Table of Contents

BEFORE YOU BEGIN

Read these instructions completely and carefully.
IMPOR
IMPOR
IMPORT T T T T ANT
ANT
ANT
• IMPOR
IMPOR
ANT
ANT- Save these instructions for local inspector's
use.
IMPOR
IMPOR
IMPORT T T T T ANT
ANT
ANT
• IMPOR
IMPOR
ANT- Observe all governing codes and ordinances.
ANT
• Note to Installer - Be sure to leave these instructions with
the customer.
• Note to Customer - Keep these instructions with your Use
and Care Book for future reference.
• Before the appliance is removed from service or discarded,
remove the washer and dryer doors.
• Inspect the dryer exhaust outlet and straighten the outlet
walls if they are bent.
• Service information and the wiring diagram are located at
the access panel.
• Do not allow children on or in the appliance. Close supervi-
sion of children is necessary when the appliance is used
near children.
• Install the appliance where the temperature is above 50°F
for satisfactory operation of the control system.
T T T T T ools Y
ools Y
ools You W
ools Y
ools Y
ou W
ou Will Need
ou W
ou W
ill Need
ill Need
ill Need
ill Need
Slip Pliers
Flat-blade Screwdriver
WARNING RISK OF FIRE
• To reduce the risk of severe injury or death, follow all in-
stallation instructions.
• Appliance installation must be performed by a qualified in-
staller.
• Install the appliance according to these instructions and in
accordance with local codes.
• This appliance must be exhausted to the outdoors.
• Use only 4" rigid metal ducting for exhausting the clothes
dryer to the outdoors.
INSTALLA
INST
INST
ALLATION INSTRUCTIONS
ALLA
ALLA
TION INSTRUCTIONS
TION INSTRUCTIONS
TION INSTRUCTIONS
INST
INST
ALLA
TION INSTRUCTIONS
Phillips Screwdriver
1/4” Nutdriver
Level
• DO NOT install a clothes dryer with flexible plastic ducting
materials. If flexible metal (semi-rigid or foil-type) duct is
installed, it must be UL listed and installed in accordance
with the instructions found in the section "Connecting The
Dryer To House Vent". Flexible venting materials are known
to collapse, be easily crushed, and trap lint. These condi-
tions will obstruct dryer airflow and increase the risk of fire.
• Do not install or store this appliance in any location where
it could be exposed to water and or weather.
• Save these instructions. (Installers: Be sure to leave these in-
structions with the customer).
NOTE: Installation and service of this appliance requires ba-
sic mechanical and electrical skills. It is your responsibility to
contact a qualified installer to make the electrical connec-
tions.
Materials You W
Materials Y
Materials Y
ou W
ou Will Need
ou W
ill Need
ill Need
ill Need
Materials Y
Materials Y
ou W
ill Need
4” Dia. Metal Duct
(Recommended)
4” Duct
Clamps (2)
4” Spring
Clamps (2)
4” Dia. Flexible Metal (Semi-Rigid)
UL Listed Transition Duct (If
Needed) Kit WX08X10077
(Includes 2 Elbows)
4” Dia. Flexible Metal (Foil Type)
UL Listed Transition Duct
(If Needed)
Appliance Power
(Not Provided)
Parts Supplied
Parts Supplied
Parts Supplied
Parts Supplied
Parts Supplied
2 Rubber Washers
(washers may be
2 Washer Hoses
4” Dia. Metal
Exhaust
Elbow
Hood
or
3/4” Strain
Relief
Gloves
UL Recognized
4” Cover Plate (If Needed)
Safety Glasses
(Kit WE1M454)
UL Rated 120/240 V, 30 A
With 3 or 4 Prongs. Identify the
Plug Type as Per the House
Receptacle Before Purchasing
Line Cord.
Cord Kit
2 Stainer Screens/
Ruber Washers
in water hoses)
1 Cable Tie
Duct Tape
