User Manual
Pepwave Surf Indoor Series:
Surf mini
Surf 400
Pepwave Surf DX Series:
400-DX
Document Rev. 9.0.33
June 10
C
& T
OPYRIGHT
RADEMARKS
Specifications are subject to change without notice. Copyright © 2010 Pepwave Ltd. All Rights Reserved. Pepwave and the
Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of
their respective owners.
Advertisement
Table of Contents
Related Manuals for Pepwave Surf mini
Summary of Contents for Pepwave Surf mini
-
Page 1: User Manual
Specifications are subject to change without notice. Copyright © 2010 Pepwave Ltd. All Rights Reserved. Pepwave and the Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners. -
Page 2: Table Of Contents
3 PRODUCT DESCRIPTION ..................4 ......................4 RODUCT EATURES ........................ 5 ARDWARE ETUP LED D ........................ 6 ESCRIPTION 4 USING THE PEPWAVE DEVICES ................9 PC S ....................9 CONFIGURING ETUP ......................10 IRST ETUP 5 CPE SETTINGS DETAILS ..................14 IP S ........................ -
Page 3: Copyright
Pepwave Ltd. Disclaimer Pepwave does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent right nor the patent rights of others. -
Page 4: Product Description
WPA/WPA2-Personal and WPA/WPA2-Enterprise security support Wi-Fi Multimedia (WMM) support Built-in DHCP server and NAT routing to manage client devices Customizable, built-in web portal for simple web-based configuration Surf mini Surf 400 Surf 400-DX http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 5: Hardware Setup
1. Attach the provided antenna to the right most antenna connector 2. Connect the LAN port to the computer’s Ethernet port with an Ethernet cable. 3. Connect the end of the included power adapter to the power socket on Pepwave Surf mini. 4. Power on the power adaptor. -
Page 6: Led Description
User Manual Pepwave PolePoint Series LED Description 3.3.1 Surf mini Series Color Status Description Green Power is on Power is off Green Device is booted Device is not booted Green Ethernet is connected ENET Blinking Sending/Receiving data Ethernet is not connected... - Page 7 Sending/Receiving data Not associated with any access point The number of lit signal bars depends on the Signal Bars Green strength of the received signal. A larger number of lit signal bars indicate stronger signals. http://www.pepwave.com Copyright @ 2010 Pepwave...
- Page 8 Ethernet is connected Ethernet is not connected Associated with an access point. The Green number of LED lights from “MIN” to “MAX” Wi-Fi indicates the received signal strength level. Not associated with any access point http://www.pepwave.com Copyright @ 2010 Pepwave...
-
Page 9: Using The Pepwave Devices
User Manual Pepwave PolePoint Series Using the Pepwave Devices Pre-configuring PC Setup You should set up your computer’s LAN interface to obtain an IP address automatically. In order to do so, select the Start menu > Control Panel > Network Connections. Right click on the Local Area Connection icon, choose Properties, and double-click on the item Internet Protocol (TCP/IP) from the list. -
Page 10: First Time Setup
Or you can go to the following URL: http://192.168.20.1/ The page will look like this. Illustration 1: Welcome Page http://www.pepwave.com Copyright @ 2010 Pepwave... - Page 11 User Manual Pepwave PolePoint Series Click the Advanced Config button to enter the parameters of the access point to associate to. You should see this screen: http://www.pepwave.com Copyright @ 2010 Pepwave...
- Page 12 User Manual Pepwave PolePoint Series Illustration 2: Pepwave Surf Setup Page In the field SSID under Wireless Settings, input the access point’s SSID (sometimes it is called the “network name”). According to the setting of the Access Point you are associating to, you may choose a different Authentication setting.
- Page 13 Pepwave PolePoint Series Illustration 3: Establishing Connection to the Internet At this point, you are associated with the access point. You may now close the web browser and open a new one to start web browsing. http://www.pepwave.com Copyright @ 2010 Pepwave...
-
Page 14: Cpe Settings Details
To configure and enable the built-in DHCP server or not. If enabled, the IP address DHCP Server range can be configured. Configure DHCP Reservation if there is a need to assign a specific IP address to a specific MAC address using DHCP. http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 15: Radio Settings
To select different channels that preferred to scan. If Single is selected, the option Scanning Scanned Channel would be shown. Mode Available options depend on the Radio Mode chosen. If auto is chosen, the device will Bit Rate choose the best bit rate dynamically and automatically. http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 16: Wireless Settings
Min Signal Preferred AP Strength, it will connect to this preferred access point, no matter the other access points are found even they have higher signal strength or the same SSID. http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 17: Roaming Settings
If there is another AP with a signal level greater than the signal level of Roaming Threshold connected AP by the specified value, it will reconnect to the AP with better (Signal Level Gain) signal. http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 18: Wireless Ip Settings
DHCP server automatically. Or select Obtain an IP Address using PPPOE and enter the fields for PPPOE connection. The AP Settings will be covered in detail in the subsequent section Integrated AP Settings Wi-Fi Access Point Configuration. http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 19: Restore And Reboot
By default, the login account is set as root and password is set as admin. Restore Factory When this option is clicked, default settings will be restored and the unit will be Settings restarted. Reboot CPE Click this button to restart the device. http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 20: Integrated Wi-Fi Access Point Configuration
SSID scan. In order to connect with the access point, the SSID needs to be known by the client. Prevent wireless clients connected to the AP from communicating with each Client Isolation other. http://www.pepwave.com Copyright @ 2010 Pepwave... - Page 21 Static WEP Key Authentication A 64- or 128-bit Encryption Key is required, and can be entered in either an ASCII or HEX representation. WPA/WPA2-Personal • An Encryption Key, of at least 8 characters, is required. http://www.pepwave.com Copyright @ 2010 Pepwave...
- Page 22 WPA/WPA2-Enterprise, then the Configure Automatically option of the Access Point Configuration becomes unavailable, because the Integrated Wi-Fi Access Point functionality currently does not support authentication via the 802.1x with dynamic WEP key and WPA/WPA2-Enterprise methods. http://www.pepwave.com Copyright @ 2010 Pepwave...
-
Page 23: Port Forwarding
TCP and UDP. IP Address The IP address that you would like the traffics forwarded to. By clicking the button, you can delete the corresponding rows of port forwarding rules. Illustration 14: Port Forwarding http://www.pepwave.com Copyright @ 2010 Pepwave... - Page 24 Pepwave PolePoint Series Below the port forwarding table is an option called DMZ Host. If you Enable this function, your Pepwave Surf will become a DMZ device. You can enter an IP address, which will be the IP address of the device that expose to the Internet.
-
Page 25: Qos
There are three choices for service priority: Background, Video and Voice. By Priority choosing Default, priority will be automatically adjusted. By clicking the button, you can delete the corresponding rows of port forwarding rules. Illustration 15: QoS http://www.pepwave.com Copyright @ 2010 Pepwave... -
Page 26: Firmware Upgrade
Pepwave PolePoint Series Firmware Upgrade The Pepwave devices are able to check whether a newer firmware (the software running on the unit) is available. However, it is recommended that you do not update the firmware unless specifically instructed by your ISP to do so. -
Page 27: Debug And System Information
User Manual Pepwave PolePoint Series Debug and System information Illustration 17: Debug tab showing the system information http://www.pepwave.com Copyright @ 2010 Pepwave... - Page 28 Debug dump and configuration file can be downloaded through clicking the links illustrated above. If encounter issues would like contact Pepwave Support Team (email: support@pepwave.com), please download the above files and attach it along with a description of your encountered issue. http://www.pepwave.com Copyright @ 2010 Pepwave...
-
Page 29: Restore To Default Settings
10 Restore to Default Settings 10.1 Surf Indoor Series There are two ways to restore the Pepwave Surf Indoor unit to default settings. If you are able to access the web admin interface, go to the CPE Setup page, and click the Restore and Reboot button. -
Page 30: Appendix
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. http://www.pepwave.com Copyright @ 2010 Pepwave... - Page 31 Contact Us: Address: Sales United States Office Hong Kong Office http://www.pepwave.com/contact/sales/ 800 West El Camino Real, 17/F, Park Building, 476 Castle Peak Road Support Mountain View Cheung Sha Wan http://www.pepwave.com/contact/ CA 94040 Hong Kong United States Business Development and...
