Summary of Contents for Electrolux ERZ3600
- Page 1 R é f r i g é r a t e u r - C o n g é l a t e u r / K o e l - V r i e s c o m b i n a t i e INSTRUCTION BOOK GEBRAUCHSANWEISUNG NOTICE D'UTILISATION GEBRUIKSAANWIJZING ERZ3600 818 37 13-02/6...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. -
Page 3: Description Of The Appliance
Description of the Appliance Model ERZ3600 Glass shelf Diveder "Natura-fresh" zone with drawers and cover Freezer drawer Freezer plate Ventilation grille Butter compartment Door shelf with Egg holder Bottle shelf Grid Quick chill shelf Bottle- and can holder Control Panel... -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 4 hours. -
Page 5: Switching Off
Pack up all foodstuffs before keeping in the "Natura-fresh" zone. In this way aroma, moisture and colour is kept for a longer time. Suitable packing materials: Polyethylene airtight bags and wraps; Plastic containers with lids; Aluminium foil. Regulation of air humidity The two drawers are fitted with adjustable air slots. -
Page 6: Cabinet Interior
Carbon filter's function: The built-in carbon filter means that strong smelling groceries can be placed near other groceries without affecting their taste or aroma. Cabinet interior The shelves and door compartments are removable and can easily be re-arranged. Certain shelves must be lifted up by the rear edge to enable them to be removed. -
Page 7: Using The Freezer
Using the freezer To start the freezer and set the correct temperature Switching on: Switch on the freezer by pressing the power switch. The alarm sounds if the temperature inside the - 18 freezer reaches room temperature. Turn off the alarm by pressing the switch-off button. -
Page 8: Freezing
Temperature alarm If the temperature rises above -12°C, the red warning lamp flashes and an audible alarm sounds. The temperature display will then start to flash. To switch off the alarm: Press the alarm shut-off button to switch off the audible alarm. -
Page 9: Suitable Storage Periods
Practical advice on freezing · When freezing products, use the top shelf, and if necessary the shelf beneath as this is the coldest part. . - Place the foods directly on the freezer shelves. · Spread out the products as much as possible to allow air to circulate between them. -
Page 10: Hints And Tips
Hints and Tips Saving energy Make sure the door gasket is complete and · always clean. Pay careful attention to where the cabinet is · Food Storage placed. See the section "Installation". When installed correctly, the cabinet will consume less To obtain the best results from your appliance, ·... -
Page 11: Cleaning
Cleaning Clean the cabinet at regular intervals. Don't use detergents, abrasive powders, high perfumed cleaning products, wax polishes or cleaning products containing bleach or alcohol when cleaning the product Disconnect the appliance from electricity supply. Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0,5 litre water) Rinse and dry thoroughly. -
Page 12: Defrosting The Fridge
Defrosting the fridge The fridge is defrosted automatically every time the compressor stops. Frost formation can be prevented · not putting warm foodstuff inside the cabinet. · avoiding frequently opening the door or keeping it open too long. To change the light bulb The light is switched on automatically when the UV-blocked door is opened. - Page 13 It is too warm inside the refrigerator. Set a lower temperature. Put food products in the right place inside the refrigerator. See the chapter "Temperature inside the refrigerator". Distribute the food products to allow cold air to circulate around them. Make sure that the door is completely closed and that the insulating strip is complete and clean.
-
Page 14: Declaration Of Guarantee Terms
or defects that result from the addition of DECLARATION OF GUARANTEE non-original accessories or spare parts are not TERMS. covered by the guarantee. Our appliances are produced with the greatest of 10. Appliances that are easy to transport may be care. -
Page 15: Technical Specification
Technical specification Model ERZ3600 Volume Refrigerator 160 l 82 l "Natura-Fresh" zone 87 l Volume Freezer Width 595 mm Height 2000 mm Depth 623 mm Energy consumption 315 kWh/y Energy class Rated power 130 W Freezing capacity 14 kg/24 hours... -
Page 16: Remove The Transport Supports
Remove the transport supports Remove the tape and the transport supports from the door sides · inside the door hinges · the shelves · Remove the transport support on the glass shelf by pushing the support forward along the edge of the shelf until it stops. -
Page 17: Installing The Cabinet
Installing the cabinet When two appliances are placed beside each other, the distances enclosed in the plastic wrapping should be glued between the appliances. As shown in the illustration. Make sure that the power plug is not squashed or damaged by back of the product. A damaged power plug may overheat and cause a ·... -
Page 18: Door Reversal
Door Reversal 1. Close the cabinet and remove the plug from the electrical socket. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Remove and reposition it on the other side. 3. Put the cabinet on a wooden board when it is laid down. - Page 19 qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK aáÉ=bäÉÅíêçäìñJdêìééÉ=áëí=ÇÉê=ïÉäíïÉáí=Öê∏≈íÉ=eÉêëíÉääÉê=îçå=Ö~ëJ=ìåÇ=ëíêçãÄÉíêáÉÄÉåÉå=dÉê®íÉå=ÑΩê=ÇáÉ=hΩÅÜÉI=òìã oÉáåáÖÉå=ìåÇ=ÑΩê=cçêëí=ìåÇ=d~êíÉåK=gÉÇÉë=g~Üê=îÉêâ~ìÑí=ÇáÉ=bäÉÅíêçäìñJdêìééÉ=áå=ΩÄÉê=NRM=i®åÇÉêå=ÇÉê=bêÇÉ=ΩÄÉê=RR jáääáçåÉå=mêçÇìâíÉ=EhΩÜäëÅÜê®åâÉI=eÉêÇÉI=t~ëÅÜã~ëÅÜáåÉåI=pí~ìÄë~ìÖÉêI=jçíçêë®ÖÉå=ìåÇ=o~ëÉåã®ÜÉêF=ãáí=ÉáåÉã tÉêí=îçå=êìåÇ=NQ=jêÇK=rpaK iÉ=dêçìéÉ=bäÉÅíêçäìñ=Éëí=äÉ=éêÉãáÉê=Ñ~ÄêáÅ~åí=ãçåÇá~ä=ÇD~éé~êÉáäë=ÇçãÉëíáèìÉëI=ÇDÉåíêÉíáÉå=Éí=éçìê=äDÉñí¨êáÉìêK mäìë=ÇÉ=RR=ãáääáçåë=ÇÉ=éêçÇìáíë=Çì=dêçìéÉ=bäÉÅíêçäìñ=EíÉäë=èìÉ=ê¨ÑêáÖ¨ê~íÉìêëI=Åìáëáåá≠êÉëI=ä~îÉJäáåÖÉI=~ëéáê~íÉìêëI íêçå´çååÉìëÉëI=íçåÇÉìëÉë=¶=Ö~òçåF=ëçåí=îÉåÇìë=ÅÜ~èìÉ=~åå¨É=éçìê=ìå=ãçåí~åí=ÇDÉåîáêçå=NQ=ãáääá~êÇë=ÇDbìêçë Ç~åë=éäìë=ÇÉ=NRM=é~óë=¶=íê~îÉêë=äÉ=ãçåÇÉK aÉ=bäÉÅíêçäìñ=dêçÉé=áë=ÇÉ=ÖêççíëíÉ=éêçÇìÅÉåí=íÉê=ïÉêÉäÇ=î~å=~~åÖÉÇêÉîÉå=~éé~ê~íÉå=îççê=ÖÉÄêìáâ=áå=ÇÉ=âÉìâÉåI êÉáåáÖáåÖëïÉêâò~~ãÜÉÇÉå=Éå=îççê=ÖÉÄêìáâ=ÄìáíÉåëÜìáëK=få=ãÉÉê=Ç~å=NRM=ä~åÇÉå=çîÉê=ÇÉ=ÜÉäÉ=ïÉêÉäÇ=ïçêÇÉå=áÉÇÉê=à~~ê ãÉÉê=Ç~å=RR=ãáäàçÉå=bäÉÅíêçäìñ=éêçÇìÅíÉå=Eòç~äë=âçÉäâ~ëíÉåI=ÑçêåìáòÉåI=ï~ë~ìíçã~íÉåI=ëíçÑòìáÖÉêëI=âÉííáåÖò~ÖÉå=Éå Öê~ëã~~áÉêëF=îÉêâçÅÜí=íÉê=ï~~êÇÉ=î~å=ÅáêÅ~=rpa=NQ=ãáäà~êÇK MARIESTAD /AV...
