PePWave Surf Series
PePWave Surf Indoor Series:
Surf 200, AP 200, AP 400
PePWave Surf Outdoor Series:
Surf AP 200/400-X, PolePoint 400-X, Surf 400-DX
User Manual
Document Rev. 1.2
July 07
C
& T
OPYRIGHT
RADEMARKS
Specifications are subject to change without notice.
Copyright © 2007 PePWave Ltd. All Rights Reserved.
PePWave and the PePWave logo are trademarks of PePWave Ltd. Other brands or products mentioned may be
trademarks or registered trademarks of their respective owners.
Advertisement
Table of Contents
Related Manuals for Pepwave Surf Series
Summary of Contents for Pepwave Surf Series
-
Page 1: User Manual
Specifications are subject to change without notice. Copyright © 2007 PePWave Ltd. All Rights Reserved. PePWave and the PePWave logo are trademarks of PePWave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners. -
Page 2: Table Of Contents
PePWave Surf Series User Manual Table of Contents COPYRIGHT ............................. 3 DISCLAIMER............................. 3 PRODUCT DESCRIPTION ......................... 4 .............................4 EATURES ........................5 ARDWARE ETUP LED D ........................5 ESCRIPTION USING THE PEPWAVE SURF ......................7 ...........................8 IRST ETUP ........................11 ETTINGS ETAILS ............13 NTEGRATED... -
Page 3: Copyright
PePWave Ltd. Disclaimer PePWave does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent right nor the patent rights of others. PePWave further reserves the right to make changes in any products described herein without notice. -
Page 4: Product Description
PePWave Surf Series User Manual Product Description PePWave Surf is a feature-rich Wi-Fi CPE with WPA, WPA2 and 802.1x supplicant support. It is designed to act as a Wireless router and connects LAN users with a Wireless Broadband Internet Service (such as Citywide Wi-Fi). -
Page 5: Hardware Setup
PePWave Surf Series User Manual Hardware Setup 3.2.1 Surf Indoor Series Attach the provided antenna to the left most antenna connector Connect the LAN port to the computer’s Ethernet port with an Ethernet cable. Connect the end of the included power adapter to the power socket (labeled “DC 5V”) on PePWave Surf. - Page 6 PePWave Surf Series User Manual Color Status Description Green Associated with an access point Wi-Fi Green Blinking Sending/Receiving data Not associated with any access point The number of lit signal bars depends on the strength Signal Green of the received signal. A larger number of lit signal bars Bars indicate stronger signals.
-
Page 7: Using The Pepwave Surf
PePWave Surf Series User Manual Using the PePWave Surf You should set up your computer’s LAN interface to obtain an IP address automatically. If you do so, you should have set it up correctly. In order to do so, select the “Start” menu, “Control Panel” and then “Network Connections”. -
Page 8: First Time Setup
PePWave Surf Series User Manual First Time Setup On your PC, start a web browser, e.g. Internet Explorer, Mozilla Firefox, etc. Visit an Internet web site. If you are not associated to an access point, you should be redirected to a logon page. - Page 9 PePWave Surf Series User Manual Click the “Advanced Config” button to enter the parameters of the access point to associate to. You should see this screen: In the field “SSID” under Wireless Settings, input the access point’s SSID (sometimes it is called the “network name”).
- Page 10 PePWave Surf Series User Manual At this point, you are associated with the access point. You may now close the web browser and open a new one to start web browsing. Page 10...
-
Page 11: Settings Details
PePWave Surf Series User Manual Settings Details LAN Interface: To configure the LAN interface’s IP address and subnet mask. DHCP Server: To configure and enable the built-in DHCP server or not. If enabled, the IP address range can be configured. - Page 12 MTU Size: You may also set the MTU Size to increase the data packet size your Surf can handle at one time. AP Settings: These settings apply only to the PePWave Surf AP model, and configure the properties of the Integrated Wi-Fi Access Point. The AP Settings will be covered in detail in the subsequent section Integrated Wi-Fi Access Point Configuration.
-
Page 13: Integrated Home W I -F I Access Point Configuration
PePWave Surf Series User Manual Integrated Wi-Fi Access Point Configuration Integrated Wi-Fi Access Point is configured via the CPE Setup tab. The following sections will provide information as a guide through the configuration. This session is not applicable for PePWave Surf DX series. - Page 14 PePWave Surf Series User Manual Access Point Disabled 4.3.2 Access Point Disabled, as shown with the red marker box Page 14...
- Page 15 PePWave Surf Series User Manual Manual Access Point configuration 4.3.3 Manual Access Point Configuration, as shown with the red marker box Page 15...
- Page 16 PePWave Surf Series User Manual In Manual Configuration mode, the SSID is manually entered. Authentication can be one of three configurable values: Open For Open Authentication Mode, no Encryption Key is necessary. Static WEP Key For Static WEP Key Authentication Mode, a 64- or 128-bit Encryption Key is required, and can be entered in either an ASCII or HEX representation.
- Page 17 PePWave Surf Series User Manual A.1.1 Automatic Access Point Configuration Auto. Access Point Configuration, as shown with the red marker box With the Access Point Configuration set to Configure Automatically, the SSID, Authentication, and Encryption Key values of the Integrated Home Wi-Fi Access Point will be configured to be the same as in the Wireless Settings section.
- Page 18 PePWave Surf Series User Manual Important Note: In the Wireless Settings section, if Authentication is set to either 802.1x with dynamic WEP key or WPA/WPA2-Enterprise, then the Configure Automatically option of the Access Point Configuration becomes unavailable, because the Integrated Home Wi-Fi Access Point functionality currently does not support authentication via the 802.1x with dynamic...
- Page 19 PePWave Surf Series User Manual Automatic Access Point Configuration is unavailable with WPA/WPA1-Enterprise Authentication Page 19...
-
Page 20: Test The Setup
PePWave Surf Series User Manual Test the Setup To test to setup, you can now go to the PePWave Surf’s Main page, enter the user name and password. The realm (the text box next to the “@” sign) value can be left empty. Then click the Connect button. -
Page 21: Firmware Upgrade
PePWave Surf Series User Manual Firmware Upgrade The PePWave Surf is able to check whether a newer firmware (the software running on the PePWave Surf) is available. This can be done in the Firmware Upgrade section. However, it is recommended that you do not update the firmware unless specifically instructed by your ISP to do so. - Page 22 476 Castle Peak Road Cheung Sha Wan Hong Kong Tel: +852-2786-9228 Fax: +852-3007-0588 h t t p : / / w w w . p e p w a v e . c o m Copyright © 2007 PePWave Ltd. All Rights Reserved.
