6. EXTERN L CHIME TERMIN L
These terminals are provided for connection of an external chime generator, such as the Inter-M PE-9103N. It
may also be used for remote control of the chime signal.
7. TELEPHONE IN TERMIN L
These terminals are used to connect to a telephone exchange system for paging purposes.
NOTE: When signal is present on the Telephone Input terminal, all other input signals (except Mic 1 and
Chime) are muted.
8. MUSIC-ON-HOLD/TEL IN LEVEL CONTROLS
The Tel In Control regulates the volume of the signal from an external telephone signal connected to the Tel In
Terminal.
The Music-on-Hold Control regulates the volume of the signal from the internal tuner (P -1000BR only), as fed
to the telephone connection.
9. LINE IN/OUT J CKS
These are line-level input and output on unbalanced RC
such as CD or cassette deck.
10. UX INPUT
Input on unbalanced 1/4" phone jack accepts a standard line-level input. The level of this input is controlled
by the front-panel ux Level control.
11. MIC 2 INPUTS
Inputs on balanced XLR and 1/4" phone jacks accept a standard mic-level or line-level input. The level of this
input is controlled by the front-panel Mic 2 Level control.
12. MUTE CONTROL
When signal is present at Mic 1 or Chime input, all other inputs are muted. This control adjusts the level of
Mic 1 and Chime output when muting is in use.
13. MIC 1 INPUTS
Inputs on balanced XLR and 1/4" phone jacks accept a standard mic-level or line-level input. The level of this
input is controlled by the front-panel Mic 1 Level control.
PUBLIC DDRESS MPLIFIER/RECEIVER
jacks, provided for connection of external sources
P -1000B/1000BR
