Installation and operating manual

MobiSet 2 digital

CAP 600

Table of Contents

Need help?

Do you have a question about the MobiSet 2 digital CAP 600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kathrein MobiSet 2 digital CAP 600

Page 1 Installation and operating manual MobiSet 2 digital CAP 600...
Page 2: Table Of Contents
CONTENTS ..........................2 CONTENTS ............3 FOREIGN LANGUAGE INSTALLATION MANUAL/DISPOSAL ............4 MOBISET 2 CAP 600 COMPONENTS/SCOPE OF DELIVERY ........................... 5 PROPER USE ................. 6 SAFETY INSTRUCTIONS - IMPORTANT NOTES ................... 9 INSTALLATION AND CONNECTION ............11 INSTALLATION OF CABLE GLAND AND MOUNTING PLATE ....................
Page 3: Foreign Language Installation Manual/Disposal
(http://www.kathrein.de/en/sat/products/franzoesisch.htm). Lei puo avvere la versione italiana delle istruzioni di montaggio dalla nostra rapresentanza (http://www. kathrein.de/include/kontakte_groups_eng.cfm?kontinent=1&gruppe=SAT) piu vicina della sua citta´, oppure scaricarla dalla nostra hompage http://www.kathrein.de/en/sat/products/italienisch.htm) Para obtener la versión española de nuestro manual de instalación, contacte nuestros representantes en su país (http://www.kathrein.de/include/kontakte_groups_eng.cfm?kontinent=1&gruppe=SAT) o bajela de...
Page 4: Mobiset 2 Cap 600 Components/Scope Of Delivery
• Sikaﬂ ex 291 adhesive sealant (100 ml tube) • UFS 740sw DVB-S receiver with connecting cables, infrared sensor and infrared remote control • MobiSet 2 digital CAP 600 installation and operating manual • UFS 740sw satellite receiver operating manual...
Page 5: Proper Use
PROPER USE (USE FOR THE INTENDED PURPOSE) The MobiSet 2 digital CAP 600 is designed to receive digital TV and radio programs via satellite. The automatic positioner is intended to be used as a turntable for the Kathrein satellite dish.
Page 6: Safety Instructions - Important Notes
SAFETY INSTRUCTIONS - IMPORTANT NOTES Safety during installation work When carrying out installation work in locations where there is a risk of falling, take appropriate safety precautions, e.g. use of a working platform. Make sure that the vehicle roof is sufﬁ ciently strong and stable to carry out the installation work (risk of damage or collapsing of roof).
Page 7 SAFETY INSTRUCTIONS - IMPORTANT NOTES Road Trafﬁ c Licensing Regulations (StVZO) The applicable regulations of the StVZO must be observed in respect of ﬁ xed installation of the turntable on a vehicle which is driven on public highways. In particular, §§ 19/2; 30 C; 32 (2) and the EC directive 74/483 EEC are applicable. Brieﬂ...
Page 8 SAFETY INSTRUCTIONS - IMPORTANT NOTES The antenna will be lowered within 12 seconds of the ignition being switched on (if the unit is in stand-by mode or the UFS 740sw is switched off). Otherwise the control unit that is in use is lowered immediately. Attention: Lowering the antenna can take up to 30 seconds after the ignition is switched on! Checks before commencing a journey...
Page 9: Installation And Connection
INSTALLATION AND CONNECTION REQUIRED TOOLS AND EQUIPMENT • Circular cutter, Ø 38 mm • Flat-bladed screwdriver for M5 screws • Power drill • Galvanised round head screws, depending on the roof structure (Ø: 5 mm, sheet metal screws D 7981, depending on the roof structure) or round head screws D 7985 with washers and nuts •...
Page 10 INSTALLATION AND CONNECTION • When selecting the installation position, take into account the range of movement of the turntable (see graphics and the “Technical Data” chapter). There must be no structures on the roof that would obstruct this range of movement (risk of collision). For safety, keep at least the required area free (for ease of installation and any subsequent dismantling).
Page 11: Installation Of Cable Gland And Mounting Plate
INSTALLATION OF CABLE GLAND AND MOUNTING PLATE Comment: If you had previously used a Kathrein HDM140/141 ﬂ exible satellite mast or another mast with a diameter of 34 mm, you can continue using the existing gland hole in the roof (if space allows).
Page 12 INSTALLATION AND CONNECTION Figure: B Arrow in the direction of travel • Mark the positions of the six fastening holes on the roof of the vehicle in a circular pattern. Note: The size of the holes and the choice of fastening screws to be used (not supplied) depend on the type and thickness of the materials used in the roof structure.
Page 13 INSTALLATION AND CONNECTION • Create the holes necessary to secure the mounting plate (Fig. C). • In addition to the screwed connection, the mounting plate and roof gland must be bonded to the roof with adhesive and sealed. This is done using the Sikaﬂ ex ® 291 adhesive sealant supplied, which is ideally suited for this purpose due to its broad range of adhesion.
Page 14: Installation Of Turntable
INSTALLATION AND CONNECTION • Ensure before starting adhesive work that the temperature of materials to be glued and the adhesive sealant is between +5 °C and +40 °C. Prepare all necessary fasteners and tools. • Prepare the tube of adhesive sealant in accordance with the instructions enclosed with the tube. •...
Page 15 INSTALLATION AND CONNECTION Figure: E Direction of travel Battery, ignition Gasket with plug for Receiver the unused duct • Lift up the turntable and place it carefully on the mounting plate facing in the direction of travel (see illustration Fig. E) (do not step on the plug connector and do not kink/crush the cables!). The through holes on the turntable must be perfectly aligned with the threaded holes on the mounting plate.
Page 16 INSTALLATION AND CONNECTION VERSION WITH EXTERNAL CABLE GLAND (FIG. F) Direction of travel Cables laid in the cable duct* and water-tight roof gland* Not included! Watertight cable ducts are used in boating and yachting applications under the name “cable ports”; they can be purchased from boating and yachting chandlers. •...
Page 17: Brief Instructions For Installing The Turntable
INSTALLATION AND CONNECTION BRIEF INSTRUCTIONS FOR INSTALLING THE TURNTABLE The sequence of pictures shown illustrates all the necessary installation steps that are required to install the turntable and the BAS 60 planar antenna on the roof of the vehicle. The other detailed instructions in this installation and operating manual must also be followed! For ease of illustration, we have dismounted the BAS 60 on these photographs.
Page 18 Apply Sikaﬂ ex ® 291 adhesive in a Aligning the mounting plate. Arrow in the direction of travel. Mark wavy line between the two grooves out the six holes for securing the and spread it using a spatula or the mounting plate.
Page 19: Installation Of The Ufs 740Sw Receiver
INSTALLATION AND CONNECTION INSTALLATION OF THE UFS 740SW RECEIVER The turntable is controlled by the UFS 740sw DVB-S receiver. The cable lengths must be taken into account when choosing the installation location. For suspended installation use the installation kit supplied with the receiver. Note: When choosing the installation location, bear in mind that the on/off switch and the slots for inserting common interface modules should always be accessible.
Page 20 INSTALLATION AND CONNECTION Remove the wood screws supplied from their transport attachment on the underside of the respective mounting piece (2 pieces). Vertically insert each mounting piece into the ﬁ fth slot from the edge, as shown in Fig. 1. Then push each mounting piece downwards and outwards (see Fig.
Page 21: Laying Cables And Connecting The Turntable
INSTALLATION AND CONNECTION LAYING CABLES AND CONNECTING THE TURNTABLE • Lay the coaxial cable to the UFS 740sw. • Lay the turntable power supply cable (3-pin plug) to the battery. Avoid laying the cables across sharp edges and secure the cables against possible chaﬁ ng points.
Page 22: Functional Instructions For Connection To The On-Board Power Supply
INSTALLATION AND CONNECTION Only for connection in a motor home, not in a caravan! • The third, green connecting cable, marked “IGNITION” allows you the option of connection to a circuit in the vehicle that is activated when the ignition key is turned and then carries a continuous 12 V supply. This type of connection ensures that when the engine is started the antenna is automatically lowered into the park position (the receiver does not need to be turned on).
Page 23: Connection Example For 12 V Battery Connection
INSTALLATION AND CONNECTION CONNECTION EXAMPLE FOR 12 V BATTERY CONNECTION Figure: G Important: For operation with two batteries, it must be ensured that the ignition signal earth has the same potential as the power supply battery earth for the turntable. Non-compliance means that the automatic lowering function will not work!
Page 24: Reception Range/Footprint
RECEPTION RANGE/FOOTPRINT The footprint is the reception area on the earth that a satellite covers with its transmission beam (spot), within which satellite reception is possible. The transmission power is at its greatest in the centre of this spot – it becomes progressively weaker moving outwards. You should preferably align your antenna to the position of the ASTRA satellite 19.2°...
Page 25: Dismantling For Servicing
Before exchanging the UFS 740sw, ﬁ rst move the turntable to the park position. ADDRESS OF THE SERVICE CENTRE Electronic Service Chiemgau GmbH Bahnhofstraße 108 83224 Grassau, Germany Phone: +49 8641 9545-0 Fax: +49 8641 9545-35 and -36 Internet: http://www.esc-kathrein.de e-mail: service@esc-kathrein.de...
Page 26: Polarisation Setting
POLARISATION SETTING POLARISATION SETTING As supplied, the BAS 60 is mounted centrally on the turntable. In this position, you can also receive signals from satellites with deviations in the degree of longitude (of the typical reception range) of between 15° and 20° from the orbit position of the satellite.
Page 27: Safety Notes
POLARISATION SETTING SAFETY NOTES We strongly advise that users who are not familiar with the installation work should not reassemble the BAS 60 independently. They should contact a technician or engineer. They may ﬁ nd a suitable person on the campsite. Make sure that: - The antenna and connected units are disconnected from the power - The person carrying out the installation does not suffer from vertigo and can move around safely on the...
Page 28: Installation Process
POLARISATION SETTING INSTALLATION PROCESS The explanation of this installation process is based on the assumption that the entire CAP unit has been properly put together, installed and set up, as described in this installation manual. The safety instructions in the detailed operating manual for the UFS 740sw must also be followed! To dismantle/install the planar antenna from the turntable, proceed as follows: (the key names refer to the remote control for the UFS 740sw receiver) Turn on the receiver at the main switch on the front of the unit.
Page 29 POLARISATION SETTING 15. Switch the receiver on ﬁ rstly with the main switch and then with any of the numeric buttons. 16. You will then see the message “Please wait, initialising HDP”. Wait until the message “Position of Astra is not known. Start a search?” is displayed – cancel this procedure by pressing the button.
Page 30: Manual Lowering To Park Position
MANUAL LOWERING TO PARK POSITION If a defect arises in the electronic controls, after some disassembly work the satellite dish can be returned to the park position (horizontal position) manually. Following this however recalibration by an authorised workshop is always necessary. Driving to the nearest workshop with the antenna extended at a moderate speed and taking into account the increase (+ 72 cm) in the vehicle height is an option and is preferable to manual lowering.
Page 31: Manual Lowering
MANUAL LOWERING TO PARK POSITION MANUAL LOWERING In the centre of the antenna (arrowed) there is a plastic cap. Lever this off with a narrow slot-head screwdriver. Behind the cap is an M8 hexagon head screw. Unscrew these using a 13 mm socket wrench. After removing the M8 screw, a further thread can be seen.
Page 32: Technical Data
TECHNICAL DATA DIMENSIONS (MM) Direction of travel Mounting plate...
Page 33 TECHNICAL DATA Min. recommended clearance Ø 880 Rotary axis BAS 60 Mounting plate Roof gland Clamping range 20/50 Weight incl. BAS 60: approx. 13.8 kg...
Page 34 TECHNICAL DATA Type CAP 600 Order no. 20310018 1 output switchable: V/H (14/18 V), low/high (0/22 kHz) LNB supply voltage vertical: 11.5-14, horiz.: 16-19 Input frequency 10.70-12.75 Output frequency 950-1950/1100-2150 Oscillator frequency (L.O.) 9.75/10.60 System quality (G/T) 11.3/12.5 GHz dB/K 13.3/13.7 Power supply (vehicle battery) 10.9-13.8...
Page 35: Sikaflex ® 291 Safety Data Sheet
SIKAFLEX ® 291 SAFETY DATA SHEET 1. Materials/preparation and company designation ® Data on the product (trade name): Sikaﬂ ex Data on manufacturer/suppliers Manufacturer/suppliers: Sika Deutschland GmbH Street/postcode: Kornwestheimer Str. 103-107 Postcode and town: Stuttgart Country: Germany Tel: +49 711 80090 Fax: +49 711 8009321 General information: Product safety...
Page 36 SIKAFLEX ® 291 SAFETY DATA SHEET 5. Measures for ﬁ re ﬁ ghting Suitable extinguishing media Compatible with all extinguishing media in general use. Special hazard from the product, its products of combustion or gases released In case of ﬁ re the following can be released: Carbon monoxide (CO) Carbon dioxide (CO Hydrogen chloride (HCl) Oxides of nitrogen (NO...
Page 37 SIKAFLEX ® 291 SAFETY DATA SHEET 4,4‘ methylene-diphenyl-diisocyanate 101-68-8 Permissible workplace concentration 0.05 mg/m TRGS 900/DE/2004 101-68-8 Permissible workplace concentration 0.005 ml/m TRGS 900/DE/2004 Xylol 1330-20-7 Permissible workplace concentration 440 mg/m TRGS 900/DE/2004 1330-20-7 Permissible workplace concentration 100 ml/m TRGS 900/DE/2004 1330-20-7 EU-TWA (8h) 221 mg/m...
Page 38 SIKAFLEX ® 291 SAFETY DATA SHEET 11. Toxicology data Sensitisation Sensitisation/allergic reactions may occur. Sensitive individuals may exhibit allergic reactions even at very low concentrations. Experience of human exposure On skin contact: May lead to irritation On eye contact: May lead to irritation On being breathed in: May lead to irritation On being swallowed:...
Page 39 SIKAFLEX ® 291 SAFETY DATA SHEET Risk phrases Sensitisation possible by breathing in. Safety phrases Do not breathe in gas/smoke/vapour/aerosol. IN the event of accident or feeling unwell summon a doctor immediately (if possible show the doctor this label). Special identiﬁ cation of particular components Contains isocyanates.
Page 40: Sikaflex ® 291 Technical Data Sheet
® SIKAFLEX 291 TECHNICAL DATA SHEET Technisches Merkblatt Technical data sheet Version 12 / 2005 Version 12/2005 ® Sikaﬂ ex Sikaflex ® -291 -291 Der haftstarke Marine-Dichtstoff The strongly bonding marine adhesive Technische Eigenschaften Technical characteristics Chemische Basis 1-K Polyurethan Chemical basis 1-component polyurethane Farbe...
Page 41 ® SIKAFLEX 291 TECHNICAL DATA SHEET Die Vernetzungsreaktion von Si- peratur von Material und Werkstoff Weitere Informationen The cross-linking reaction of Sikaf- For advice on selection and arran- Additional information ® kaflex -291 erfolgt mit Luftfeuch- liegt zwischen 15°C und 25°C. ®...
Page 42: Cap 600 Operating Manual
The Kathrein Customer Hotline is also at your disposal. Phone: +49 8031 184-700 The automatic updating of the EPG data described in the UFS 740sw operating...
Page 43: Important Information For Cap 600 Before Setup
IMPORTANT INFORMATION FOR CAP 600 BEFORE SETUP This section of the UFS 740 operating manual for the turntable assumes that the UFS 740 and the turntable have been properly installed and connected, as described in the installation and operating manuals! If you have not yet done so, read the safety instructions at the beginning of the UFS 740sw operating manual and follow them when handling the UFS 740sw and the turntable!
Page 44: First Installation
FIRST INSTALLATION Before using your unit for the ﬁ rst time, read the “Safety Instructions - Important Information” and “Installation and Connection” sections. You will ﬁ nd a sample conﬁ guration for a motor home in the Section “Installation and Connection”, “Connection Example”.
Page 45 FIRST INSTALLATION The following display appears: Use the buttons here to select the settings for your TV set. When doing this, refer to the operating instructions for your TV set! TV aspect ratio Here you select the TV's picture format. Either 4:3 or 16:9 Picture format...
Page 46 FIRST INSTALLATION The following display appears: System Use the buttons at “System” to select “CAP 600”. Then press the (green) button twice (Channel scan “item 4/5” is skipped). The following display appears: Local time offset Use the buttons to set the time zone variation from UTC (formerly GMT) (e.g. for Germany +1 hour). Use the buttons to switch to the “Automatic clock change”...
Page 47: Alignment (Satellite Search)
ALIGNMENT (SATELLITE SEARCH) The antenna is aligned automatically. After the UFS 740 has been switched on, the turntable automatically moves to the last channel received and the associated satellite position (e.g. ARD/ASTRA). This works because every satellite broadcasts its own identiﬁ cation signal, which is automatically identiﬁ ed by the turntable.
Page 48: Manual Correction
ALIGNMENT (SATELLITE SEARCH) MANUAL CORRECTION At the margins of the footprints of a satellite (e.g. after a slight change of position), it may be necessary for you to manually correct the setting (not normally required). It is also possible to manually correct the ﬁ ne tuning.
Page 49: Channel (Satellite) Selection
CHANNEL (SATELLITE) SELECTION By pressing the buttons all channels can be selected in the sequence that they appear in the current channel list and its sorting. Press the (blue) button to switch between TV and radio channels. CHANNEL SELECTION FROM THE CHANNEL LIST Providing you are not in a menu, pressing the button calls up the channel list.
Page 50: Change Of Location/Timer Programming
CHANGE OF LOCATION/TIMER PROGRAMMING After a change of location, the antenna moves to the last position selected. After initialisation, you will therefore see the following display (example, as it depends on the last selected position): For slight changes of location, the antenna can ﬁ...
Page 51: Reset/Parking
RESET/PARKING RESETTING THE MOTORISED ANTENNA Press the button to return to the main menu. By using the buttons and the button you can call up sub-menus (“Settings”, “Antenna Conﬁ guration”). Use the buttons to move to the “Reset the motorised antenna” menu item and then press button.
Page 52: Parking The Turntable
RESET/PARKING PARKING THE TURNTABLE You have three options for “parking” the antenna. The antenna can be moved to park position by pressing the button twice. Press the button to return to the main menu. By using the buttons and the button you can call up the sub-menus (“Settings”, “Antenna Conﬁ...
Page 53: Special Messages From The Turntable
SPECIAL MESSAGES FROM THE TURNTABLE SYSTEM PROTECTION MESSAGES The following messages are shown on the screen to protect your reception system and the on-board power supply: The power supply to the turntable is insufﬁ cient (battery voltage below minimum value). The turntable can still be moved, but communication errors can occur between the UFS 740sw and the turntable (e.g.
Page 54 SPECIAL MESSAGES FROM THE TURNTABLE The turntable motor temperature is in the critical range. The controls can move the turntable only to a known satellite position or to the park position. In addition you receive the message “Last Move done” (to allow the turntable motor the opportunity to cool down, no movements of the turntable are permitted for a few minutes).
Page 55 SPECIAL MESSAGES FROM THE TURNTABLE The motorised antenna has reached the mechanical stop or is jammed! Check whether the turntable is obstructed (e.g. by a branch). MESSAGES ARISING FROM SOFTWARE PROBLEMS A serious software error has occurred. Reset the turntable in the CAP menu, or contact our service centre. The motorised antenna software is defective.
Page 56 SPECIAL MESSAGES FROM THE TURNTABLE FURTHER MESSAGES The receiver has lost communication with the turntable. Check the connection between the UFS 740sw and the turntable. The connection to the turntable is defective. Reset the turntable in the CAP menu, check the connections between the turntable and receiver, or contact our service centre.
Page 57: Declaration Of Conformity
See the respective instructions for proper use. Development, production, quality assurance and sales are based on the EN ISO 9001 standard, certiﬁ cate register no. Q1 99 10 11297 015 for Kathrein-Werke KG dated 17.10.2000, issued by TÜV PRODUCT SERVICE GMBH.
Page 58: For Your Notes
FOR YOUR NOTES...
Page 59 FOR YOUR NOTES...
Page 60 Internet: http://www.kathrein.de KATHREIN-Werke KG • Anton-Kathrein-Straße 1 - 3 P.O. Box 100 444 • 83004 Rosenheim GERMANY...
