Pepwave AP One Series:
AP One Enterprise / AP One AC mini / AP One In-Wall / AP One Rugged /
AP One Flex 300M
Pepwave AP Pro Series:
AP Pro / AP Pro 300M / AP Pro Duo
May 2016
C
& T
OPYRIGHT
RADEMARKS
Specifications are subject to change without notice.
Copyright © 2016 Pepwave Ltd. All Rights Reserved.
Pepwave and the
Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of
their respective owners.
Advertisement
Table of Contents
Related Manuals for Pepwave AP Pro
Summary of Contents for Pepwave AP Pro
- Page 1 Specifications are subject to change without notice. Copyright © 2016 Pepwave Ltd. All Rights Reserved. Pepwave and the Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners.
-
Page 2: Table Of Contents
AP One In-Wall ....................6 AP One Rugged ....................6 AP One Flex 300M ....................6 AP Pro / AP Pro 300M / AP Pro Duo ..............6 Hardware Overview ....................6 AP One Enterprise ....................7 AP One AC mini ....................8 AP One In-Wall .................... - Page 3 Monitoring Device Status ..................50 Device ........................ 51 Client List ......................51 WDS Info......................51 Portal ......................... 52 Rogue AP ......................52 Event Log ......................53 Restoring Factory Defaults ................53 Appendix ......................55 Datasheets ......................55 http://www.pepwave.com Copyright © Pepwave 5/23/16...
-
Page 4: Introduction And Scope
(802.1x, open, captive portal, etc.), allowing faster, easier, and more cost- effective network builds. Each member of the AP Series family also features a high- powered Wi-Fi transmitter that greatly enhances coverage and performance while reducing equipment costs and maintenance. http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 5: Product Features And Benefits
• WDS support allows secure and fast network expansion. • Guest Protect support guards sensitive business data and subnetworks. • WMM (Wi-Fi Multimedia) and QoS (Quality of Service) support keeps video and other bandwidth-intensive data flowing fast and lag-free. Package Contents http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 6: Ap One Enterprise
1 x AP One Flex 300M 1 x Instruction sheet AP Pro / AP Pro 300M / AP Pro Duo 1 x AP Pro / AP Pro 300M / AP Pro Duo 1 x Instruction sheet 1 x Installation guide Hardware Overview http://www.pepwave.com... -
Page 7: Ap One Enterprise
OFF – No device connected to Ethernet port BLINKING – Ethernet port sending/receiving data LAN 1 ON – Powered-on device connected to Ethernet port Note that LAN 5 displays the status of the uplink connection http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 8: Ap One Ac Mini
BLINKING – AP sending/receiving data Wi-Fi GREEN – 2.4/5GHz Wi-Fi radio on Note that this model includes a 2.4GHz Wi-Fi radio and a 5GHz Wi-Fi radio that can operate simultaneously to increase speed and reduce interference. http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 9: Ap One In-Wall
OFF – No device connected to Ethernet port BLINKING – Ethernet port sending/receiving data LAN 1-5 ON – Powered-on device connected to Ethernet port Note that LAN 5 displays the status of the uplink connection http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 10: Ap One Rugged
BLINKING – AP sending/receiving data Wireless GREEN – 2.4/5GHz Wi-Fi radio on Note that this model includes a 2.4GHz Wi-Fi radio and a 5GHz Wi-Fi radio that can operate simultaneously to increase speed and reduce interference. http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 11: Ap One Flex 300M
GREEN – Access point ready OFF – No device connected to Ethernet port BLINKING – Ethernet port sending/receiving data ON – Powered-on device connected to Ethernet port Number of connected clients (1-10, 11-20, 21-30, 31-40) http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 12: Ap Pro / Ap Pro 300M / Ap Pro Duo
AP Pro / AP Pro 300M / AP Pro Duo Front/Top View Rear Panel View http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 13: Installation
Installation Your access point acts as a bridge between wireless and wired Ethernet interfaces. A typical setup follows: http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 14: Installation Procedures
Google Chrome 2.0 or above, connect to https://192.168.0.3. 6. Enter the default admin login ID and password, admin and public respectively. 7. After logging in, the Dashboard appears. Click the System tab to begin setting up your access point. http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 15: Using The Dashboard
When your access point is connected to a WAN, this field displays the WAN IP address. For more information, click the Details… link, which displays the following: IP Address Status This field displays the current WAN connection status. http://www.pepwave.com Copyright © Pepwave 5/23/16... - Page 16 Model This field displays your access point’s model number. Firmware The firmware version currently running on your access point appears here. Uptime This field displays your access point’s uptime since the last reboot or shutdown. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 17 The channel currently used by your access point is displayed in this field. If your access point is using a VLAN ID for management traffic, it will appear here. A VLAN value of 0 indicates that a VLAN ID is not being used. http://www.pepwave.com Copyright © Pepwave 5/23/16...
-
Page 18: Configuration
Configuration http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 19: System
This field specifies the administrator username of the web admin. It is set as admin by Name default. This field allows you to specify a new administrator password. The default password is Admin Password public. http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 20: Firmware
7.1.2 Firmware http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 21: Time
Time region used by the system. All choices are based on UTC. To choose a time server other than the default, enter the URL here. To restore the Time Server default time server, click the Default button. 7.1.4 Event Log http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 22: Snmp
Remote Syslog Enter the IP address or hostname of the remote syslog server, as well as the port number. Host 7.1.5 SNMP SNMP, or simple network management protocol, is an open standard that can be used http://www.pepwave.com Copyright © Pepwave 5/23/16... - Page 23 This option allows you to enable SNMP version 1. SNMPv2c This option allows you to enable SNMP version 2c. SNMPv3 This option allows you to enable SNMP version 3. To add a community for either SNMPv1 or SNMPv2c, click the Add SNMP Community http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 24 Select None or CBC-DES as the SNMPv3 privacy protocol. When CBC-DES is Privacy Protocol selected, an entry field will appear for the password. Access Mode Select Read Only or Read and Write as the SNMPv3 access mode. http://www.pepwave.com Copyright © Pepwave 5/23/16...
-
Page 25: Controller
In section, you can manage and backup access point configurations, as well as reset your access point to its factory configuration. Backing up your access point’s settings immediately after successful initial setup is strongly recommended. http://www.pepwave.com Copyright © Pepwave 5/23/16... -
Page 26: Reboot
You can select the firmware version you would like to reboot the device with. The firmware marked with (Running) is the current system boot up firmware. Please note that a firmware upgrade will always replace the inactive firmware partition. http://www.pepwave.com Copyright © Pepwave 5/23/16... - Page 27 Use the controls on the AP tab to set the wireless SSID and AP settings, as well as wireless distribution system (WDS) settings. 7.2.1 Wireless SSID Wireless network settings, including the name of the network (SSID) and security policy, can be defined and managed in this section. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 28 Otherwise, select None. If you use a distributed DHCP server/relay environment, you can enable this option to DHCP Option 82 provide additional information on the manner in which clients are physically connected to the network. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 29 Open (No Encryption), WEP, 802.1X, WPA2 – Personal, WPA2 – Security Policy Enterprise, WPA/WPA2 - Personal, and WPA/WPA2 – Enterprise. To allow any Wi-Fi client to access your AP without authentication, select Open (No Encryption). Details on each of the available authentication methods follow. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 30 This option specifies the length of time throughout which the broadcast key remains valid. When the re-keying period expires, the broadcast key is no longer valid and Re-keying Period broadcast key renewal is required. The default is 14400 seconds (four hours). 0 disables re-keying. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 31 When v2 is selected, only v2 clients can associate with 802.1X Version the access point. Most modern wireless clients support v2. For stations that do not support v2, select v1. The default is v2. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 32 This menu determines how your usage quota resets. Setting it to Daily will reset it at a Quota Reset Time specified time every day. Setting a number of minutes after quota reached establishes a timer for each user that begins after the quota has been reached. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 33 None, Deny all except listed, Accept all except listed, and RADIUS MAC Authentication. Connections coming from the MAC addresses in this list will be either denied or MAC Address List accepted based on the option selected in the previous field. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 34 1813. Maximum Enter the maximum number of allowed retransmissions. Retransmission RADIUS Request Enter a value in seconds to limit RADIUS request frequency. Note the initial value will Interval double on each retransmission. http://www.pepwave.com Copyright © Pepwave 5/23/16...
- Page 35 Enter a value in kpbs to limit connected clients’ upstream bandwidth. Enter 0 to allow Limit unlimited upstream bandwidth. Client Enter a value in kpbs to limit connected clients’ downstream bandwidth. Enter 0 to allow http://www.pepwave.com Copyright © Pepwave 5/23/16...
