Page 1: User Manual
MPC-50A 10.4"LCD Panel PC User Manual Version 1.1 August 18, 2003... - Page 2 Trademarks MPC-50A is a registered trademark of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 PRODUCT INFORMATION................4 ENERAL NFORMATION ......................4 RODUCT PECIFICATIONS ......................4 HECK ..........................5 ECHANICAL IMENSIONS ......................6 (MPC-50A) ....................6 ISPLAY ODULE CHAPTER 2 SYSTEM SETUP ....................6 MPC-50A P PC I ANEL NSTALLATION ..................7 RIVE NSTALLATION .....................8 OWER UPPLY NSTALLATION ....................9... -
Page 4: Chapter 1 Product Information
Product Information General Information The MPC-50A, 10.4”TFT LCD 4-slot Panel PC, takes advantages of modern flat-panel displays technology. It consists of a CPU board, a power supply and a passive backplane for minimum size. It is an IBM PC/AT compatible computer specially designed to meet the applications for industrial environments. -
Page 5: Check List
Plug-in Card Size Maximum card size is 226mm Industrial Power Supply Type:ACE-816AP (ATX), 150 Watt ACE-916AP (AT), 150 Watt Shock: 10 G peaks acceleration (11 msec duration) Safety: meet UL/CSA/TUV EMI: meet FCC/CISPR class B Environmental specifications Operating Temperature : 0 ~ 50¢ J Relative Humidity: 10-95% @40 ¢... -
Page 6: Mechanical Dimensions
Mechanical Dimensions The following diagram indicates the dimensions of MPC-50A. Front panel: 312(W) x 242(H) x 9(D)mm Cabinet: 288(W) x 218(H) x 212(D) mm 288.0 273.0 (227.1) 100.0 100.0 211.9 Unit :mm 311.9 Display Module (MPC-50A) -
Page 7: Chapter 2 System Setup
Chapter 2 System Setup The MPC-50A(10.4.") LCD 4-slot Panel PC is easy to setup for operation. The following sections demonstrate how to remove the upper cover, and then install backplane, CPU card, display control card, hard disk drive and other I/O cards required by the application. -
Page 8: Disk Drive Installation
Disk Drive Installation MPC-50A (10.4") provides one slim type CD-ROM drive space and Three 3.5” drive spaces. The following diagram shows how to install the slim CD-ROM drive and the 3.5" FDD. For installing the two 3.5" HDDs, please remove the bottom panel by releasing the... -
Page 9: Power Supply Installation
4 screws as the diagram shown below. Cooling Fan Installation MPC-50A is equipped with one 80mm cooling fan for system. The following diagram indicates the location of the fan. Warning: Do not use the wet filter to filter out the dirt. -
Page 10: Backplane And Cpu Card Installation
Backplane and CPU Card Installation The figure below illustrates how to install the Backplane and CPU card on the MPC-50A. Cover Installation Figure below illustrates how to install the cover on the MPC-50A. -
Page 11: Panel Mounting
Panel Mounting MPC-50A can be mounted within a panel as the diagram below shown. Please make sure the dimension of the case is within panel aperture so that the holes of screws match with the mounting bolts on the flange of MPC-50A. -
Page 12: Appendix Apower Supply Specification
Appendix A Power Supply Specification. This chapter provides detailed information of the power supply. ACE-816AP OUTPUT RATING Output Nominal Regulation Ripple/Noise ± +3.3V 50mV 0.3A 10.0A ± 50mV 1.0A 14.0A ± +12V 120mV 0.3A 4.2A ± -12V 120mV 0.0A 0.3A ±... -
Page 13: Appendix Buser Mode Osd Item Description
Appendix B User Mode OSD Item Description Auto-Adjustment This item will automatically adjust the H/V position, frequency, phase, and black level. Auto Phase This item will automatically adjust the sampling. Brightness It is used to adjust the brightness of screen. This function will adjust the offset value of ADC. - Page 14 DOS/GFX It is used to choose VGA input signal that are text mode or graphic mode. ( It is only selectable on resolution of 720/640x400 or 720/640x350 . ) 400 and 350 standard IBM mode have the same Hsync. and Vsync. Value. AV-9261 MPU can not differentiate them automatically , user need to adjust them manually to match proper VGA mode .
- Page 15 Save It is used to save the parameters into the user OSD adjustment data area of the system EEPROM 24c16 device and close OSD. Whenever user adjusts any parameters, it is needed to execute this item to save data into EEPROM. And next time power on, the MPU will use the storied data to initialize the AV-9261 system.
-
Page 16: Appendix Cdimensions Of Backplanes
Appendix C Dimensions of Backplanes 96.29 91.34 4-O4.0 71.15 50.83 30.51 10.19 4.95 Utin:mm BP-4S 96.37 91.36 86.89 4-O4.0 66.57 46.25 10.36 Unit:mm IP-4S... - Page 17 96.37 96.37 91.36 91.36 86.89 66.57 53.11 IP-4S2 31.95 4-O4 Holes 10.36 IP-4S2 Unit:mm 96.37 91.36 91.36 86.89 59.99 46.25 10.36 IP-4SA Unit:mm...
