  • Page 1 Installation and operating manual MobiSet 2 digital CAP 600...

  • Page 2: Table Of Contents

    ... 2 CONTENTS FOREIGN LANGUAGE INSTALLATION MANUAL/DISPOSAL MOBISET 2 CAP 600 COMPONENTS/SCOPE OF DELIVERY ... 5 PROPER USE SAFETY INSTRUCTIONS - IMPORTANT NOTES INSTALLATION AND CONNECTION INSTALLATION OF CABLE GLAND AND MOUNTING PLATE INSTALLATION OF TURNTABLE BRIEF INSTRUCTIONS FOR INSTALLING THE TURNTABLE INSTALLATION OF THE UFS 740SW RECEIVER LAYING CABLES AND CONNECTING THE TURNTABLE CONNECTING TO THE UFS 740SW...

  • Page 3: Foreign Language Installation Manual/Disposal

    (http://www.kathrein.de/en/sat/products/franzoesisch.htm). Lei puo avvere la versione italiana delle istruzioni di montaggio dalla nostra rapresentanza (http://www. kathrein.de/include/kontakte_groups_eng.cfm?kontinent=1&gruppe=SAT) piu vicina della sua citta´, oppure scaricarla dalla nostra hompage http://www.kathrein.de/en/sat/products/italienisch.htm) Para obtener la versión española de nuestro manual de instalación, contacte nuestros representantes en su país (http://www.kathrein.de/include/kontakte_groups_eng.cfm?kontinent=1&gruppe=SAT) o bajela de...

  • Page 4: Mobiset 2 Cap 600 Components/Scope Of Delivery

    291 adhesive sealant (100 ml tube) • UFS 740sw DVB-S receiver with connecting cables, infrared sensor and infrared remote control • MobiSet 2 digital CAP 600 installation and operating manual • UFS 740sw satellite receiver operating manual UFS 740sw (Front view)

  • Page 5: Proper Use

    PROPER USE (USE FOR THE INTENDED PURPOSE) The MobiSet 2 digital CAP 600 is designed to receive digital TV and radio programs via satellite. The automatic positioner is intended to be used as a turntable for the Kathrein satellite dish.

  • Page 6: Safety Instructions - Important Notes

    SAFETY INSTRUCTIONS - IMPORTANT NOTES When carrying out installation work in locations where there is a risk of falling, take appropriate safety precautions, e.g. use of a working platform. Make sure that the vehicle roof is suffi ciently strong and stable to carry out the installation work (risk of damage or collapsing of roof). In case of doubt, contact a qualifi...
  • Page 7 SAFETY INSTRUCTIONS - IMPORTANT NOTES Road Traffi c Licensing Regulations (StVZO) The applicable regulations of the StVZO must be observed in respect of fi xed installation of the turntable on a vehicle which is driven on public highways. In particular, §§ 19/2; 30 C; 32 (2) and the EC directive 74/483 EEC are applicable. Briefl...
  • Page 8 SAFETY INSTRUCTIONS - IMPORTANT NOTES The antenna will be lowered within 12 seconds of the ignition being switched on (if the unit is in stand-by mode or the UFS 740sw is switched off). Otherwise the control unit that is in use is lowered immediately. Attention: Lowering the antenna can take up to 30 seconds after the ignition is switched on! •...

  • Page 9: Installation And Connection

    INSTALLATION AND CONNECTION REQUIRED TOOLS AND EQUIPMENT • Circular cutter, Ø 38 mm • Flat-bladed screwdriver for M5 screws • Power drill • Galvanised round head screws, depending on the roof structure (Ø: 5 mm, sheet metal screws D 7981, depending on the roof structure) or round head screws D 7985 with washers and nuts •...
  • Page 10 INSTALLATION AND CONNECTION • When selecting the installation position, take into account the range of movement of the turntable (see graphics and the “Technical Data” chapter). There must be no structures on the roof that would obstruct this range of movement (risk of collision). For safety, keep at least the required area free (for ease of installation and any subsequent dismantling).

  • Page 11: Installation Steps

    INSTALLATION OF CABLE GLAND AND MOUNTING PLATE Comment: If you had previously used a Kathrein HDM140/141 fl exible satellite mast or another mast with a diameter of 34 mm, you can continue using the existing gland hole in the roof (if space allows).
  • Page 12 INSTALLATION AND CONNECTION Figure: B • Mark the positions of the six fastening holes on the roof of the vehicle in a circular pattern. Note: The size of the holes and the choice of fastening screws to be used (not supplied) depend on the type and thickness of the materials used in the roof structure.
  • Page 13 INSTALLATION AND CONNECTION • Create the holes necessary to secure the mounting plate (Fig. C). • In addition to the screwed connection, the mounting plate and roof gland must be bonded to the roof with adhesive and sealed. This is done using the Sikafl ex ® 291 adhesive sealant supplied, which is ideally suited for this purpose due to its broad range of adhesion.

  • Page 14: Installation Of Turntable

    INSTALLATION AND CONNECTION • Ensure before starting adhesive work that the temperature of materials to be glued and the adhesive sealant is between +5 °C and +40 °C. Prepare all necessary fasteners and tools. • Prepare the tube of adhesive sealant in accordance with the instructions enclosed with the tube. •...
  • Page 15 INSTALLATION AND CONNECTION Figure: E Gasket with plug for the unused duct • Lift up the turntable and place it carefully on the mounting plate facing in the direction of travel (see illustration Fig. E) (do not step on the plug connector and do not kink/crush the cables!). The through holes on the turntable must be perfectly aligned with the threaded holes on the mounting plate.
  • Page 16 INSTALLATION AND CONNECTION VERSION WITH EXTERNAL CABLE GLAND (FIG. F) Not included! Watertight cable ducts are used in boating and yachting applications under the name “cable ports”; they can be purchased from boating and yachting chandlers. • The external cable gland should not be so far from the turntable that the junction between the two cables projecting from the turntable and the extension cables cannot lie within the interior of the vehicle.

  • Page 17: Brief Instructions For Installing The Turntable

    INSTALLATION AND CONNECTION BRIEF INSTRUCTIONS FOR INSTALLING THE TURNTABLE The sequence of pictures shown illustrates all the necessary installation steps that are required to install the turntable and the BAS 60 planar antenna on the roof of the vehicle. The other detailed instructions in this installation and operating manual must also be followed! For ease of illustration, we have dismounted the BAS 60 on these photographs.
  • Page 18 INSTALLATION AND CONNECTION Aligning the mounting plate. Arrow in the direction of travel. Mark out the six holes for securing the mounting plate. Place mounting plate on roof gland and secure with appropriate screws (choose screws according thickness/structure of roof). Making the electrical connections.

  • Page 19: Installation Of The Ufs 740Sw Receiver

    INSTALLATION AND CONNECTION INSTALLATION OF THE UFS 740SW RECEIVER The turntable is controlled by the UFS 740sw DVB-S receiver. The cable lengths must be taken into account when choosing the installation location. For suspended installation use the installation kit supplied with the receiver. Note: When choosing the installation location, bear in mind that the on/off switch and the slots for inserting common interface modules should always be accessible.
  • Page 20 INSTALLATION AND CONNECTION Remove the wood screws supplied from their transport attachment on the underside of the respective mounting piece (2 pieces). Vertically insert each mounting piece into the fi fth slot from the edge, as shown in Fig. 1. Then push each mounting piece downwards and outwards (see Fig.

  • Page 21: Laying Cables And Connecting The Turntable

    INSTALLATION AND CONNECTION LAYING CABLES AND CONNECTING THE TURNTABLE • Lay the coaxial cable to the UFS 740sw. • Lay the turntable power supply cable (3-pin plug) to the battery. Avoid laying the cables across sharp edges and secure the cables against possible chafi ng points.

  • Page 22: Functional Instructions For Connection To The On-Board Power Supply

    INSTALLATION AND CONNECTION Only for connection in a motor home, not in a caravan! • The third, green connecting cable, marked “IGNITION” allows you the option of connection to a circuit in the vehicle that is activated when the ignition key is turned and then carries a continuous 12 V supply. This type of connection ensures that when the engine is started the antenna is automatically lowered into the park position (the receiver does not need to be turned on).

  • Page 23: Connection Example For 12 V Battery Connection

    INSTALLATION AND CONNECTION CONNECTION EXAMPLE FOR 12 V BATTERY CONNECTION Figure: G Important: For operation with two batteries, it must be ensured that the ignition signal earth has the same potential as the power supply battery earth for the turntable. Non-compliance means that the automatic lowering function will not work!

  • Page 24: Reception Range/Footprint

    RECEPTION RANGE/FOOTPRINT The footprint is the reception area on the earth that a satellite covers with its transmission beam (spot), within which satellite reception is possible. The transmission power is at its greatest in the centre of this spot – it becomes progressively weaker moving outwards. You should preferably align your antenna to the position of the ASTRA satellite 19.2°...

  • Page 25: Dismantling For Servicing

    Before exchanging the UFS 740sw, fi rst move the turntable to the park position. ADDRESS OF THE SERVICE CENTRE Electronic Service Chiemgau GmbH Bahnhofstraße 108 83224 Grassau, Germany Phone: +49 8641 9545-0 Fax: +49 8641 9545-35 and -36 Internet: http://www.esc-kathrein.de e-mail: service@esc-kathrein.de...

  • Page 26: Polarisation Setting

    POLARISATION SETTING As supplied, the BAS 60 is mounted centrally on the turntable. In this position, you can also receive signals from satellites with deviations in the degree of longitude (of the typical reception range) of between 15° and 20° from the orbit position of the satellite.

  • Page 27: Safety Notes

    SAFETY NOTES We strongly advise that users who are not familiar with the installation work should not reassemble the BAS 60 independently. They should contact a technician or engineer. They may fi nd a suitable person on the campsite. Make sure that: - The antenna and connected units are disconnected from the power - The person carrying out the installation does not suffer from vertigo and can move around safely on the roof of the caravan or motor home...

  • Page 28: Installation Process

    INSTALLATION PROCESS The explanation of this installation process is based on the assumption that the entire CAP unit has been properly put together, installed and set up, as described in this installation manual. The safety instructions in the detailed operating manual for the UFS 740sw must also be followed! To dismantle/install the planar antenna from the turntable, proceed as follows: (the key names refer to the remote control for the UFS 740sw receiver) Turn on the receiver at the main switch on the front of the unit.
  • Page 29 15. Switch the receiver on fi rstly with the main switch and then with any of the numeric buttons. 16. You will then see the message “Please wait, initialising HDP”. Wait until the message “Position of Astra is not known. Start a search?” is displayed – cancel this procedure by pressing the 17.

  • Page 30: Manual Lowering To Park Position

    MANUAL LOWERING TO PARK POSITION If a defect arises in the electronic controls, after some disassembly work the satellite dish can be returned to the park position (horizontal position) manually. Following this however recalibration by an authorised workshop is always necessary. Driving to the nearest workshop with the antenna extended at a moderate speed and taking into account the increase (+ 72 cm) in the vehicle height is an option and is preferable to manual lowering.

  • Page 31: Manual Lowering

    MANUAL LOWERING TO PARK POSITION MANUAL LOWERING In the centre of the antenna (arrowed) there is a plastic cap. Lever this off with a narrow slot-head screwdriver. Behind the cap is an M8 hexagon head screw. Unscrew these using a 13 mm socket wrench. After removing the M8 screw, a further thread can be seen.

  • Page 32: Technical Data

    TECHNICAL DATA DIMENSIONS (MM) Direction of travel Mounting plate...
  • Page 33 TECHNICAL DATA Min. recommended clearance Ø 880 Rotary axis BAS 60 Mounting plate Roof gland Clamping range 20/50 Weight incl. BAS 60: approx. 13.8 kg...
  • Page 34 Type Order no. LNB supply voltage Input frequency Output frequency Oscillator frequency (L.O.) System quality (G/T) 11.3/12.5 GHz Power supply (vehicle battery) Power consumption from the 12 V vehicle electrical system: - Inrush current - Satellite search - TV reception - Stand-by Current consumption from the receiver Setting range:...

  • Page 35: Sikaflex ® 291 Safety Data Sheet

    SIKAFLEX ® 291 SAFETY DATA SHEET 1. Materials/preparation and company designation Data on the product (trade name): Data on manufacturer/suppliers Manufacturer/suppliers: Street/postcode: Postcode and town: Country: Germany Tel: General information: Emergency information hotline: 2. Composition/data on components Chemical characterisation: Hazardous contents (designation to 67/548/EEC) CAS-No.
  • Page 36 SIKAFLEX ® 291 SAFETY DATA SHEET 5. Measures for fi re fi ghting Suitable extinguishing media Compatible with all extinguishing media in general use. Special hazard from the product, its products of combustion or gases released In case of fi re the following can be released: Carbon monoxide (CO) Additional instructions Combustion residues and contaminated extinguishing media must be disposed of in accordance with the local authority regulations.
  • Page 37 SIKAFLEX ® 291 SAFETY DATA SHEET 4,4‘ methylene-diphenyl-diisocyanate 101-68-8 101-68-8 Xylol 1330-20-7 1330-20-7 1330-20-7 1330-20-7 1330-20-7 1330-20-7 Personal protective equipment General protective and hygiene measures Ensure suffi cient ventilation at the workplace. Avoid contact with the eyes and skin. Apply prophylactic skin protection by protective hand cream. Take off soiled clothing immediately.
  • Page 38 SIKAFLEX ® 291 SAFETY DATA SHEET 11. Toxicology data Sensitisation Sensitisation/allergic reactions may occur. Sensitive individuals may exhibit allergic reactions even at very low concentrations. Experience of human exposure On skin contact: On eye contact: On being breathed in: On being swallowed: 12.
  • Page 39 SIKAFLEX ® 291 SAFETY DATA SHEET Risk phrases Sensitisation possible by breathing in. Safety phrases Do not breathe in gas/smoke/vapour/aerosol. IN the event of accident or feeling unwell summon a doctor immediately (if possible show the doctor this label). Special identifi cation of particular components Contains isocyanates.

  • Page 40: Sikaflex ® 291 Technical Data Sheet

    SIKAFLEX Technisches Merkblatt Technical data sheet Version 12 / 2005 Version 12/2005 Sikafl ex Sikaflex Der haftstarke Marine-Dichtstoff The strongly bonding marine adhesive Technische Eigenschaften Technical characteristics Chemische Basis Chemical basis Farbe Colour Härtungsmechanismus Curing mechanism Dichte vor Aushärtung (DIN 53479) Density before curing (DIN 53479) Standfestigkeit Stability...
  • Page 41 ® SIKAFLEX 291 TECHNICAL DATA SHEET Die Vernetzungsreaktion von Si- The cross-linking reaction of Sikaf- ® kaflex -291 erfolgt mit Luftfeuch- ® 291 occurs in the presence of tigkeit. Bei niedriger Temperatur ist atmospheric moisture. At lower tem- der Wassergehalt der Luft geringer peratures the water content of the air und die Vernetzungsreaktion ver- is less and the cross-linking reaction...

  • Page 42: Cap 600 Operating Manual

    The Kathrein Customer Hotline is also at your disposal. Phone: +49 8031 184-700 The automatic updating of the EPG data described in the UFS 740sw operating...

  • Page 43: Important Information For Cap 600 Before Setup

    IMPORTANT INFORMATION FOR CAP 600 BEFORE SETUP This section of the UFS 740 operating manual for the turntable assumes that the UFS 740 and the turntable have been properly installed and connected, as described in the installation and operating manuals! If you have not yet done so, read the safety instructions at the beginning of the UFS 740sw operating manual and follow them when handling the UFS 740sw and the turntable!

  • Page 44: First Installation

    Before using your unit for the fi rst time, read the “Safety Instructions - Important Information” and “Installation and Connection” sections. You will fi nd a sample confi guration for a motor home in the Section “Installation and Connection”, “Connection Example”. Do not connect the unit to the power supply until all installation work has been properly carried out.
  • Page 45 The following display appears: Use the buttons here to select the settings for your TV set. When doing this, refer to the operating instructions for your TV set! TV aspect ratio Here you select the TV's picture format. Either 4:3 or 16:9 Picture format Here you select the type of screen display, depending on the setting of your TV format:...
  • Page 46 FIRST INSTALLATION The following display appears: System Use the buttons at “System” to select “CAP 600”. Then press the (green) button twice (Channel scan “item 4/5” is skipped). The following display appears: Local time offset Use the buttons to set the time zone variation from UTC (formerly GMT) (e.g. for Germany +1 hour). Use the buttons to switch to the “Automatic clock change”...

  • Page 47: Alignment (Satellite Search)

    ALIGNMENT (SATELLITE SEARCH) The antenna is aligned automatically. After the UFS 740 has been switched on, the turntable automatically moves to the last channel received and the associated satellite position (e.g. ARD/ASTRA). This works because every satellite broadcasts its own identifi cation signal, which is automatically identifi ed by the turntable.

  • Page 48: Manual Correction

    ALIGNMENT (SATELLITE SEARCH) MANUAL CORRECTION At the margins of the footprints of a satellite (e.g. after a slight change of position), it may be necessary for you to manually correct the setting (not normally required). It is also possible to manually correct the fi ne tuning.

  • Page 49: Channel (Satellite) Selection

    CHANNEL (SATELLITE) SELECTION By pressing the buttons all channels can be selected in the sequence that they appear in the current channel list and its sorting. Press the CHANNEL SELECTION FROM THE CHANNEL LIST Providing you are not in a menu, pressing the appears: Also attention...

  • Page 50: Change Of Location/Timer Programming

    CHANGE OF LOCATION/TIMER PROGRAMMING After a change of location, the antenna moves to the last position selected. After initialisation, you will therefore see the following display (example, as it depends on the last selected position): For slight changes of location, the antenna can fi...

  • Page 51: Reset/Parking

    RESETTING THE MOTORISED ANTENNA Press the button to return to the main menu. By using the up sub-menus (“Settings”, “Antenna Confi guration”). Use the buttons to move to the “Reset the motorised antenna” menu item and then press button. The following display appears: Press the button to confi...

  • Page 52: Parking The Turntable

    PARKING THE TURNTABLE You have three options for “parking” the antenna. The antenna can be moved to park position by pressing the Press the button to return to the main menu. By using the can call up the sub-menus (“Settings”, “Antenna Confi guration”). Use the “Move to park position”...

  • Page 53: Special Messages From The Turntable

    SPECIAL MESSAGES FROM THE TURNTABLE SYSTEM PROTECTION MESSAGES The following messages are shown on the screen to protect your reception system and the on-board power supply: The power supply to the turntable is insuffi cient (battery voltage below minimum value). The turntable can still be moved, but communication errors can occur between the UFS 740sw and the turntable (e.g.
  • Page 54 SPECIAL MESSAGES FROM THE TURNTABLE The turntable motor temperature is in the critical range. The controls can move the turntable only to a known satellite position or to the park position. In addition you receive the message “Last Move done” (to allow the turntable motor the opportunity to cool down, no movements of the turntable are permitted for a few minutes).

  • Page 55: Messages Arising From Software Problems

    SPECIAL MESSAGES FROM THE TURNTABLE The motorised antenna has reached the mechanical stop or is jammed! Check whether the turntable is obstructed (e.g. by a branch). MESSAGES ARISING FROM SOFTWARE PROBLEMS A serious software error has occurred. Reset the turntable in the CAP menu, or contact our service centre. The motorised antenna software is defective.

  • Page 56: Further Messages

    SPECIAL MESSAGES FROM THE TURNTABLE FURTHER MESSAGES The receiver has lost communication with the turntable. Check the connection between the UFS 740sw and the turntable. The connection to the turntable is defective. Reset the turntable in the CAP menu, check the connections between the turntable and receiver, or contact our service centre.

  • Page 57: Declaration Of Conformity

    See the respective instructions for proper use. Development, production, quality assurance and sales are based on the EN ISO 9001 standard, certifi cate register no. Q1 99 10 11297 015 for Kathrein-Werke KG dated 17.10.2000, issued by TÜV PRODUCT SERVICE GMBH.

  • Page 58: For Your Notes

    FOR YOUR NOTES...
  • Page 59 FOR YOUR NOTES...
  • Page 60 Internet: http://www.kathrein.de KATHREIN-Werke KG • Anton-Kathrein-Straße 1 - 3 P.O. Box 100 444 • 83004 Rosenheim GERMANY...
