Item
LAN Profile
Virtual IP
VHID
Role
Peer IP
ID
Peer IP and ID
Apply
Cancel
Vigor3900 Series User's Guide
Description
Choose one of the LAN profiles that such function will be
applied to.
Assign an IP address as a virtual IP.
It means Virtual Host ID. Type a number as VHID for such
function.
Select a role for this device as Master or Backup.
If you choose Master, the fields of Peer IP and ID will be
hidden.
If you choose Backup, the field of Peer IP and ID will be
hidden.
Type the IP address of the peer side.
If Master is chosen as the role for Vigor3900, please type
the LAN IP address of the backup device. If Backup is
chosen as the role of Vigor3900, please type the LAN IP
address of the master device.
Type a number value here to represent the privilege of the
peer IP.
You can type several groups of Peer IP and ID for
Vigor3900 (when it represents the Master device).
Click it to save the configuration.
Click it to discard the settings configured in this page.
203
