Page 1: Setup Guide
5300 Transaction Printer: Setup Guide Pertech � 220322A 5350 7/05 Rev. 01 220322A 5300 11/05 Rev. 04... -
Page 2: Unpacking The Printer
Unpacking the Printer Save all packing materials in case you need to repack the printer. To report a printer that was damaged during shipping, see “Contact Information” on the last page of this Guide. Ink Jet Packaging To repack the printer, consult the above illustration and use the origi- nal packing materials. -
Page 3: Connecting The Cables
Connecting the Cables Caution: Be sure the power switch is turned off before connecting cables. Power Serial Cash Drawer RS-232 Interface Connection Printer Computer DB-9M DB-9M 1 N/C 1 N/C 2.RXD ← 3 TXD → 4 DTR → 5 SIG. GND. ←... -
Page 4: Printer Controls
Printer Controls The 5300 printer includes the following controls : •Paper feed button used to advance paper. •Power switch used to turn the printer on and off. Installing the Print Cartridge Press the Power Switch to turn on the printer. -
Page 5: Loading Paper
LED Indicators ����� ����� ��� ��� ����� ���� The 5300 series printers are equipped with two color led indicators that identify Paper, Error, Ink Low, Form In, and Power On conditions. Status Left LED Right LED Power On Green... - Page 6 Release the Paper Feed Button after 4 seconds for the printing to begin. The 5300 completes a test of RAM , a checksum test of program memory, homing and maintenance of the print head and then prints the configuration settings.
- Page 7 5351 Ink jet Configuration Report Different Models and Compatibility Modes may have additional Serial Number: options not listed. ******** Main Firmware Revision: * ** *** CRC: Options for 5351 ACL Compatibility **** Boot Firmware Revision: Mode listed below. * ** *** CRC: ����...
- Page 8 Preventive Maintance There is no customer maintenance required for the 5300 printers. However, printers gather paper dust and other debris through normal use, continued accumulation can eventually lead to printer issues. A general preventive maintenance program can help reduce unnecessary failures and downtime.
-
Page 9: Industry Canada
A shielded (360 degree) interface cable must be used with this product. The shield must be connected to the frame or earth ground reference at each end of the cable. Use of a cable other than the described here will require that you test this cable with the Pertech printer and your system for FCC and CE mark certification.
