r e f r i g e r a t o r
INSTRUCTION BOOKLET
ERN 16300
ERN 2372
UK
2222 746-34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERN 16300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Electrolux ERN 16300

  • Page 1 INSTRUCTION BOOKLET ERN 16300 ERN 2372 2222 746-34...
  • Page 2: Important Safety Instructions

    Important Safety Instructions These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Prior to Installation General Safety ¥...
  • Page 3: Table Of Contents

    At the end of the Appliance Life consequences for the environment and human health, which could otherwise be caused by ¥ When disposing of your appliance use an inappropriate waste handling of this product. For authorised disposal site. more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where The symbol...
  • Page 4: Operation

    Operation Before use Remove all securing tapes. Wash inside the Meat can only be stored safely in this way for one appliance with lukewarm water and bicarbonate of or two days at the most. soda (5 ml to 0.5 litre of water). Do not use soap or Fruit &...
  • Page 5: Groceries Drawer / The Door Shelves

    Groceries Drawer Normal operating sounds (only for ERN 2372) Some models have a groceries drawer mounted on You may hear faint gurgling or bubbling sounds when rollers above the fruit and vegetable trays. When the refrigerant is pumped through the coils or tubing stored here groceries are more easily accessible.
  • Page 6: Health And Safety Guidelines

    Health and Safety Guidelines Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that ¥...
  • Page 7: Defrosting

    Defrosting The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. Important To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment...
  • Page 8: Something Not Working

    Something not Working? Before contacting your local Service Force Centre check the following points. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. Symptom Solution No power to appliance...
  • Page 9: Service And Spare Parts

    Customer Care Department For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk...
  • Page 10: Guarantee Conditions

    Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ¥...
  • Page 11: Technical Specifications

    Technical specifications ERN 1673 ERN 2372 POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz 220-240 V / 50 Hz TOTAL POWER ABSORBED 100 W 140 W AVERAGE DAILY UNITS ELECTRICITY (*) 0,49 kWh 0,44 kWh GROSS CAPACITY 158 l 230 l NET CAPACITY 154 l...
  • Page 12: Door Reversal

    Door reversal The applianceÕs door has been locked in position for transport by means of pins on both sides. According to the door opening direction, remove relevant pins at the top and at the bottom. Attention After completion of the door reversing operation, check that the door gasket adheres to the cabinet.
  • Page 13: Electrical Connection

    Electrical Connection If you fit your own plug, the colours of the wires in the WARNING mains lead of your appliance, may not correspond THIS APPLIANCE MUST BE EARTHED. with the markings identifying the terminals in your The manufacturer declines any liability plug, proceed as follows: should this safety measure not be Connect the Green and the Yellow (earth) wire to the...
  • Page 14: Building In

    Building in Dimensions of the recess ERN 1673 ERN 2372 Height of housing (1) 1225 Depth of housing (2) Width of housing (3) D022 1. Fit the appliance in the niche by making sure that it stands against the interior surface of the unit on the side where the door hinges of the appliances are fitted.
  • Page 15 PR33 7. Fix cover (Hc) on guide (Ha) until it clips into place. 4. Snap vent grill (B) and hinge cover (E) into position. Apply blanking covers (C-D) as indicated. PR167 8. Open the appliance door and the furniture door at 90¡.
  • Page 16 PR168 10. Place the small square on the guide again and fix it with the screws supplied. Should the alignment of the furniture door be necessary, use the clearance of slots. At the end of this procedure, it is necessary to check if the door of the furniture closes properly.
  • Page 20 Electrolux HemProdukter AB S-105 45 Stockholm www.electrolux.se ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE...
