KD-VPHD4X1 Operating Instructions
2. Understand the full capabilities of your KD-VPHD4X1 Switcher & Processor unit.
Your KD-VPHD4X1 Switcher & Processor unit is feature-rich, and performs much more than
"4 x 1" switching of HDMI signals A/V and corresponding analog, PCM, and/or Toslink optical
Audio. Your KD-VPHD4X1 Switcher & Processor unit has a built-in, high-quality scaler and
video processor. Before we start to operate and control these functions, let's look at the
gamut of features provided in your unit:
Video Processing Functions Provided
Key Digital ® DPE
I
Sharpness, Brightness, Contrast
I
Saturation, Hue
I
Horizontal & Vertical Size, Position, Input Offset
I
Zoom (Output Aspect Ratio processing), including options to prevent monitor burn-in for
I
Letterbox or Pillarbox images:
Full
I
Letterbox, Pillarbox
I
Horizontal Zoom, Vertical Zoom, Horizontal and Vertical Zoom
I
You can also scale the selected (switched) HDMI video input to match the native resolution
of your display:
Using world-renowned Key Digital
I
technologies to deliver world-class scaling
Supports all popular source and display formats and resolutions
I
3. Operating the KD-VPHD4X1 Switcher Video Scaler and Video Processor.
The Video Scaler and Video Processor built into your KD-VPHD4X1 Switcher & Processor unit
is easy to operate. You can control these functions using the front-panel pushbutton switch-
es or your IR Remote Control, with instant feedback from the front-panel LCD display.
Use the "Menu" pushbutton, and "Arrow" keys to scroll through the Menu options. For each
input, first select the video format carried by your HDMI signal: either RGB or Component
(YPbPr). Each of the four (4) Inputs HDMI Inputs has a separate memory, so you can save
your preferred settings per input device. You can then select and store the following preferred
parameters for:
Brightness
I
Sharpness
I
Contrast
I
H-Size
I
TM (digital picture enhancement) and DEE
® Clear Matrix Pro
TM (digital edge enhancement)
TM and SDS TM (Super Digital Scaling)
