Page 1: Table Of Contents
NOTE: The FrameSaver product line has been Installation Instructions renamed to iMarc. Document Number 9783-A2-GN11-30 May 2003 Contents iMarc DSL 9783 Router Overview ..............Upgrading a Unit to the SLM Feature Set ............. Product Documentation Online ..............Package Checklist ..................
Page 2: Imarc Dsl 9783 Router Overview
IP router that connects a DSL link to an Ethernet network. The iMarc DSL 9783 Router is used for data only and provides corporate LAN access over traditional twisted-pair copper telephone wiring. Copper pairs run from the central office (CO) to the customer premises (CP) to create the local loop.
Page 3: Upgrading A Unit To The Slm Feature Set
The iMarc DSL 9783 CSU/DSU is available in two feature sets: „ Basic diagnostic feature set provides basic frame relay and diagnostic capability. „ Service Level Management (SLM) provides basic features, plus reporting and monitoring. Refer to the iMarc SLV Technical Description for a list of iMarc DSL features, and the capabilities provided by each feature set.
Page 4: Product Documentation Online
SLV SNMP Reference (9000-A2-GB32) iMarc SLV Operations Guide (9000-A2-GB33) iMarc SLV Router Command Line Interface (9000-A2-GB34) To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. Package Checklist In addition to these instructions, verify that your package contains the following: ❑...
Page 5: Wiring And Cables You May Need
EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm). ❑ Ethernet wiring: Shielded twisted-pair wiring (CAT5, or better). The CAT5 wiring must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm). Contact your sales representative to order Paradyne cables. Interface Feature Connection Cables...
Page 6: Prior To Installing The Router
Prior to Installing the Router These Installation Instructions assume that the virtual circuits at the DSLAM have already been configured. Provisioning of these circuits can be simplified by using the OpenLane SLM (Service Level Management) system, as indicated in Provisioning Data Circuits in OpenLane.
Page 7: Installing The Router
Installing the Router Place the iMarc DSL 9783 Router on a flat surface, with clearance for the rear connectors. Procedure 1. Use the supplied 8-pin DSL network cable (for use in the U.S.), or a 6-pin DSL network cable (using connectors similar to RJ11), as applicable, for the DSL connection.
Page 8 3. Use an 8-pin Ethernet cable for the Ethernet connection. Insert one end of the cable into the jack labeled ETHERNET. — Use a straight-through cable to connect the other end of the cable to an Ethernet hub. Do not connect to the hub’s optional Uplink connection with a straight-through cable;...
Page 9 4. Use a VT100-compatible asynchronous terminal or PC to set up management access to the unit. Insert the DB25 end of the EIA-232 cable into the router’s COM port. Tighten the screws on each side of the connector. Insert the other end into the terminal or PC.
Page 10 5. Insert the supplied power cord’s round end into the jack labeled POWER. Plug the transformer into an AC outlet. Install the supplied tie wrap for strain relief, as shown. Grounded Power Outlet Wrap Power Jack P O W C O M E T H E R N E T N E T...
Page 11: Status Leds
Status LEDs After a successful self-test, the LEDs should appear as indicated in BOLD in the Condition column below. Condition Status System LEDs The router has power. An alarm condition exists. No alarms have been detected by the router. TEST The router is performing the power-on self-test, or a test initiated by the service provider is currently active.
Page 12: Troubleshooting
Troubleshooting LED Symptom Action All LEDs are on. If the LEDs remain on for more than ten minutes, the router is not functional. Unplug the router and reapply power. If the ALM LED is still on, contact the service provider. ALM LED only The power-on self-test may have failed.
Page 13: Configuration Setup
Configuration Setup Once the router is installed, it can be accessed locally through the menu-driven user interface via an asynchronous terminal or PC connection, or remotely via a Telnet session, and the router’s interfaces can be provisioned. The following provisioning can be set up: „...
Page 14: Verifying That Self-Test Passed
main 9783-RtrSLV Device Name: Node A 2/26/2001 00:02 MAIN MENU Status Test Configuration Control Easy Install ----------------------------------------------------------------------------- Ctrl-a to access these functions, Shift-r to access the Router’s CLI. Exit If the Main Menu does not appear, recheck the terminal or PC’s settings, or press Enter again.
Page 15: Menu Navigation
Menu Navigation The router should operate using the default (factory-set) configuration options. Refer to the following table for help in navigating the menus. Press the . . . To . . . Esc key Go back one screen or menu level. See Menu Hierarchy page 16.
Page 16: Menu Hierarchy
Menu Hierarchy The Menu Hierarchy shows the organization of the iMarc unit’s screens. Status System and Test Self-Test Results Status Last Reset Health and Status Test Status IP Path Connection Device Name Status IP Address Status Discovery Source PVC Connection Source Link, DLCI, EDLCI Status Primary Destination Link, DLCI,...
Page 17: Configuration System
Test Network PVC Tests PVC Loopback Send Pattern Monitor Pattern Connectivity Network ATM ATM Ping Loopback Tests IP Ping Lamp Test Abort All Tests Configuration System Class of Service Definitions Service Level Verification General Network Physical Frame Relay Circuit Records Virtual Router Ports DLCI Records PVC Connections...
Page 18 Control System Information Device Name System Name, Location, Contact ATM Location ID Date Time Administer Logins Login ID Password Access Level Change Operating Back-to-Back Mode Mode Standard Mode Select Software Current Release Release Alternate Release Switch & Reset Reset Device Easy Install DSLAM Type Node IP Address...
Page 19: Using The Easy Install Feature
1. Select the Easy Install feature. Main Menu → Easy Install Easy Install Screen Example main/easy_install 9783-RtrSLV Device Name: Node A 2/26/2001 00:01 EASY INSTALL DSLAM Type: Paradyne Node IP Address: 000.000.000.000 Clear Node Subnet Mask: 000.000.000.000 Clear TS Access: VPI,VCI 0,35...
Page 20: Completing Setup From The Noc
2. If the router will not be connected to a Paradyne DSLAM, change the DSLAM Type. Other selections are Alcatel (NewBridge), PairGain, and Nokia. 3. Enter the Node IP Address and Subnet Mask. 4. Specify TS Access if a Troubleshooting (TS) DLCI or Virtual Circuit (VC) is being set up for remote access by the service provider.
Page 21: Configuring Snmp Trap Managers And Traps
Configuring SNMP Trap Managers and Traps Procedure To enter SNMP managers and configure traps: 1. Select SNMP Traps. Main Menu → Configuration → Management and Communication → SNMP Traps 2. Configure the following: — Enable SNMP Traps. — Identify the total Number of Trap Managers. —...
Page 22 Procedure 1. Create a DLCI on the router virtual port. Configuration → Virtual Router Ports → DLCI Records Assign the DLCI number that will be used for management on Serial port 0 (Rtr-S0 – e.g., DLCI 900). 2. Create a management PVC using the DLCI just configured on Serial port 0 to connect the management link to the router.
Page 23: Verifying The End-To-End Management Path
Verifying the End-to-End Management Path ® After installation of a remote router, run an ATM Ping test from the Hotwire GranDSLAM. Procedure To Ping the router: 1. From the Hotwire ATM Line Card’s Main Menu, select the ATM Ping test. Diagnostics →...
Page 24: Checking Pvc Connections
Provisioning the Router Interface The iMarc DSL 9783 Router defaults to bridge mode. Routing without bridging, and simultaneous routing and bridging, are also options. Use the bridge command from the router’s CLI to configure the bridge and routing attributes.
Page 25: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
Page 26: Emi Notices
The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. CANADA – EMI NOTICE: This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations.
Page 27: Government Requirements
Government Requirements Certain governments require that instructions pertaining to connection to the telephone network be included in the installation and operation manual. Specific instructions are listed in the following sections. Notice to Users of the Canadian Telephone Network The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s).
Page 28: Warranty, Sales, Service, And Training Information
Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
