® FrameSaver DSL 9788 Router Installation Instructions Document Number 9788-A2-GN11-00 July 2002 Contents FrameSaver DSL Router Overview ............... Upgrading a Unit to Advanced SLM Feature Set .......... Product Documentation Online ..............Package Checklist ..................Wiring and Cables You May Need ..............
Page 2: Framesaver Dsl Router Overview
FrameSaver DSL Router Overview ® The FrameSaver DSL (Digital Subscriber Line) Router is a component in the FrameSaver system. This system allows you to perform end-to-end service level management (SLM) across a hybrid DSL/ATM/Frame Relay network. Service providers can isolate and correct problems remotely from their NOC (Network Operations Center). The router has a DSL interface and is a manageable frame relay-aware endpoint.
Page 3: Upgrading A Unit To Advanced Slm Feature Set
To learn more about activating the Advanced SLM Feature Set, refer to the FrameSaver SLV Activation Instructions (Document Number 9000-A2-GK43), or contact your sales representative. Product Documentation Online Complete documentation for this product is available at www.paradyne.com. Select Library → Technical Manuals → FrameSaver Frame Relay Devices. Select the following document: 9700-A2-GB20 FrameSaver DSL, Models 9783 and 9788, User’s Guide...
Page 4: Package Checklist
Power cord with power transformer Tie wrap for power cord strain relief DSL network access cable (with U.S. models only) FrameSaver DSL Router, Models 9783 and 9788, Quick Reference (Document Number 9700-A2-GL11) Be sure to register your warranty at www.paradyne.com/warranty.
Page 5: Wiring And Cables You May Need
EIA/TIA-568 specifications with 24 AWG (0.5 mm) or 26 AWG (0.4 mm). For standard cables, refer to Cables and Connectors on page 22 for standard pin numbers. For Paradyne cables, contact your sales representative to order them. Interface Feature Connection...
Page 6: Provisioning Data Circuits Before Installation
Provisioning Data Circuits Before Installation Before installing the router, use the OpenLane SLM system’s Provision Circuit screen to add: New circuits that start at the FrameSaver DSL endpoint and traverse the SCM and ® ATM line card in the Hotwire GranDSLAM™...
Page 7: Installing The Router
Installing the Router Place the FrameSaver DSL Router on a flat surface, with clearance for the rear connectors. Procedure 1. Use an 8-pin modular cable (supplied with U.S. models). Insert one end of the cable into the jack labeled NET. Insert the other end into the wall jack for DSL data communications.
Page 8 2. Use an 8-pin Ethernet cable for the Ethernet connection. Insert one end of the cable into the jack labeled ETHERNET. — Use a straight-through cable to connect the other end of the cable to an Ethernet hub. Do not connect to the hub’s optional Uplink connection with a straight-through cable;...
Page 9 3. Use a VT100-compatible asynchronous terminal or PC to set up management access to the unit. Insert the DB9 end of an EIA-232 cable into the router’s COM port. Tighten the screws on each side of the connector. Insert the other end into the terminal or PC.
Page 10 4. Insert the supplied power cord’s round end into the jack labeled POWER. Plug the transformer into an AC outlet. Install the supplied tie wrap for strain relief, as shown. Grounded Power Cable Outlet POWER P O W C O M E T H E R N E T N E T...
Page 11: Power-On
13 for LED indications requiring action. System OK – green Alarm – red Test – yellow ATM – green DSL – green Ethernet Port – green 9788 ROUTER FrameSaver ® SHDSL System Network Port 01-16985 FrameSaver DSL 9788 Router...
Page 12: Status Leds
Status LEDs After a successful self-test, the LEDs should appear as indicated in BOLD in the Condition column below. Condition Status System LEDs The router has power. An alarm condition exists. No alarms have been detected by the router. TEST The router is performing the power-on self-test, or a test initiated by the service provider is currently active.
Page 13: Troubleshooting
Troubleshooting LED Symptom Action All LEDs are on. If the LEDs remain on for more than ten minutes, the router is not functional. Unplug the router and reapply power. If the ALM LED is still on, contact the service provider. ALM LED only The power-on self-test may have failed.
Page 14: Configuration Setup
Configuration Setup Once the router is installed, it can be accessed locally through the menu-driven user interface via an asynchronous terminal or PC connection, or remotely via a Telnet session, and the router’s interfaces can be provisioned. The following provisioning can be set up: Frame relay, ATM, and physical layer provisioning –...
Page 15 Procedure To access the menu-driven user interface: 1. Verify the terminal or PC’s configuration: — Data Rate is set to 19.2 kbps. — Character Length is set to 8 data bits. — Parity is set to None. — Stop Bits is set to 1. —...
Page 16: Menu Navigation
Menu Navigation The router should operate using the default (factory-set) configuration options. Refer to the following table for help in navigating the menus. Press the . . . To . . . Esc key Go back one screen or menu level. For a visual display of the menu hierarchy, see the Quick Reference.
Page 17: Verifying That Self-Test Passed
Verifying that Self-Test Passed To verify that the unit passed its self-test, go to the System and Test Status screen. Main Menu → Status → System and Test Status The results of the self-test appear directly under the screen title. If any failure messages appear, reset the unit by disconnecting, then reconnecting the power cord.
Page 18: Completing Setup From The Noc
3. Specify TS Access if a Troubleshooting (TS) DLCI or Virtual Circuit (VC) is being set up for remote access by the service provider. The default is 0,35. 4. Select Create a Dedicated Network Management Link to set up for permanent remote access by the NOC.
Page 19: Setting Up For In-Band Management
Configuring SNMP Trap Managers and Traps Procedure To enter SNMP managers and configure traps: 1. Select SNMP Traps. Main Menu → Configuration → Management and Communication → SNMP Traps 2. Configure the following: — Enable SNMP Traps. — Identify the total Number of Trap Managers. —...
Page 20 Procedure 1. Create a DLCI on the router virtual port. Configuration → Vitual Router Ports → DLCI Records Assign the DLCI number that will be used for management on Serial port 0 (Rtr-S0 – e.g., DLCI 900). 2. Create a management PVC using the DLCI just configured on Serial port 0 to connect the management link to the router.
Page 21 Verifying the End-to-End Management Path After installation of a remote router, run an ATM Ping test from the Hotwire GranDSLAM. Procedure To Ping the router: 1. From the Hotwire ATM Line Card’s Main Menu, select the ATM Ping test. Diagnostics → ATM Ping (D-C) 2.
Page 22: Provisioning The Router Interface
Checking PVC Connections Check PVC connections to verify that all PVCs, including management PVCs, are configured and active. Procedure To verify PVCs: 1. Select PVC Connection Status from the Status menu. The PVC Connection Status screen shows all PVC connections, the interface source and DLCI number of the incoming data linked to the interface, and DLCI number for the outgoing data.
Page 23 The Ethernet interface connector uses an 8-pin, non-keyed modular plug. Use shielded twisted-pair CAT5, or better, cables. See Step 2 on page 8. — To connect the router to an Ethernet hub, use a straight-through connection. 8-Pin Straight-through Connections Ethernet Pin # Function Cable...
Page 24 The communication (COM) port connector uses a 9-position, EIA-232-C connector. Pin # Signal Direction Data Carrier Detect (DCD) To DTE (Out ) Receive Data (RD) To DTE (Out ) Transmit Data (TD) From DTE (In) Data Terminal Ready (DTR) From DTE (In) Signal Ground (GND) —...
Page 25: Router Technical Specifications
Router Technical Specifications Item Specification Approvals FCC Part 15 Class A digital device Safety Certifications Refer to equipment’s label for approvals on product Physical Environment Operating temperature 0°C to 50°C (32°F to 122°F) Storage temperature –20°C to 70°C (–4°F to 158°F) Relative humidity 5% to 85% (noncondensing) Shock and vibration...
Page 26: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
Page 27: Government Requirements
CE Marking When the product is marked with the CE mark on the equipment label, a supporting Declaration of Conformity may be downloaded from the Paradyne World Wide Web site at www.paradyne.com. Select Library → Technical Manuals → CE Declarations of Conformity.
Page 28: Warranty, Sales, Service, And Training Information
Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
