questions and answers

Summary of Contents for Electrolux PINOT TF

  • Page 1 When servicing machines, do not remove ANY detachable parts while the machine is powered. The reason is internal faults may cause shorts to components that are normally at low voltage presenting a shock hazard. Electrolux Thailand Co.,Ltd. 1910 Electrolux Building New Petchburi Rd. Bangkapi Publication-No.
  • Page 2: Product Feature

    PRODUCT FEATURE ETB4602AA,ETB5702AA - 2 -...
  • Page 3 PRODUCT FEATURE ETE4600AA - 3 -...
  • Page 4 PRODUCT FEATURE ETE5720AA - 4 -...
  • Page 5 PRODUCT FEATURE EBE4500AA - 5 -...
  • Page 6 PRODUCT FEATURE EHE5220AA - 6 -...
  • Page 7 PRODUCT FEATURE Azzurra UI ERF1600 ERF2003 Ruby AIM ERF2003 Cyan UI Azzura UI Cyan UI Ruby AIM •5 leds – Temperature •7 Touch keys control FEATURES •5 leds – Temperature level with back lit LEDs •6 leds – Temperautre •LED Digit display level •1 led –...
  • Page 8: Product Specifications

    PRODUCT SPECIFICATIONS - 8 -...
  • Page 9 PRODUCT SPECIFICATIONS HOT PIPE Anti condensations (TF) HOT PIPE MULLION (TF/BF/MD Model) METAL MULLION COVER HOT PIPE (BF & MD Model) BF & MD DUCT CROSS OVER SIDE AIR COOL DUCT CROSS OVER SIDE AIR COOL - 9 -...
  • Page 10: Product Installation

    PRODUCT INSTALLATION Pinot is big capacity and height. Importance : when install product must adjust stability foot attach with the floor completely to prevent product fall down when customer use. Stability foot Adjustable Feet & Rollers Back roller Back roller Handle installations •...
  • Page 11: Operation

    OPERATION Pinot refrigerant applied R600a. Evap Skin condensers Suction tube Capillary Tube Dryer Comp Refrigeration cycle Comp Suction Skin tube condenser Evap Dryer Capi tube - 11 -...
  • Page 12 OPERATION • Inverter compressor spec VNX113Y spec VNX1113Y FLEX DRIVE PINOT - 12 -...
  • Page 13 OPERATION • Air Flow Diagram Air outlet to the top Air outlet to Fast Freezing Insufflate to Ice Maker Air to all compartment Air to all compartment Air to Deodorizer Air Return Freezer Air Return Freezer Air Return Fridge Air outlet to Chilled Air Return Fridge Air outlet to Shelf Side cooling supply...
  • Page 14: Normal Operation

    OPERATION • OPARETION TF BASIC MODEL (ETBXXXXX) AZURA UI ERF1600 Normal Operation Temp adjust Compartments Factory setting temp 0ºc to 7ºc 3ºc Fridge 1ºc/step -18ºc -23ºc to -14ºc Freezer 1.3ºc/step The compressor & Fan are controlled according to Fridge temperature sensor. If Fridge sensor temperature is above Cut-In temperature then compressor &...
  • Page 15 OPERATION • Inverter Compressor VNX1113Y,R600a, 230V ,40-150 Hz. Working current is 0.5-0.6 amp. Compressor speed is controlled by inverter drive “Flex drive 1” board Compressor Parameters Speed Cycling. 2700rpm Fridge temperature is more than 5ºc above set-point. 3300rpm After defrost is operated for 30 min. 3300rpm The first defrost is according to below meet conditions.
  • Page 16 OPERATION • Defrost Defrost is activated when DTS is below 0°C and: • The actual compressor run time(CRT) is bigger than the set runtime. • The compressor cycle is off and the actual compressor run timer is less than 30 minutes of the set runtime. The defrost process is split into 4 stages in a cycle.
  • Page 17 OPERATION • Next defrost The next defrost is base on the heater defrost On time. See in table below. Default defrost 32 minutes time (def) <= def def + 1 def + 2 def + 3 def + 4 def + 5 def + 6 >= def +7 Defrost Time...
  • Page 18 OPERATION 1. 5 Leds –Temperature level. 2. 7 Led- Boost function. Led 7 3. 6 Led- Colder. Led 6 Led 5 4. 2 Led – Less cold. Led 4 5. 1 led-Temperature selection & Led 3 Led 2 Boost function. Led 1 •...
  • Page 19 OPERATION • Temperature Adjustment. There are 10 steps of temperature adjustment. Press on the button will decrease the temperature by 1 step see the detail as per below table. Led 7 Led 6 Led 5 Led 4 Led 3 Led 2 Led 1 •...
  • Page 20 OPERATION • Fault Mode Sensor Fault In sensor fault mode LED will blink with in 1sec.(0.5 sec Brightness , 0.5 sec down).If touch button is pressed. It is able to adjust Temperature level but after 10 sec it will come back to sensor fault displayed. •...
  • Page 21 OPERATION • Operation TF,BF LUXURY (ETEXXXX,EBEXXXX) TF,MD LUXURY AIM (ETE5720 , EHE5220) Main PCB ERF2003,8W and ERF2003,15W ERF2003 ,8w For TF&BF ERF2003,15w For TF,MD Luxury Luxury AIM In red arrow are visual point to know that both board are difference and can’t compatible Between ERF2003 ,15w &...
  • Page 22 OPERATION • Compressor control Compressor operation is base on Freezer temperature. If freezer temperature (NTC_FZ) is above the Freezer Cut In then compressor is turned on. Once the freezer temperature is below Freezer Cut Out the compressor is turned off. The compressor is only turned back on if ALL conditions are met.
  • Page 23 OPERATION • Fan control • The compressor is running • Boost Fridge is activated • The corrected food compartment temperature is greater than the (food Set Point + food Differential + Fan Override) The fan is turned off when the compressor is turned off and fresh food compartment have moved below its cut-out value.
  • Page 24 OPERATION • Adaptive Compressor Runtime (Next defrost) The next defrost is base on the heater defrost On time. See in table below. Default defrost 32 minutes time (def) ≤ def Defrost Time def + 1 def + 2 def + 3 def + 4 def + 5 def + 6...
  • Page 25 OPERATION • Power on • When refrigerator is powered on each segment is lit in succession starting from the top and working down to the bottom. • on’ tone will sound. Ramp LEDs to Active Mode in Power 0.5sec (0% to 100%) to show factory •...
  • Page 26: Fridge Compartment

    OPERATION 4.Temperature adjust. Fridge compartment Freezer compartment 5.Quick Freeze /Boost Fridge. “Quick Freeze” button when freezer zone selected. Compressor will operate for 90 minutes then switch to Normal Mode. “Boost Fridge” button when fridge zone selected. Compressor will operate for 90 minutes then switch to Normal Mode.
  • Page 27 OPERATION Error/Fault Codes 1.Fridge Door Alarm If the fridge door is left open for longer than 2 minutes The buzzer on PWB will sound. • the alarm LED_2 (Fridge Zone) will flash (100% to 0% to 100%) every 1sec (ramp up = 0.5sec, Ramp down = 0.5sec). •...
  • Page 28 OPERATION Error/Fault Codes 3.Communication Error between main board and UI board. LED_7 flashes with 1sec timing 4.Sensors faulty. LED_4 and LED_1 will flash for failure of Freezer sensor. LED_4 and LED_2 will flash for failure of fridge sensor. LED_6 will flash for a failure of the DTS. Combinations of LEDs will flash if there is a failure of more than one sensor.
  • Page 29 OPERATION • OPARETION TF,MD LUXURY AIM (ETE5720AA) RUBY UI + ERF2003,15W RUBY UI ERF2003,15W 1.Power On When the power is first turned on: All icons and LEDs will illuminate to 100% brightness for 3 seconds Then: Fade off to factory default setting in Activate mode sound will “Beep”. Factory default settings are “Icemaker off”...
  • Page 30 OPERATION 2. Temperature Adjustment From activated mode: 1.Use “Select” button to select freezer or fridge compartment temperature setting. -23 ºC to -14 °C. 2.Freezer adjust temperature range 7 °C to 0 °C. 3.Fridge adjust compartment temperature range 4.To make temperature colder in 1°C steps press left “-” button.
  • Page 31 OPERATION 3.2 Fast Ice Use the Fast Ice Mode when you add a large amount of food to the freezer compartment or need to make ice faster. Activate Fast Ice: • Activate by press “MODES” key until “Fast Ice” brightness. •...
  • Page 32 OPERATION 4. Eco icon (Energy Saving) Activate Eco icon: Freezer temperature setting from -18°C to -14°C and Fridge temperature setting from +3°C to +7°C. Eco icon will not active: •If Boost actived. •If Fast Ice actived. •If door alarm activated •If over temp alarm activated.
  • Page 33: Freezer Temperature Alarm

    OPERATION 6.Freezer temperature alarm After the power has been On minutes, if the freezer compartment becomes too warm temperature in the freezer warmer than 10°C above the setting point for 50 minutes. • A buzzer on PWB will sound. • The “Freezer temperature display”...
  • Page 34 OPERATION 8.Display Lock Activated mode: • Press and hold the “Display Lock” button for 3 seconds. This will lock the display to prevent • accidental changes to the settings. The “Padlock” icon will appear on the electronic display when Display Lock is activated. •...
  • Page 35 OPERATION 10.Ice maker On/off. To active this select mode press “ICE maker On/Off ” then will select between 2 modes. 1) ICE maker Off icon On ( Ice maker off) Ice maker On/off by press 2) ICE maker icon off (Ice maker turn On) “ICEMAKER ON/OFF”...
  • Page 36 OPERATION 13.Error/Fault Codes 1.Communication Error A communication error means the display has lost contact with the main control board. Recommend the customer turn the product off for 5 minutes and then turn it back on, 2.Sensors Any sensor are open or short will displayed as per below. Sensor Open circuit Short circuit...
  • Page 37 OPERATION Auto Ice Maker Components Nozzle Flex Tube Water Water Outlet Supply Lid Automatic Ice Water Maker Assy Pump Pump Housing Water tank assy. Defrost Heater 2,4W Connector Icemaker Connector Elbow Connector AIM Space Salsa (3x) Tube Water Drain Elbow Connector Housing Nut Nylon Hex...
  • Page 38 OPERATION Ice twist motor Ice cube tray Ice tray temp sensor. Ice maker arm Auto Ice Maker work Flow...
  • Page 39 DIAGNOSTICS • Diagnostics mode TF Basic ETBXXXX...
  • Page 40 DIAGNOSTICS • Diagnostics mode TF ,BF luxury ETEXXXX,EBEXXXX...
  • Page 41 DIAGNOSTICS • Diagnostics mode TF ,BF luxury ETEXXXX,EBEXXXX • Diagnostics mode TF ,MD luxury ETE5720,EHE5220...
  • Page 42 DIAGNOSTICS...
  • Page 43 DIAGNOSTICS...
  • Page 44 DIAGNOSTICS...
  • Page 45 DIAGNOSTICS...
  • Page 46 DIAGNOSTICS • FLEX DRIVE 1 INPUT & OUTPUT SIGNAL...
  • Page 47 DIAGNOSTICS...
  • Page 48 DIAGNOSTICS...
  • Page 49 DIAGNOSTICS...
  • Page 50 DIAGNOSTICS...
  • Page 51 DIAGNOSTICS • MAIN BOARD DISASEMBLY The main PCB is placed on back side of the cabinet with the fully cover. 1) Unscrew to remove the cover. 2) Disconnect wring to remove PCB. Caution : when handle the PCB and all terminal connecters must wear an anti static gloves to avoid ESD charge to PCB it may cause PCB defect.
  • Page 52 DIAGNOSTICS • FLEX DRIVE 1 ASSEMBLY Assembly terminal and wiring ground to compressor connecter. Tight screw to compressor to fix the box. Caution : when assembly terminal must be assembly only 1 direction as per below picture. • Assy Evap and cover Evap Freezer sensor Assy Evap EVAP AC Fan...
