Wirelessly Connecting a Home Network with PePWave Surf AP 200 and 400
I n t e g r a t e d H o m e W i - F i A c c e s s P o i n t S e t u p G u i d e
Overview
Integrated Home Wi-Fi Access Point – Introduction
Wirelessly Connecting a Home Network
This guide presents a brief introduction, and a step-by-step process, to
configure a basic setup for the Integrated Home Wi-Fi Access Point
functionality of PePWave Surf AP 200 and 400.
Prior to carrying out the setup procedure in this
guide, the process of connecting PePWave Surf
AP 200/400 with Citywide Wi-Fi must have been
successfully performed.
The high-level steps are as follows:
1. Set up Integrated Home Wi-Fi Access
Point on PePWave Surf AP 200/400
2. Configure Wi-Fi enabled host PC(s)
3.
Test the Wi-Fi connection(s) with PePWave Surf AP 200/400
Integrated Home Wi-Fi Access Point functionality of PePWave Surf AP 200/400 allows
802.1b/g devices on customers' premises to wirelessly connect with a PePWave Surf
AP 200/400 unit through which Citywide Wi-Fi is accessed. With PePWave Surf AP
200/400, the already existing Ethernet capabilities of the PePWave Surf Series
remain unaffected.
Figure 1 – PePWave Surf AP 200/400 and Integrated Home Wi-Fi Access Point
1
How-to Document
PePWave Surf AP 200 and 400
Copyright © 2007 PePWave Ltd.
Advertisement
Related Manuals for Pepwave Surf AP 200
Summary of Contents for Pepwave Surf AP 200
- Page 1 AP 200/400 unit through which Citywide Wi-Fi is accessed. With PePWave Surf AP 200/400, the already existing Ethernet capabilities of the PePWave Surf Series remain unaffected. Figure 1 – PePWave Surf AP 200/400 and Integrated Home Wi-Fi Access Point Wirelessly Connecting a Home Network Copyright © 2007 PePWave Ltd.
-
Page 2: Setup Procedure
From the configuration and connections performed in the Prerequisite Setup, the Web-based Configuration Interface of PePWave Surf AP 200/400 should remain accessible via a host PC connected via Ethernet to the PePWave Surf AP 200/400 unit. Configure the Integrated Home Wi-Fi Access Point settings as follows: 1. - Page 3 How-to Document PePWave Surf AP 200 and 400 3. In the section AP Settings, select the radio button labeled Configure Manually. Upon the selection, further configuration parameters are displayed. Figure 3 – The AP Settings section on the CPE Setup page Figure 4 –...
- Page 4 6. In the Encryption Key field, enter an alphanumeric value that is difficult to guess, and contains at least 8 characters. The same value as the one entered here will subsequently be used when configuring host PC(s) that connect with Integrated Home Wi-Fi Access Point of PePWave Surf AP 200/400. illustration purposes,...
- Page 5 PePWave Surf AP 200/400, via the URL http://192.168.20.1 Upon successfully connecting, the Welcome Screen is displayed. After successfully testing the connection between the Wi-Fi enabled host PC and PePWave Surf AP 200/400, test the connection with the Internet by visiting our website at www.pepwave.com. PePWave Technical Support...
