Connecting the Cables

Caution: Be sure the power switch is turned off before
Power
RS-232 Interface Connection
Printer
DB-9M
Pin
1 N/C
2.RXD
3 TXD
4 DTR
5 SIG. GND.
6 DSR
(TTL FORM IN)
7 RTS
8 CTS
(TTL OPTION)
9. N/C
Pin # Signal Name
1 Ground
2 Cash Drawer drive #1
3 Cash Drawer Sense
4 Cash Drawer +24V
5 Cash Drawer drive #2
6 COM
Warning: use of incompatible cables can damage the printer and will void
the warranty.
When purchasing a cash drawer for this product please make sure the vendor is
aware of the product specifications.

connecting cables.

USB
←
→
→
←
←
→
→
←
→
Signal Source
Printer

Cash Drawer

Printer
Printer
Cash Drawer
Serial
Computer
DB-9M
1 N/C
3
2
6
5
4
8
7
N/C
Description
Ground
Drive for Cash Drawer 1
Cash Draw Switch
Drawer supply side.
Drive for Cash Drawer 2
Cash Sense Return (Gnd)
Cash Drawer
123456
