Item
Cancel
4. Enter all the settings and click Apply.
5. A new IP Group profile has been created.
4 . 5 . 3 S e r v i c e T y p e
4 . 5 . 3 S e r v i c e T y p e
TCP and UDP service with specified port range can be saved with different service type
object profiles. Later, it can be applied to Firewall as a filter rule.
In default, common used service type object profiles have been created in this page.
Each item will be explained as follows:
Item
Add
Edit
Delete
Description
Click it to exit the dialog without saving anything.
O b j e c t
O b j e c t
Description
Add a new profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
154 Vigor3900 Series User's Guide
