[PLL UNIT]
REF ORDER
NO. NO.
C195 4030011340 S.CERAMIC
C203 4030006880 S.CERAMIC
C222 4030006880 S.CERAMIC
C223 4030011600 S.CERAMIC
C224 4030011600 S.CERAMIC
C225 4030006940 S.CERAMIC
C226 4030006940 S.CERAMIC
C227 4030007100 S.CERAMIC
C228 4550002890 S.TANTALUM
J1 6510018960 S.CONNECTOR
J3 6510022000 S.CONNECTOR
J4 6510018960 S.CONNECTOR
W1 7030003860 S.JUMPER
W7 7030003860 S.JUMPER
W9 7030003860 S.JUMPER
W10 7030003860 S.JUMPER
W92 7030003860 S.JUMPER
W170 7030003860 S.JUMPER
WS1 8970023701 E.OTHER
WS2 8970023710 E.OTHER
EP1 0910052025 PCB
[PA UNIT]
REF ORDER
NO. NO.
Q1 1530000790 TRANSISTOR
Q2 1530000190 TRANSISTOR
Q3 1530000190 TRANSISTOR
Q4 1530000200 TRANSISTOR
Q5 1530000200 TRANSISTOR
Q6 1540000500 TRANSISTOR
Q7 1590001150 S.TRANSISTOR
D1 1790000710 VARISTOR
D2 1790000710 VARISTOR
D3 1790000710 VARISTOR
D4 1790000700 DIODE
D5 1790000700 DIODE
D6 1160000140 S.DIODE
D7 1730000480 S.ZENER
L1 6140002350 COIL
L2 6140002980 COIL
L3 6140003600 COIL
L4 6140003590 COIL
L5 6140003220 COIL
L6 6910000670 COIL
L7 6910000670 COIL
L8 6910000670 COIL
L14 6180001230 COIL
L19 6200003840 S.COIL
L20 6910000670 COIL
L21 6910000670 COIL
L22 2040000490 COIL
L23 2040000490 COIL
L24 6200003240 S.COIL
L25 6200003240 S.COIL
L26 6200008820 S.COIL
L27 6200008820 S.COIL
L30 2040000490 COIL
L31 2040000490 COIL
R1 7030003310 S.RESISTOR
R2 7030003360 S.RESISTOR
R3 7030003410 S.RESISTOR
R4 7030006210 S.RESISTOR
DESCRIPTION
C1608 CH 1H 471J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 CH 1H 030C-T-A
C1608 CH 1H 030C-T-A
C1608 CH 1H 560J-T-A
TESVA 1A 225M1-8L
B2B-PH-SM3-TB
16FMN-BMTTR-TBT
B2B-PH-SM3-TB
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
SX2241 0.8D COAXIAL TUBE (2)/PL
SX2241 ICOM SHIELD (1) /PL
B 5379E
DESCRIPTION
2SC1971
2SC3133
2SC3133
2SC2904
2SC2904
2SD1585K
UN9211 (TX)
MA29B
MA29B
MA29B
DSA3A1
DSA3A1
DAP222 TL
RD10M-T2B3
LR-274 (RIB4X7X5 3A6)
LR-143
LR-401
LR-400
LR-359 (SK-10M-15YY(120)
BL01RN1-A62-001
BL01RN1-A62-001
BL01RN1-A62-001
LAL 04NA 8R2K
MLF2012D R22K-T
BL01RN1-A62-001
BL01RN1-A62-001
EXC-ELDR25C
EXC-ELDR25C
NL 322522T-221J
NL 322522T-221J
HF70ACC 635050-T
HF70ACC 635050-T
EXC-ELDR25C
EXC-ELDR25C
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERJ12YJ4R7U (4.7 Ω)
[PA UNIT]
REF ORDER
NO. NO.
R5 7030006250 S.RESISTOR
R6 7030003420 S.RESISTOR
R7 7030000220 S.RESISTOR
R8 7030000220 S.RESISTOR
R9 7030009230 S.RESISTOR
R10 7030009230 S.RESISTOR
R11 7030004040 S.RESISTOR
R12 7030003440 S.RESISTOR
R13 7030003440 S.RESISTOR
R15 7030008000 S.RESISTOR
R16 7030008000 S.RESISTOR
R17 7030006060 S.RESISTOR
R18 7030006060 S.RESISTOR
R20 7030006070 S.RESISTOR
R21 7310003750 TRIMMER
R22 7030006130 S.RESISTOR
R23 7030009220 S.RESISTOR
R24 7310003240 TRIMMER
R25 7100000640 RESISTOR
R26 7030003440 S.RESISTOR
R27 7030003440 S.RESISTOR
R28 7030004040 S.RESISTOR
R29 7030003420 S.RESISTOR
R30 7510000130 THERMISTOR
R31 7030003470 S.RESISTOR
R32 7030006130 S.RESISTOR
R33 7030006130 S.RESISTOR
R34 7030008000 S.RESISTOR
R35 7030008000 S.RESISTOR
R36 7030008000 S.RESISTOR
R37 7030008000 S.RESISTOR
C1 4030006880 S.CERAMIC
C2 4030004720 S.CERAMIC
C3 4030004740 S.CERAMIC
C4 4030005110 S.CERAMIC
C5 4030012490 S.CERAMIC
C6 4030012490 S.CERAMIC
C8 4030011260 S.CERAMIC
C9 4010005930 CERAMIC
C11 4030011260 S.CERAMIC
C13 4010005870 CERAMIC
C14 4010005870 CERAMIC
C15 4320000650 DIP MICA
C16 4320000780 DIP MICA
C17 4030008920 S.CERAMIC
C19 4030008920 S.CERAMIC
C20 4510006230 S.ELECTROLYTIC ECEV1EA470UP
C21 4030005110 S.CERAMIC
C22 4030006860 S.CERAMIC
C23 4030008920 S.CERAMIC
C24 4030008920 S.CERAMIC
C25 4030008920 S.CERAMIC
C26 4510006230 S.ELECTROLYTIC ECEV1EA470UP
C27 4510004600 ELECTROLYTIC
C28 4030006880 S.CERAMIC
C29 4030011600 S.CERAMIC
C30 4030007170 S.CERAMIC
C31 4030005110 S.CERAMIC
C32 4510004600 ELECTROLYTIC
C33 4030006880 S.CERAMIC
C34 4030007170 S.CERAMIC
C35 4030006480 S.CERAMIC
C38 4030011600 S.CERAMIC
C39 4030008920 S.CERAMIC
C42 4510004600 ELECTROLYTIC
C45 4030006880 S.CERAMIC
C46 4030006880 S.CERAMIC
C47 4030006880 S.CERAMIC
C48 4030006480 S.CERAMIC
C49 4030007120 S.CERAMIC
C50 4030007120 S.CERAMIC
C51 4030008920 S.CERAMIC
C52 4030008920 S.CERAMIC
C53 4030008920 S.CERAMIC
C54 4030008920 S.CERAMIC
C55 4030006880 S.CERAMIC
C56 4030006880 S.CERAMIC
C57 4030006880 S.CERAMIC
C68 4030011740 S.CERAMIC
C69 4030011740 S.CERAMIC
6 - 12
DESCRIPTION
ERJ12YJ271U (270 Ω)
ERJ3GEYJ 681 V (680 Ω)
MCR10EZHJ 47 Ω (470)
MCR10EZHJ 47 Ω (470)
ERJ1WYJ121U (120 Ω)
ERJ1WYJ121U (120 Ω)
ERJ3GEYJ 4R7 V (4.7 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ1WYJ3R3U (3.3 Ω)
ERJ1WYJ3R3U (3.3 Ω)
ERJ12YJ100U (10 Ω)
ERJ12YJ100U (10 Ω)
ERJ12YJ101U (100 Ω)
EVN-2ACA00 B52 (501)
ERJ1WYJ100U (10 Ω)
ERJ12YJ561U
EVN-2ACA00 B23 (202)
5 SI 0.012 Ω (J)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 4R7 V (4.7 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERT-D2FHL 333S
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ1WYJ100U (10 Ω)
ERJ1WYJ100U (10 Ω)
ERJ1WYJ3R3U (3.3 Ω)
ERJ1WYJ3R3U (3.3 Ω)
ERJ1WYJ3R3U (3.3 Ω)
ERJ1WYJ3R3U (3.3 Ω)
C1608 JB 1H 472K-T-A
C2012 JB 1H 102K-T-A
C2012 JB 1H 472K-T-A
C2012 JB 1E 473K-T-A
GRM42-6 SL 472J 100PT
GRM42-6 SL 472J 100PT
GRM42-6 W5R 102K 500PT
HM11SJ SL 391J 500V
GRM42-6 W5R 102K 500PT
HM95SJ SL 221J 500V
HM95SJ SL 221J 500V
KD20C 102J5
KD19C 821J5
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C2012 JB 1E 473K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
16 MV 1000 HC
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 221J-T-A
C2012 JB 1E 473K-T-A
16 MV 1000 HC
C1608 JB 1H 472K-T-A
C1608 CH 1H 221J-T-A
GRM42-6 B 104K 50PT
C1608 JB 1C 104KT-N
C1608 JB 1C 473K-T-A
16 MV 1000 HC
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
GRM42-6 B 104K 50PT
C1608 CH 1H 820J-T-A
C1608 CH 1H 820J-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
GRM42-2 CH 201J 500PT
GRM42-2 CH 201J 500PT
S.=Surface mount
