Mac Block - Draytek Vigor3900 Series User Manual

4 . 4 . 3 M A C B l o c k
4 . 4 . 3 M A C B l o c k
MAC Block allows you to set lots of proprietary MAC Address. Packets will be dropped if
the source or destination MAC Address of packets is matched with these assigned MAC
Addresses. The advantage of MAC Block is that it can filter some unnecessary packets or
attacking packets on LAN network.
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Rename
Profile
Enable The Profile
MAC Address
Description
Add a new profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Renew current web page.
Allow to modify the selected profile name.
Display the name of the profile.
Display the status of the profile. False means disabled; True
means enabled.
Display the MAC address for such profile.
146 Vigor3900 Series User's Guide
