8.3 Power Supply Replacement Parts
8.3 Power Supply Replacement Parts
8.3 Power Supply Replacement Parts
8.3 Power Supply Replacement Parts
8.3 Power Supply Replacement Parts
Item #
Qty
Description
1
1
Transformer/Inductor (Incl. Chassis):
DRAG-GUN 100V/50Hz 110V/60Hz
DRAG-GUN 120V 50Hz
DRAG-GUN 120V 60Hz
DRAG-GUN 220V 50Hz
DRAG-GUN 208/230 60Hz
2
1
Cover (incl. Labels)
3
1
Control PCB Assembly
4
1
Capacitor:
DRAG-GUN 100V 50Hz/110V 60Hz, Capacitor AC 120UF, 180V
DRAG-GUN 120V 50Hz, Capacitor AC 120UF, 180V
DRAG-GUN 120V 60Hz, Capacitor AC 120UF, 180V
DRAG-GUN 220V 50Hz, Capacitor AC, 60MFD, 370V
DRAG-GUN 208/230 60Hz, Capacitor AC 60 MFD, 370V
5
1
Wire Harness (Not Shown)
6
1
Relay, DPST, -NO, 25A @ 250V
7
1
Fan:
DRAG-GUN 100V/50Hz 110V/60Hz, Fan 115V
DRAG-GUN 120V 50Hz, Fan 115V
DRAG-GUN 120V 60Hz,Fan 115V
DRAG-GUN 220V 50Hz, Fan 220V
DRAG-GUN 208/230 60Hz, Fan 220V
8
1
Compressor, Air, 12VDC, 0.5 CFM
1
Compressor Disc Filter (not shown)
9
1
Resistor, 0.5ohm, 55 watt, 10%,3/16 Faston
10
1
Resistor, 1Kohm, 55 watt, 5%,3/16 Faston
11
1
Work Cable, 15 ft. (4.57 m) w/Red Handles
12
1
Input Power Cable, 6.5 ft. min. (2 m):
DRAG-GUN 100V/50Hz 110V/60Hz, Power Cable, 14/3 w/molded plug
DRAG-GUN 120V 50Hz, Power Cable, "CE", **
DRAG-GUN 120V 60Hz, Power Cable, 16/3 w/molded plug
DRAG-GUN 220V 50Hz, Power Cable, "CE" **
DRAG-GUN 208/230 60Hz, Power Cable, 16/3 w/molded plug
** Plug to be supplied by customer.
13
1
ON/OFF Switch:
DRAG-GUN Switch, DPST, 125V 15A w/RED NEON (non CSA)
DRAG-GUN Switch, DPST, 22A, 125VAC, RED NEON (CSA)
DRAG-GUN Switch, 16A, 250VAC, AMBER (or RED) NEON
14
1
CD Transformer/Ferrite Core Assembly
15
2
Bridge Rectifier
16
1
Handle
8.4 Options & Accessories (not shown)
8.4 Options & Accessories (not shown)
8.4 Options & Accessories (not shown)
8.4 Options & Accessories (not shown)
8.4 Options & Accessories (not shown)
1
Circle Cutting Guide Kit
1
Leads Wrap - Installs Under Handle
DRAG-GUN Plasma Cutter
22
Ref.
Catalog#
T1/L1
9-0023
9-0024
9-0001
9-0037
9-0036
9-0002
9-0003
C13
9-0004
9-0004
9-0004
9-3924
9-3924
9-0005
K1
9-7508
8-3209
8-3209
8-3209
9-7687
9-7687
9-0010
9-7912
R30
9-0011
R31
9-0012
9-0013
9-0052
9-0044
9-0014
9-0044
9-0014
SW1
9-0015
9-0021
9-0029
T2
9-0018
BR1, BR2
7-3345
9-8115
7-8910
9-7865
Operating Manual 0-2682
