Page 1: Ceiling Fan
CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: 54-660-5WA-25 54-660-5MP-188 FAN RATING AC 120V. 60Hz CUL LISTED MODEL : AC-552A... -
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Set of blades (5) b. Hanger bracket assembly c. -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, insure To avoid personal injury or damage to the electricity has been turned off at the circuit fan and other items, be cautious when breaker or fuse box before beginning. working around or cleaning the fan. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. appropriate fasteners and building materials. -
Page 5: Hanging The Fan
5. HANGING THE FAN Hanger REMEMBER to turn off the power. Follow bracket the steps below to hang your fan properly: Ceiling canopy Step 1. Remove the decorative canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Canopy cover Figure 5... -
Page 6: Installation Of Safety Support
6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to Hanger bracket Safety cable prevent the fan from falling. Secure the safety cable to the ceiling joist with screw and washer, as illustrated in Figure 9. Figure 9 7. - Page 7 Step 3. (Fig. 12 and 13) Receiver to House Supply Wires Electrical Connections: Outlet box Connect the black (hot) wire from the ceiling to the black wire marked "AC in L" White (neutral) Black (hot) Green or bare from the receiver. Connect the white copper (ground) Black ("AC IN L") (neutral) wire from the ceiling to the white...
-
Page 8: Installing The Wall Transmitter
8. INSTALLING THE WALL TRANSMITTER REMEMBER to Shut the Power Off at the Circuit Breaker or Fuse Box. WARNING: HOOK UP IN "SERIES ONLY" DO NOT CONNECT THE HOT AND NEUTRAL WIRES OF ELECTRIC CIRCUIT TO THE TRANSMITTER WALL SWITCH - DAMAGE TO THE SWITCH AND POSSIBLE FIRE COULD OCCUR. -
Page 9: Installing The Decorative Scroll
10. INSTALLING THE DECORATIVE SCROLL Screws Decorative Step 1. Place the ring at the end of the scroll arms decorative scroll arm to the frame on top of the motor housing and secure tighten the top of decorative scroll to the decorative Decorative scroll ring with the screw provided on the scroll ring... -
Page 10: Installing The Light Kit
12. INSTALLATING THE MOUNTING PLATE 1. Remove the 1 of 3 screws from the mounting ring and loosen the other 2 screws. (Do not remove) 2. Place the key holes on the mounting plate over the 2 screws previously loosened from the mounting ring, turn mounting plate until it locks in place at the Mounting ring narrow section of the key holes. -
Page 11: Installing The Light Bulbs & Glass Shade
14. INSTALLING THE LIGHT BULBS & GLASS SHADE 1. Install 3 x 40W (MAX.) candelabra bulbs (provided). 2. Remove the decorative nut, glass cap and metal nut from the light kit. Place glass shade over the light kit stem, secure with the metal nut (rubber side on the top), glass cap and decorative nut. - Page 12 The Reverse switch is located on the top of the motor housing. Slide the switch to the Left for warm weather operation. Slide the switch to the Right for cool weather operation. Speed setting for warm or cool weather depend on factors such as the room size. Ceiling height, number of fans and so on.
-
Page 13: Troubleshooting
16. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
