V-Size
I
Saturation
I
Hue
I
H-Input Offset
I
V-Input Offset
I
H-Position
I
V-Position
I
Input format (RGB or YPbPr)
I
Zoom / Aspect Ratio
I
Once you have selected a parameter to adjust for a particular Input (Input 1 through 4),
simply use the Left and Right Arrow buttons to move through the range. For example,
"Brightness" is set to a factory default of "00" but can be adjusted Up to +50 or Down to -50.
When instructed, you can reset the setting to Factory Default using the "Select" pushbutton on
the front panel.
4. Video Resolution Formats Supported.
The world-class video processor and scaler built into your KD-VPHD4X1 Switcher & Processor
converts the Input Video format to match the resolution format of your display. Pass-through
mode
(output = input). Most popular Input and Output video resolution formats are supported,
including:
Input Formats Supported:
720 x 480i @ 60 Hz
I
720 x 480p @ 60 Hz
I
1280 x 720p @ 60 Hz
I
1920 x 1080i @ 60 Hz
I
Output Formats Supported:
640 x 480p @ 60 Hz
I
720 x 480i @ 60 Hz
I
20 x 480p @ 60 Hz
I
920 x 540 p @ 60 Hz
I
1280 x 720p @ 60 Hz
I
1368 x 768p @ 60 Hz
I
1280 x 768p @ 60 Hz
I
1400 x 1050p @ 60 Hz
I
1920 x 1080i @ 60 Hz
I
1920 x 1080p @ 60 Hz
I
576i @ 50 Hz
I
576p @ 50 Hz
I
720p @ 50 Hz
I
1080i @ 50 Hz
I
576i @ 50 Hz
I
576p @ 50 Hz
I
720p @ 50 Hz
I
1080i @ 50 Hz
I
Pass-through mode (output = input)
I
15
