User Manual
Pepwave Surf Series:
Surf mini
Surf 400
Surf 400-DX
July 11
C
& T
OPYRIGHT
RADEMARKS
Specifications are subject to change without notice. Copyright © 2011 Pepwave Ltd. All Rights Reserved. Pepwave
and the Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or
registered trademarks of their respective owners.
Advertisement
Table of Contents
Related Manuals for Pepwave Surf mini
Summary of Contents for Pepwave Surf mini
-
Page 1: User Manual
Specifications are subject to change without notice. Copyright © 2011 Pepwave Ltd. All Rights Reserved. Pepwave and the Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners. -
Page 2: Table Of Contents
PGRADE ..................... 26 EBUG AND YSTEM INFORMATION 4.10 ....................27 ESTORE TO EFAULT ETTINGS APPENDIX: ............................28 FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT ..........28 Pepwave Surf / Surf AP / Surf DX Series - 2 - Copyright © 2011 Pepwave... -
Page 3: Copyright
Pepwave Ltd. Disclaimer Pepwave does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent right nor the patent rights of others. Pepwave further reserves the right to make changes in any products described herein without notice. -
Page 4: Product Description
Built-in DHCP server and NAT routing to manage client devices Customizable, built-in web portal for simple web-based configuration Surf mini /400 Surf 400-DX Pepwave Surf / Surf AP / Surf DX Series - 4 - Copyright © 2011 Pepwave... -
Page 5: Hardware Setup
1. Attach the provided antenna to the right most antenna connector 2. Connect the LAN port to the computer’s Ethernet port with an Ethernet cable. 3. Connect the end of the included power adapter to the power socket on Pepwave Surf mini. -
Page 6: Led Description
The number of lit signal bars depends on the Number of strength of the received signal. A larger number of lit signal bars indicate stronger signals. Pepwave Surf / Surf AP / Surf DX Series - 6 - Copyright © 2011 Pepwave... - Page 7 Associated with an access point. The number of LED lights from “MIN” to Green “MAX” indicates the received signal Wi-Fi strength level. Not associated with any access point Pepwave Surf / Surf AP / Surf DX Series - 7 - Copyright © 2011 Pepwave...
-
Page 8: Using The Pepwave Devices
Internet Protocol (TCP/IP) from the list. On the screen, just set it as follows: Click the OK button to confirm the change. Pepwave Surf / Surf AP / Surf DX Series - 8 - Copyright © 2011 Pepwave... -
Page 9: First Time Setup
Internet web site. If you are not associated to an access point, you should be redirected to a logon page. Or you can go also go to this URL http://192.168.20.1/ The page will look like this. Illustration 1: Welcome Page Pepwave Surf / Surf AP / Surf DX Series - 9 - Copyright © 2011 Pepwave... - Page 10 Click the Advanced Config button to enter the parameters of the access point to associate to. You should see this screen: Illustration 2: Pepwave Surf AP Setup Page Pepwave Surf / Surf AP / Surf DX Series - 10 - Copyright © 2011 Pepwave...
- Page 11 Click the Save button at the bottom to complete. You can now click the Connect link on the top bar and then click the Connect button to associate with the access point. Pepwave Surf / Surf AP / Surf DX Series - 11 - Copyright © 2011 Pepwave...
- Page 12 At this point, you are associated with the access point. You may now close the web browser and open a new one to start web browsing. Pepwave Surf / Surf AP / Surf DX Series - 12 - Copyright © 2011 Pepwave...
-
Page 13: Settings Details
Configure DHCP Reservation if there is a need to assign a specific IP address to a specific MAC address using DHCP. Pepwave Surf / Surf AP / Surf DX Series - 13 - Copyright © 2011 Pepwave... - Page 14 Min Signal Strength, it will connect to this preferred access point, no matter the other access points are found even they have higher signal strength or the same SSID. Pepwave Surf / Surf AP / Surf DX Series - 14 - Copyright © 2011 Pepwave...
- Page 15 If there is another AP with a signal level greater than the signal level Threshold (Signal of connected AP by the specified value, it will reconnect to the AP Level Gain) with better signal. Pepwave Surf / Surf AP / Surf DX Series - 15 - Copyright © 2011 Pepwave...
- Page 16 (Applicable to Surf AP Series) AP Settings The AP Settings will be covered in detail in the subsequent section Integrated Wi-Fi Access Point Configuration. Pepwave Surf / Surf AP / Surf DX Series - 16 - Copyright © 2011 Pepwave...
- Page 17 To restore the device to default settings. When this option is clicked, Settings default settings will be restored and the unit will be restarted. Reboot CPE To restart the device. Pepwave Surf / Surf AP / Surf DX Series - 17 - Copyright © 2011 Pepwave...
-
Page 18: Integrated Wi-Fi Access Point Configuration
Point are automatically configured to be the same as the respective values that correspond to the ISP’s network. Access Point Disabled 4.4.1 Illustration 9: Access Point Disabled Pepwave Surf / Surf AP / Surf DX Series - 18 - Copyright © 2011 Pepwave... - Page 19 A 64- or 128-bit Encryption Key is required, and can be entered in either an ASCII or HEX representation. WPA/WPA2-Personal • An Encryption Key, of at least 8 characters, is required. Pepwave Surf / Surf AP / Surf DX Series - 19 - Copyright © 2011 Pepwave...
- Page 20 Access Point Configuration becomes unavailable, because the Integrated Wi-Fi Access Point functionality currently does not support authentication via the 802.1x with dynamic WEP key and WPA/WPA2-Enterprise methods. Pepwave Surf / Surf AP / Surf DX Series - 20 - Copyright © 2011 Pepwave...
-
Page 21: Test The Setup
The realm (the text box next to the “@” sign) value can be left empty. Then click the Connect button. Illustration 12: Establishing Connection to the Internet After connected, you should see: Illustration 13: Internet Connection Established Pepwave Surf / Surf AP / Surf DX Series - 21 - Copyright © 2011 Pepwave... -
Page 22: Port Forwarding
The IP address that you would like the traffics forwarded to. By clicking the button, you can delete the corresponding rows of port forwarding rules. Illustration 14: Port Forwarding Pepwave Surf / Surf AP / Surf DX Series - 22 - Copyright © 2011 Pepwave... - Page 23 Below the port forwarding table is an option called DMZ Host. If you Enable this function, your Pepwave Surf will become a DMZ device. You can enter an IP address, which will be the IP address of the device that expose to the Internet. The purpose of a DMZ is to make all external users can has access to any ports of the device, so that user do not need to set up port forwarding and internet traffics can directly reach internal devices.
-
Page 24: Qos
Voice. By choosing Default, priority will be automatically adjusted. By clicking the button, you can delete the corresponding rows of port forwarding rules. Illustration 15: QoS Pepwave Surf / Surf AP / Surf DX Series - 24 - Copyright © 2011 Pepwave... -
Page 25: Firmware Upgrade
Pepwave User Manual Firmware Upgrade The Pepwave devices are able to check whether a newer firmware (the software running on the unit) is available. However, it is recommended that you do not update the firmware unless specifically instructed by your ISP to do so. When a firmware upgrade is needed, your ISP will either give you instructions or they will upgrade the firmware remotely. -
Page 26: Debug And System Information
Illustration 17: Debug tab showing the system information Debug dump and configuration file can be downloaded through clicking the links illustrated above. If you encounter issues and would like to contact Pepwave Support Team (email: support@pepwave.com), please download the above files and attach it along with a description of your encountered issue. -
Page 27: 4.10 Restore To Default Settings
Surf Indoor Series 4.10.1 There are two ways to restore the Pepwave Surf Indoor unit to default settings. If you are able to access the web admin interface, go to the CPE Setup page, and click the Restore and Reboot button. -
Page 28: Appendix
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Pepwave Surf / Surf AP / Surf DX Series - 28 - Copyright © 2011 Pepwave... - Page 29 Contact Us: Address: Sales United States Office Hong Kong Office sales@pepwave.com 800 West El Camino Real, 17/F, Park Building, Mountain View 476 Castle Peak Road Support CA 94040 Cheung Sha Wan support@pepwave.com United States Hong Kong Tel: +1 (650) 331 0641...
