User Manual
Pepwave OfficePoint Indoor Series
200 / 400
Pepwave OfficePoint Outdoor Series
400-DX
Document Rev.2.1.6
Dec-10
C
& T
OPYRIGHT
RADEMARKS
Specifications are subject to change without notice. Copyright © 2010 Pepwave Ltd. All Rights Reserved. Pepwave and the
Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of
their respective owners.
Advertisement
Table of Contents
Related Manuals for Pepwave Pepwave OfficePoint Indoor 200
Summary of Contents for Pepwave Pepwave OfficePoint Indoor 200
-
Page 1: User Manual
Specifications are subject to change without notice. Copyright © 2010 Pepwave Ltd. All Rights Reserved. Pepwave and the Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners. -
Page 2: Table Of Contents
User Manual Pepwave OfficePoint Series Table of Contents 1 INTRODUCTION AND SCOPE ................. 3 2 PRODUCT FEATURES ..................... 4 3 PACKAGE CONTENTS .................... 5 4 PEPWAVE OFFICEPOINT OVERVIEW ..............6 ......................... 6 RONT ........................ 7 ANEL 5 INSTALLATION ......................9 .................... -
Page 3: Introduction And Scope
Pepwave OfficePoint is an enterprise grade 802.11b/g Wi-Fi access point with centralized management system. It is a powerful solution for building wireless networks for all business needs. Each Pepwave OfficePoint is loaded with essential features such as Multiple SSID, VLAN, AutoMesh and Guest Protect. -
Page 4: Product Features
User Manual Pepwave OfficePoint Series Product Features Key features of Pepwave OfficePoint: • High-power output enhances coverage and lowers cost of ownership • Independent security policies and encryption mechanisms per virtual AP • Centralized management via InControl • AutoMesh Support for secure and fast network expansion •... -
Page 5: Package Contents
User Manual Pepwave OfficePoint Series Package Contents The following items are the contents of a Pepwave OfficePoint indoor package: • 1 x Pepwave OfficePoint indoor unit • 1 x Omni-directional antenna • 1 x Power Supply Unit • 1 x Passive PoE •... -
Page 6: Pepwave Officepoint Overview
User Manual Pepwave OfficePoint Series Pepwave OfficePoint Overview Front View OfficePoint 200, 400 OfficePoint 400-DX http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 7: Rear Panel View
Status ON – The unit is ready. OFF – The Ethernet port is not connected. Ethernet ON – The Ethernet port is connected. OFF – Wireless is not ready. Wireless On – Wireless is ready. http://www.pepwave.com Copyright © 2010 Pepwave... - Page 8 One LED on: 1-10 clients; Two LEDs on: 11-20 clients; WIFI Three LEDs on: 21-30 clients; Four LEDs on: 31-40 clients; Five LEDs on: 40 clients above. Off: Wi-Fi is not ready http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 9: Installation
User Manual Pepwave OfficePoint Series Installation Pepwave OfficePoint acts as a bridge between the wireless and the wired Ethernet interface. A typical setup is as follows: Installation Procedures 1. Attach the antenna to the Pepwave OfficePoint unit. 2. Connect the LAN port on the unit with the backbone network using an Ethernet cable. The port could auto sense the cable is straight-through or cross-over. -
Page 10: Information
This shows the time has been up since boots up. Click on the Detail link beside the Network IP Information to check the following system information: IP Address Mode, IP Address, Subnet Mask, Default Gateway, DNS Server. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 11: Wireless
Click on the Info link to check the following wireless information: Web Portal Login, Wireless Network Firewall, MAC Filter, Bandwidth Control, Layer 2 Isolation. Click on the Stat link to check the following networking statistics: Packets Sent, Bytes Sent, Packets Received, Bytes Received. http://www.pepwave.com Copyright © 2010 Pepwave... - Page 12 Authentication This shows the client authentication method(s). Status Type This shows the radio mode of the client. Connection Length This shows the associated duration. Click on the Details link, more networking statistics will be provided. http://www.pepwave.com Copyright © 2010 Pepwave...
- Page 13 This shows the receive data rate of the client from the AP. Transmit Data Rate This shows the transmit data rate of the client to the AP. Signal (RSSI) This shows the signal strength received by the client. http://www.pepwave.com Copyright © 2010 Pepwave...
- Page 14 This shows the channel of the existing Bssid. Signal (RSSI) This shows the signal strength. Last Seen This indicates the time stamp of the access point sc Status This shows the current status of this nearby network. http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 15: Automesh
This shows the channel of the existing Bssid. Signal (SNR) This value shows the signal strength of the neighbor AutoMesh members. Level This shows the signal strength of the node. State This shows the hop level of the node. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 16: Configuration
A user-specified name for the location of the access point. Location This value can be retrieved via SNMP. This option specifies the time region to be used for representing the time on Time zone the system. http://www.pepwave.com Copyright © 2010 Pepwave... - Page 17 This setting specifies the subnet mask of the Pepwave OfficePoint unit. Default Gateway This setting specifies the default gateway of the Pepwave OfficePoint unit. This is the DNS server address to be used by the Pepwave OfficePoint unit for DNS Server resolving host names.
- Page 18 This is the Network Time Protocol (NTP) Server hostname to be used for NTP Server synchronizing system clock of Pepwave OfficePoint. The default value of this setting is pool.ntp.org. The system would perform reboot based on the scheduled time set. Click the Scheduled Reboot box above the Schedule to Enable this feature.
- Page 19 This setting specifies the length of time throughout which an IP address of a DHCP client remains valid. Upon expiration of the Lease Time, the assigned IP Lease Time address will no longer be valid and the renewal of the IP address assignment will be required. http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 20: Wireless Networks
This setting specifies the VLAN ID to be tagged on all outgoing packets generated from the virtual AP (i.e. packets that travel from the Wi-Fi segment, through the Pepwave OfficePoint unit to Ethernet segment via the LAN port). Default VLAN ID If 802.1x is enabled, a per-user VLAN ID can be specified in the authentication... - Page 21 Available options are: Open - No Encryption, Static WEP, 802.1X, WPA-TKIP, WPA2-AES:CCMP. Selecting Open - No Encryption disables encryption. Security Level For details on the other options, please refer to: 7.2.1.1 - Static WEP Parameters 7.2.1.2 - 802.1x Parameters 7.2.1.3 - WPA Parameters http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 22: Static Wep
For ASCII format, key length is either 5 or 13. For HEX format, key length is either 10 or 26. Shared Key This setting enables the use of shared key authentication. Open Authentication authentication is the default authentication. http://www.pepwave.com Copyright © 2010 Pepwave... - Page 23 When WPA-PSK or WPA2-PSK is configured, a Pre-Shared Key, or Passphrase, is used for data encryption and authentication. Under this configuration, the Pre-Shared Key option should be enabled. Key length must be between 8 and 63 characters (inclusive). The security level of this method is known to be high. http://www.pepwave.com Copyright © 2010 Pepwave...
- Page 24 By default, it is set as 3. This specifies the time interval in second between each RADISU request Radius Request attempt. Note that the request time interval would be doubled every Interval retransmission. By default, it is set as 3s. http://www.pepwave.com Copyright © 2010 Pepwave...
- Page 25 Pepwave OfficePoint Series 7.2.2 Web Portal Login Simply registering the devices with Pepwave InControl, users can apply configurations, firmware, and monitor network activity remotely through this centralized management system. For more details, you can refer to Pepwave website at: http://www.pepwave.com/products/incontrol/.
- Page 26 5. On the "Edit a wireless network" screen, click "Web Portal Login" tab. Click "Enable" to enable the Web Portal Login function. Click "OK" to continue. 6. Click "Save" button to save the changes. http://www.pepwave.com Copyright © 2010 Pepwave...
- Page 27 9. You can generate more than one account at one time. Change the parameters in the fields No. of accounts to be generated, Username prefix, Sequence number suffix and Time Quota. Default time limit is set to 24 hours. You can change the time limit. http://www.pepwave.com Copyright © 2010 Pepwave...
- Page 28 12. A standard portal page will be generated automatically after guest accounts are generated (http://guest.pepwave.com). You can customize the portal page by clicking on the "Portal Page Customization" tab. In the screen upload your logo image and enter message for guests. You can preview your portal page and then publish the portal page.
- Page 29 Disable – Firewall mode is disabled. (Default option) This setting specifies the exceptions when Lockdown or Flexible Firewall Exceptions Mode is selected. Exceptions can be added by types, including Port, Domain, IP Address, MAC Address, Application /Service. http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 30: Mac Filter
User Manual Pepwave OfficePoint Series 7.2.4 MAC Filter The settings allow administrator to control the access through Mac address filtering. Available options are: None, Deny all except listed, Accept all except listed. http://www.pepwave.com Copyright © 2010 Pepwave... - Page 31 This setting specifies the VLAN ID to be tagged on all outgoing packets generated from the virtual AP (i.e. packets that travel from the Wi-Fi segment, through the Pepwave OfficePoint unit to Ethernet segment via the LAN port). If 802.1x is enabled and a per-user VLAN ID is specified in the authentication...
- Page 32 Pepwave OfficePoint Series The 802.1p QoS value to be marked on all outgoing packets generated from the virtual AP (i.e. packets that travel from the Wi-Fi segment, through the Pepwave OfficePoint unit to Ethernet segment via the LAN port). Network Priority (QoS) If per-user or per-domain QoS value is specified, the Default Quality of Service value will be overridden.
-
Page 33: Advanced Wireless Settings
802.11g Only: Pepwave OfficePoint accepts only 802.11g client association requests. This setting specifies the country / region whose regulations the Pepwave OfficePoint unit should follow. If United States is selected, RF channels 1 to 11 are available. Maximum Operating Country transmission power is 26 dBm (400 mW) for models of MPW-4xx, or 23dBm (200 mW) for models of MPW-2xx. -
Page 34: Advanced Features
For Pepwave OfficePoint Outdoor units, the hardware may be equipped with two antennas for transmit and receive diversity. Antenna Selection If the Pepwave OfficePoint unit is equipped with two antennas, users can select Main, Aux. and Both (antenna diversity). By default, Main is selected. - Page 35 This setting provides the option to specify the timeout for the unit to wait for CTS Timeout CTS response in the RTS/CTS handshake. Enable this setting to in favor of 802.11g devices in mixed mode (11g and 11b) 802.11g Protection networks. http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 36: Automesh
Disable – the unit would not link to any AP. This setting gives the encryption key to secure the data between APs. AutoMesh Number You can click the link Hide / Show Passphrase to show or hidden the above encryption key. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 37: Snmp
Once this option is enabled, the following two options for SNMP Trap will be available for configuration. SNMP Trap This setting specifies the name that identifies the SNMP Trap Receiver. Receiver Name SNMP Trap This setting specifies the IP address of the SNMP Trap Receiver. IP Address http://www.pepwave.com Copyright © 2010 Pepwave... - Page 38 The password for getting or setting SNMP values. IP Address and IP The allowed IP and subnet address which can access the SNMP server. Mask Access Mode Choose either Read Only or Read & Write. Status Enable or Disable this community. http://www.pepwave.com Copyright © 2010 Pepwave...
-
Page 39: Snmpv3 Users
This option is shown only if CBC-DES is chosen as the Privacy Protocol. This Privacy Password is the key for decrypting the encrypted data. Access Mode Grant Read or Read & Write access to this user. Status Enable or Disable this user. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 40: Web Administration
If HTTPS is enabled, HTTP to HTTPS Redirection option will be provided. 7.6.2 Admin Username The selection Admin Username configures the administrator username for entering Web Admin Interface. To change to the Username, enter the new username into the Username input fields. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 41: Web Administration
To change to the password, enter the same new password into the New Password and New Password (Retype) input fields. 7.6.4 Web Administration The selection Disable Web Administration turns off the access to Web Administration Interface. After being turned off, Web Administration Interface can be re-enabled using SNMP. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 42: Tools - Diagnostic Tools
User Manual Pepwave OfficePoint Series Tools - Diagnostic Tools This provides three useful tools for diagnosing the network. The three available options are: Ping, Traceroute and Nslookup. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 43: Commands
Upon selecting Commands from the navigation bar on the left-hand-side of the Main Menu, a list of commands is displayed, as follows: Activate Changes Click on Activate Changes and a prompt will ask and confirm to save configuration and activate the OfficePoint unit. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 44: Firmware
This indicates which flash partition boots up the system. Firmware Upgrade This shows which flash partition is used for firmware upgrade. Target Upload a firmware file for upgrading the unit’s software. A reboot is required Firmware Image File after upgrading the firmware. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 45: Configuration
Preserve the network settings by enabling Preserve Settings. Download Active Select this command to download the active configuration for backup Configuration To purposes. File Upload Select this command to upload the configuration from a backed up Configuration File configuration file. http://www.pepwave.com Copyright © 2010 Pepwave... -
Page 46: Misc
Download Debug In the event of technical issues, to facilitate prompt resolution by technical Information support from Pepwave, please send along with a debug file with the support request. Reboot AP This option is for rebooting the Pepwave OfficePoint unit. -
Page 47: Restoration Of Factory Defaults
3. The Status LED will blink, and then the unit will automatically reboot. 4. 4. Wait for 1 minute or until the Status LED turns green, upon which the settings of Pepwave OfficePoint will have been restored to the factory defaults. -
Page 48: Appendix A
User Manual Pepwave OfficePoint Series Appendix A. Radius Server Setup Pepwave OfficePoint has been test to be functional with Radiator version 3.9, using the EAP-TTLS protocol. For Pepwave OfficePoint, configure the authentication protocol of the virtual access point to WPA- AES:CCMP. -
Page 49: Appendix B
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. http://www.pepwave.com Copyright © 2010 Pepwave... - Page 50 Contact Us: Address: Sales http://www.pepwave.com/contact/sales/ United States Office Hong Kong Office Support 800 West El Camino Real, 17/F, Park Building, http://www.pepwave.com/contact/ 476 Castle Peak Road Mountain View Cheung Sha Wan CA 94040 Business Development and Hong Kong United States...
