- Page 1 CAP 750 GPS Translation of the original operating manual HDP 750 GPS English CAP 750 GPS HDP 750 GPS Only with CAP 750 GPS...
-
Page 2: Table Of Contents
Contents General Scope of Delivery Intended Use Safety Instructions and General Guidelines Installation and Connection Installing and Connecting the Turntable 5.1.1 Required Tools and Equipment 5.1.2 Unpacking and Preparing 5.1.3 Selecting the Installation Location 5.1.4 Installing the Cable Gland and Mounting Plate 5.1.5 Installation of the Turntable 5.1.6... - Page 3 CAP 750 GPS Operating Instructions 12.1 Installing the CAP Converter 12.2 Change of Location 12.3 Operating the Turntable Using the External Push-button 12.3.1 Starting the Turntable 12.3.2 Moving the Turntable to the Park Position. 12.3.3 Performing a Reset 12.4 Updating Channel List and Software 12.4.1 Updating the Channel List 12.4.2...
-
Page 4: General
General General Company address KATHREIN Digital Systems GmbH Anton-Kathrein-Straße 1 - 3 83022 Rosenheim, Germany 4 of 48... -
Page 5: Scope Of Delivery
12 V connection cable and LED/pushbutton cable ● 4 x wood screw, 4.5 mm x 30 mm ● CAP 750 GPS, CTS 750-xx GPS operating manual Fixed connection to the turntable A coaxial cable F-socket/F-socket is required to connect the TV set to the CAP converter (cable length depends on the distance between the two devices). -
Page 6: Intended Use
Intended Use Intended Use The CAP 750 GPS and CTS 750-xx GPS are designed to receive digital TV and radio channels via satellite. The automatic positioner is intended to be used as a turntable for the Kathrein parabolic reflector. The turntable can be used to receive digital TV and radio signals in the frequency range from from 10.70 to 12.75 GHz; the antenna cannot receive terrestrial signals such as DVB-T/DVB-T2. -
Page 7: Safety Instructions And General Guidelines
Safety Instructions and General Guidelines Danger to life from electric shock when touching electrical installations! ► Maintain a minimum clearance of 1 m from all electrical devices. ► Disconnect the turntable and all the units connected to it from the power supply during installation/ repairs/dismantling. - Page 8 Safety Instructions and General Guidelines Proper installation and safety The system may be installed only by qualified specialist personnel! To prevent hazards during installation, operation or when driving on public highways, the instruc- tions and information in this manual must be strictly adhered to. Proper installation and connection of the system are prerequisites for conformity with the corresponding standards.
- Page 9 Cables Risk of smouldering fire! Tying the cables up with a wire or the like could cause a smouldering fire. ► Disentangle and remove the wire or the like. Trip hazard due to cables! Crushing or excessively stretching cables can cause a smouldering fire. ►...
- Page 10 Safety Instructions and General Guidelines Using the cable core marked Ignition, the power supply cable is connected to the ignition current circuit. This way, the turntable has a function for automatic lowering of the antenna. The lowering takes place as soon as the vehicle ignition circuit is turned on.
- Page 11 Ready-made config.xml files are available free of charge at www.kathrein.de/service/downloads/cap/ from our service centre in Ulm, Germany. 1. On a USB flash drive create a kathrein folder with a capconverter subfolder. (Use lower case letters for folder names!) 2. Copy the config.xml file to the capconverter subfolder.
-
Page 12: Installation And Connection
Installation and Connection Installation and Connection Installing and Connecting the Turntable 5.1.1 Required Tools and Equipment ● Circular cutter, Ø 38 mm ● Cleaning agent ● Flat-bladed screwdriver for M5 screws ● Open-ended or ring spanners 10 and 11 mm across flats ●... -
Page 13: Selecting The Installation Location
5.1.3 Selecting the Installation Location Essentially, the cable lengths of the components that are supplied allow you a free choice of installation location on your caravan or motor home. When selecting the installation site, take note of the following points: ►... - Page 14 Installation and Connection Direction of travel 75º Park position The height of neighbouring attachments on the roof may lead to shadowing! Area (min. Ø 566 mm) within which equipment can be attached to the turntable up to a height of 210 mm. Recommended min.
-
Page 15: Installing The Cable Gland And Mounting Plate
5.1.4 Installing the Cable Gland and Mounting Plate If you have previously used a Kathrein HDM 140/141 jointed tripod mast or another mast with a diameter of 34 mm, you can continue using the existing through hole in the roof. Fig. A Fig. B ①... - Page 16 Installation and Connection 7. Create the holes necessary to secure the mounting plate (Fig. C). 8. In addition to the screwed connection, the mounting plate and roof duct must be bonded to the roof with adhesive and sealed. This is done using an adhesive sealant (e.g. DEKAsyl MS adhesive sealant), which is ideally suited for this purpose due to its broad range of adhesion.
-
Page 17: Installation Of The Turntable
– Use a clean colourless cloth to remove any adhesive sealant that leaks out at the sides. Pay attention to the following: ~ Do not use any cleaning agents or thinners containing solvents, as this could damage the adhesive sealant applied under the mounting plate. - Page 18 Installation and Connection Version with external cable gland The external roof duct is arranged such that it forms a watertight enclosure on the vehicle roof around the point where the three cables projecting from the turntable are connected to the two extension cables within the interior of the vehicle, and where if necessary they can be disconnected (see Fig.
-
Page 19: Installing The Turntable
5.1.6 Installing the Turntable The sequence of pictures shown illustrates all the necessary installation steps that are required to install the turntable and the pre-assembled parabolic reflector on the roof of the vehicle. However, follow the other detailed instructions in this installation and operating manual! 1. -
Page 20: Laying The Cables And Connecting The Turntable
● Connect the master coaxial cable to the IF INPUT socket at the rear of the master control unit (alphatronics SL TV set (with Kathrein control) or CAP converter). If necessary, use the coaxial extension cable. ● Make sure that each live cable leading to the individual units is sufficiently fuse-protected and was installed by an expert. -
Page 21: Functional Instructions For Connection To The On-Board Power Supply
● At the connecting point for the power cable, the voltage must not fall below 11.5 V even with a higher load. Otherwise optimum functioning can no longer be guaranteed. ● Only for motor homes: The third, green core of the connecting cable, marked “IGNITION”, allows the connection to a circuit in the vehicle that is activated when the ignition key is turned and then carries a continuous 12 V supply voltage. -
Page 22: Connection Example For 12 V Battery Connection
Installation and Connection 5.1.9 Connection Example for 12 V Battery Connection UFZ 131* TV set 1 Wi-Fi Hotspot with satellite tuner ly c a b Ignition TV set 2 r s u p p P o w e with satellite tuner l c a b le c o a x ia S la v e... - Page 23 When choosing the installation location, take account of the following: ● The wall thickness of the installation surface must be at least 15 mm, as otherwise the screws will break through on the other side or damage the surface. ● Ensure that the cupboard or storage compartment in which the unit is housed is adequately ventilated, to prevent a build-up of heat.
-
Page 24: Preparing The Cap Converter For Installation
Installation and Connection 5.2.2 Preparing the CAP Converter for Installation Removing the blanking caps When the unit is delivered, the screw sockets are covered with blanking plugs. Push these out, using the screws supplied working upwards from below in the direction of arrow. -
Page 25: Installing The Cap Converter On The Rear Panel Of A Tv Set
Risk of material damage due to countersunk head screws! ► Under no circumstances use countersunk head screws for installation (see figure on the right). Risk of malfunction and material damage due to overheating! If the CAP converter is attached to another electrical device, e.g. a TV set, the temperature rise of each unit in operation can affect the other, thus causing overheating. -
Page 26: Installing The Cap Converter
Installation and Connection For installation on the rear panel of a TV set, securing with two screws is sufficient. Before installing the CAP converter, pay attention to the following: ● The TV set must have one of the following hole patterns for wall mounting on its rear panel: 100 x 100; 100 x 200; 200 x 200 or 200 x 400. -
Page 27: Connecting The Cap Converter
5.2.6 Connecting the CAP converter The CAP converter must not be connected to any supply voltage other than 10.5 to 15.5 V. The CAP converter’s earth connection must be connected to the negative pole of the motor home or caravan battery. -
Page 28: Installation And Connection Of The Cts 750-Xx Gps
Installation and Connection Installation and Connection of the CTS 750-xx GPS See operating instructions of the alphatronics TV set. 5.3.1 Connection Example for 12 V Battery Connection UFZ 131* Wi-Fi Hotspot l y c a b Ignition TV set 2 r s u p p P o w e with satellite tuner... -
Page 29: Reception Range/Footprint
Reception Range/Footprint The footprint is the reception area on the earth that a satellite covers with its transmission beam (spot), within which satellite reception is possible. The transmission power is at its greatest in the centre of this spot – it becomes progres- sively weaker moving outwards. -
Page 30: Dismantling For Servicing
➯ The casing is watertight again. Address of the Service Centre Main factory repair centre CSS Caravan-Sat-Service GmbH Bahnhofstr. 110 83224 Grassau, Germany Phone: +49 8641 6998427 Fax: +49 8641 6998429 Email: service@css-grassau.de More service partners under: www.kathrein-ds.com 30 of 48... -
Page 31: Polarisation Setting
Polarisation Setting About Polarisation Setting The LNB of the turntable is factory-set to the polarisation setting 0. In this position you can still receive signals from 1) satellites with deviations of 15° to 20° . For larger deviations it is best to set the required polarisation angle by rotating the LNB. -
Page 32: Safety Instructions
Polarisation Setting Safety Instructions ► Follow the general safety instructions; see 4 Safety Instructions and General Guidelines, p.7 Risk of material damage due to obstacles in the range of rotation or malfunction due to incorrect setting! ► Make sure that there are no obstacles in the range of rotation of the turntable. ►... - Page 33 View after installation +45° View after installation -45° 33 of 48...
-
Page 34: Manually Lowering The Antenna To Park Position
Manually Lowering the Antenna to Park Position Manually Lowering the Antenna to Park Position Risk of material damage due to a defect in the electronic controls! If there is a defect in the electronic controls, the antenna cannot lower to the park position automati- cally. -
Page 35: Manually Lowering The Turntable
Manually Lowering the Turntable 1. Using a narrow flat-bladed screwdriver, lever the plastic cap in the centre of the axis (see the arrow). ➯ You can see an M8 hexagon head screw (WAF 13 mm). 2. Remove the M8 hexagon head screw using a socket wrench (WAF 13 mm). -
Page 36: Technical Data And Dimensions
Technical Data and Dimensions Technical Data and Dimensions 10.1 Technical Data Type Unit CAP 750 GPS Order no. 20310056 2 switchable outputs: V/H (14/18) Low/High (0/22) Supply voltage LNB Vertical: 11.5 – 14 Horizontal: 16 – 19 Input frequency 10.70 – 12.75 Output frequency 950 – 1950/1100 – 2150 Oscillator frequency (L. O.) 9.75/10.60... -
Page 37: Dimensions (In Mm)
10.2 Dimensions (in mm) Direction of travel Mounting plate 37 of 48... - Page 38 Technical Data and Dimensions 137,5 with mounting plate (210) 38 of 48...
-
Page 39: Safety Instructions And General Guidelines
Safety Instructions and General Guidelines In the following operating manual we assume that the CAP converter or the alphatronics TV set and the turntable have been properly installed and connected, as described in Chapter 4, p. 7 and Chapter 5, p. 12. If you have not yet done so, read the safety instructions in this installation and operating manual and follow them when handling the CAP converter or the alphatronics TV set and the turntable! Before setting up your satellite system, make sure that the location allows a free view to the satellite posi-... -
Page 40: Cap 750 Gps Operating Instructions
If, despite studying these operating instructions, you still have questions about getting started with the unit or using it correctly, or if unexpected problems occur, please contact your specialist dealer. The Kathrein Technical Customer Support is also at your disposal. Phone: +49 731 27090970 40 of 48... -
Page 41: Installing The Cap Converter
12.1 Installing the CAP Converter ✔ The master coaxial cable is connected to the ANTENNA ② socket; see 5.2.6, p. 27. 1. Connect the TV set to an TV/STB ① socket using a coaxial cable (not included) . Risk of malfunction! ► Do not interchange the cables. 2. -
Page 42: Updating Channel List And Software
12.4.1 Updating the Channel List ✔ An FAT32 formatted USB flash drive is available for this task. 1. On the USB flash drive create a kathrein folder with a capconverter subfolder. 2. Download a channel.xml file with an up-to-date channel list from www.kathrein-ds.com... -
Page 43: Led Status Display On The Cap Converter V2 - External Pushbutton
12.5 LED Status Display on the CAP Converter V2 - external Pushbutton Function LED Colour Signal Description LED flashes 1x for 0.5 sec, then pauses for 2 sec No connection to CAP/HDS LED flashes 2x for 0.5 sec, then pauses for 2 sec Satellite not found LED flashes 3x for 0.5 sec, then pauses for 2 sec Ignition is active... -
Page 44: Possible Malfunctions
Phone: +49 8641 699 84 27 Email: service@css-grassau.de 13.3 Service Partners You can find service partners under www.kathrein-ds.com. Disposal Electronic equipment Electronic equipment is not domestic waste – in accordance with directive 2012/19/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL dated 04th July 2012 concerning used electrical and electronic appliances, it must be dis- posed of properly. -
Page 45: Simplified Eu Declaration Of Conformity
Hereby, KATHREIN Digital Systems GmbH declares that the radio equipment types HDP 750 GPS, BN: 20410084 and CAP 750 GPS, BN: 20310056 are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity are available at the following internet address: www.kathrein-ds.com... -
Page 46: Connection Of The Current-Carrying Cables
Connection of the current-carrying cables Connection of the current-carrying cables Important notice! Valid for all available CAP/HDP turntables ATTENTION Material damage and malfunction due to reversed polarity! When connecting the power cables, reversed polarity can lead to thermal overload and damage to compo- nents when the equipment is powered up. - Page 47 47 of 48...
