22
KD-VPHD4X1 Operating Instructions
Video Processing Functions
Sharpness, Brightness, Contrast
I
Saturation, Hue
I
H & V Size, Position, Input Offset
I
Zoom (Output Aspect Ratio processing), including options to prevent monitor burn-in for
I
Letterbox or Pillarbox images:
Full
I
Letterbox, Pillarbox
I
Horizontal Zoom, Vertical Zoom, Horizontal and Vertical Zoom
I
Built-in Test patterns help you set-up your video system (all patterns available through the
I
front-panel LCD and pushbuttons, as well as RS-232):
White pattern
I
Cross pattern
I
Cross hatch
I
Color bars
I
Gray scale
I
White window
I
Horizontal ramp
I
Wide horizontal ramp
I
Wide vertical ramp
I
Status and Control
Store your custom settings for each of the four (4) HDMI Inputs
I
Convenient front-panel display and pushbuttons
I
Easy-to-operate IR Remote Control
I
Discrete IR commands available
I
Rear-panel remote input
I
RS-232:
I
Firmware upgradeable, with rear-panel switch to go into "Program Mode"
I
Supports major control systems such as AMX
I
Crestron
®
, HomeLogic
Connectors
Each Input and the Output is compromised of the following connectors:
I
HDMI: 1 x HDMI Type A 19-pin connector
I
Digital Coaxial PCM Audio: 1 x RCA female
I
Optical Audio: 1 x Toslink
I
Analog stereo Left & Right Audio: RCA female (1 each color-coded Left & Right)
I
RS-232C: D-sub 9-pin
I
Mechanical
No fan noise
I
Rack mountable: 1U
I
Product Size: 17 x 11 x 1.5 inches (excluding rack ears)
I
Product Weight: 8 lbs. (excluding external power supply)
I
Enclosure type: Metal
I
Input power: External power supply included (6 Volt DC @ 5 Amps, 110-240 VAC, 50-60 Hz)
I
, lifeIware
, RTI
®
, Savant, Universal
®
, Colorado vNet
®
, Control4
®
, Xantech
®
®
,
