Connecting Speakers
Connecting Speakers
Before connecting speakers disconnect the
than the rated impedance indicated.
For 4 low-impedance speakers, connect in parallel, with the negative (-) connectors to the COM terminal and
the positive (+) connectors to the 4
For 8 low-impedance speakers, connect in parallel, with the negative (-) connectors to the COM terminal and
the positive (+) connectors to the 8
FOR 4 TERMIN L
For high-voltage distributed systems, connect with matching transformer as per Figures 2-3 and 2-4 below. Be
certain that the total impedance does not equal less than the rated impedance.
FOR 25V TERMIN L
Be sure that total impedance is not less than rated impedance.
(US /C N D & ssociated Version)
C power cable. Make certain that the total impedance is not less
terminal. See Figure 2-1 below.
terminal. See Figure 2-2 below.
(Figure 2-1)
(Figure 2-3)
PUBLIC DDRESS MPLIFIER/RECEIVER
FOR 8 TERMIN L
(Figure 2-2)
FOR 70V TERMIN L
Be sure that total impedance is not less than rated impedance.
(Figure 2-4)
P -1000B/1000BR
9
