STONE-FIRED COOKING EQUIPMENT
Wood Stone Mountain Series
WS-MH-RFG-IR
Installation and Operation Manual
Keep this manual for future reference.
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property damage,
!
personal injury or death.
Do not store gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Keep the area under and around this appliance free and clear of
any and all combustible materials.
1801 W. Bakerview Rd. Bellingham WA 98226 USA
Tel. 360-650-1111
Fx. 360-650-1166
www.woodstonehome.com
Revised September 2006
Advertisement
Table of Contents
Related Manuals for Wood Stone WS-MH-RFG-IR
Summary of Contents for Wood Stone WS-MH-RFG-IR
- Page 1 STONE-FIRED COOKING EQUIPMENT Wood Stone Mountain Series WS-MH-RFG-IR Installation and Operation Manual Keep this manual for future reference. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death.
- Page 2 Services, (ETL SEMKO) to the specifications of ANSI Z21.1- 2005 WARNING This product must be installed by a Licensed Plumber or Gas Fitter when installed within the Commonwealth Of Massachusetts. Wood Stone Corporation 1801 W. Bakerview Rd. Bellingham WA 98226...
-
Page 3: Unloading And Moving
4x4 post DO NOT TURN THE APPLIANCE ON ITS SIDE! Contact Wood Stone if the appliance must be turned on its side for specific instructions. Moving a Wood Stone oven can present interesting challenges to even the most experienced riggers. -
Page 4: Installation Clearances
CLEARANCES a. The Wood Stone MH-RFG-IR should have a minimum 1'’ clearance to combustibles from all sides, and 6" clearance to combustibles from the top (See Figures 1a. and 1b on page 6). If building a facade that will contact the appliance, use completely non- combustible materials*. - Page 5 1 2 3 4 5 6 7 8 9 above and 6" to either side of 1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9 the oven doorway. September Questions? Call Wood Stone at 800-578-6836 2006...
-
Page 6: Facade Details
1 2 3 4 5 6 7 1 2 3 4 5 6 7 doorway must be constructed of non-combustible building materials. All surfaces in this area should also be easily cleanable. September Questions? Call Wood Stone at 800-578-6836 2006... -
Page 7: Gas Specifications
MH-RFG-IR Installation and Operation Manual GAS SPECIFICATIONS The Wood Stone Gas ovens are equipped with a 3/4" NPT gas connection. Have a licensed gas installer provide the hook-up and test all fittings and pipe connections for leaks. Use approved gas leak detectors (soap solutions or equivalent) over and around the fittings and pipe connections. - Page 8 MH-RFG-IR Installation and Operation Manual GAS SPECIFICATIONS Hourly Natural Gas BTU input rates for Wood Stone gas ovens Model Hourly BTU Input Rate WS-MS-4-RFG-IR-NG 115,000 WS-MS-5-RFG-IR-NG 188,000 WS-MS-6-RFG-IR-NG 188,000 WS-MS-7-RFG-IR-NG 220,000 Hourly Propane BTU input rates for Wood Stone gas ovens...
-
Page 9: Electrical Specifications
3 prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle. Do not cut or remove the grounding prong from the plug. September Questions? Call Wood Stone at 800-578-6836 2006... - Page 10 500 and 700 CFM. Wood Stone provides a port in the flue collar of the oven for insertion of a magnehelic gauge so the installer can monitor the draft to ensure proper operation of the venting system.
- Page 11 Views of installation of a Wood Stone hood. Note that the notch of the hood is even with the front edge of the oven. Hood may be moved forward slightly if needed. The hood should be installed in accordance with the hood manufacturer's instructions, and with NFPA 96 and/or the applicable local and national codes.
- Page 12 4. The following applies to stucco finish ovens only (Models ending with S): a. Once the oven has been set in place, cover wire mesh and metal lathing with no less than one inch of stucco (see page 16 for diagram and stucco formulae). September Questions? Call Wood Stone at 800-578-6836 2006...
-
Page 13: Mantle Mounting
Allow the adhesive to set for several hours before filling any gap between the stone slab and the metal bracket with the silicone compound (provided). Clean up any adhesive and/or silicone before it dries! September Questions? Call Wood Stone at 800-578-6836 2006... - Page 14 Throttle Rod Extension position. Be sure to retighten the clamp once the throttle knob is in the desired position. Cotter Key Throttle Valve September Questions? Call Wood Stone at 800-578-6836 2006...
- Page 15 MH-RFG-IR Installation and Operation Manual ASSEMBLY Ovens Equipped With Optional Lower Extension September Questions? Call Wood Stone at 800-578-6836 2006...
- Page 16 2 parts sand MINIMUM STUCCO APPLICATION IS 1" This figure depicts the application of stucco. Use no less than one inch of stucco coating to cover all exposed metal lathing on the oven. September Questions? Call Wood Stone at 800-578-6836 2006...
-
Page 17: Initial Start-Up
Note: small "crazing" cracks will occur with normal heating and cooling. They will not effect the performance or durability of the appliance. If cracks of 1/8" or more develop, contact Wood Stone for evaluation. Never run the appliance with the night door(s) in place. - Page 18 This burner is the primary heat source. The infrared under floor burner acts as an assist, to speed heat up and to maintain desired floor temperatures during periods of high food production. September Questions? Call Wood Stone at 800-578-6836 2006...
-
Page 19: Oven Operation
For additional operational and cooking information please visit www.woodstone-corp. com or call Wood Stone! NIGHT DOORS: The door(s) are used for nighttime heat retention. Do not operate the appliance with doors in place. -
Page 20: Controller Diagram
Presser le bouton Presser le bouton ON/OFF pour ON/OFF pour arreter le bruleur allumer le bruleur. WAIT 5 MINUTES BEFORE RELIGHTING ATTENDRE 5 MINUTES AVANT DE RÉALLUMER 1-800-988-8103 www.woodstone-corp.com September Questions? Call Wood Stone at 800-578-6836 2006... -
Page 21: Daily Maintenance
DAILY MAINTENANCE: Cooking Chamber Wood Stone recommends the use of a long-handled, brass bristled brush for sweeping aside excess food particles that will accumulate on the ceramic floor of the appliance during use. The floor can be cleaned with a damp rag. -
Page 22: Periodic Thermal Cleaning
600 degrees for about an hour. Once the floor and dome appears clean, allow the oven to return to normal operating temperatures and continue normal operation. September Questions? Call Wood Stone at 800-578-6836 2006... - Page 23 Contact Wood Stone for assistance. Please contact Wood Stone at 1-800-578-6836 should service be necessary, or if you have any questions about the appliance. Our office hours are 8am to 4:30pm West Coast time.
-
Page 24: Electrical Diagram
MH-RFG-IR Installation and Operation Manual ELECTRICAL DIAGRAM September Questions? Call Wood Stone at 800-578-6836 2006... -
Page 25: Operation Sequence
‘chec’ heat light on, SV1 opens, underfloor burner lights Floor reaches the set point Temp. Controller turns off power to SV1 and underfloor burner shuts off. September Questions? Call Wood Stone at 800-578-6836 2006... - Page 26 No other connection to the appliance control system is condoned by Wood Stone and may affect the warranty and cause damage to the controls. September Questions? Call Wood Stone at 800-578-6836 2006...
-
Page 27: Limited Warranty
LIMITATIONS OF LIABILITY: In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof. Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser.
