Easy to control and operate:
I
Convenient front-panel display and pushbuttons
I
Easy-to-operate IR Remote Control
I
RS-232
I
Video & Audio Inputs
There are four (4) Inputs, on the rear of the product, labeled "1" through "4"
I
Select "RGB" or Component (YPbPr) for each Input
I
For each of the four (4) Inputs, there are the following connectors:
I
HDMI A/V: 1 x HDMI Type A 19-pin connector
I
Supports HDCP Copy Protection
I
To support DVI-D Video, use HDMI<>DVI adapter cable(s)
I
Digital Coaxial PCM Audio: 1 x RCA female
I
Optical Audio: 1 x Toslink
I
Analog stereo Left & Right Audio: RCA female (1 each color-coded Left & Right)
I
Video & Audio Outputs
There is one (1) Output, on the rear of the product, with the following connectors:
I
HDMI A/V: 1 x HDMI Type A 19-pin connector
I
Supports HDCP Copy Protection
I
To support DVI-D Video, use HDMI<>DVI adapter cable(s)
I
Digital Coaxial PCM Audio: 1 x RCA female
I
Optical Audio: 1 x Toslink
I
Analog stereo Left & Right Audio: RCA female (1 each color-coded Left & Right)
I
Video Input Formats Supported
Supports the following popular Input Formats:
I
720 x 480i @ 60 Hz
I
720 x 480p @ 60 Hz
I
1280 x 720p @ 60 Hz
I
1920 x 1080i @ 60 Hz
I
Accepts and automatically detects 60 Hz and 50 Hz input formats
I
Video Output Formats Supported
Supports the following popular Output Formats:
I
640 x 480p @ 60 Hz
I
720 x 480i @ 60 Hz
I
720 x 480p @ 60 Hz
I
1920 x 540 p @ 60 Hz
I
1280 x 720p @ 60 Hz
I
1368 x 768p @ 60 Hz
I
1280 x 768p @ 60 Hz
I
1400 x 1050p @ 60 Hz
I
1920 x 1080i @ 60 Hz
I
1920 x 1080p @ 60 Hz
I
The output frame rate will be the same as the input frame rate, and supports 60 Hz and 50
I
Hz input formats
576i @ 50 Hz
I
576p @ 50 Hz
I
720p @ 50 Hz
I
1080i @ 50 Hz
I
576i @ 50 Hz
I
576p @ 50 Hz
I
720p @ 50 Hz
I
1080i @ 50 Hz
I
Pass-through mode (output = input)
I
