5 LCD Status Indicators and Diagnostics

5.1 CGW-T4 LCD Status Indicators and Diagnostics

The CGW-T4 Gateway can be connected to the analog trunks interface of the PBX or directly
to the analog home phone. At power-up of the CGW-T4 unit, the information on the LCD
will provide the first diagnostics. In many cases further diagnostics is not needed. By
connecting an analog telephone with the RJ-11 connector to the appropriate port's socket in
the unit, you are able to perform further diagnostics.
5.1.1 LCD Status Indicators
The following table shows the messages appearing on the LCD, their description and the
action to be taken (if any).
LCD Message
Searching
Network...
Ver:CGWT4_XX
Enter PIN code
(GSM only)
Enter PUK code
(GSM only)
Registration...
S=X %
Name operator
Calling...
Connected
Disconnected
Incoming Call
Description
Searching for the mobile network.
Displays the firmware number
CGW-T4 needs the PIN code to
activate the SIM card.
CGW-T4 received 3 times an
incorrect PIN code.
Registration process after the
mobile network has been found.
LCD shows signal level in intervals
of 20% (20%, 40%, 60%, 80%,
100%).
Name of Operator (read from
mobile network).
CGW-T4 dials to destination.
When called party answers.
End of call.
CGW-T4 gets a call from network.
No action needed.
No action needed.
1. Connect an analog telephone to the unit and
enter the code. (4-8 digits. Add a # to the code
when using less than 8 digits)
2. Alternatively, insert the SIM into your mobile
phone and disable the security option.
Request the PUK code from your local GSM
operator and enter it into the CGW-T4.
Wait till registration phase is finished.
If 20% or No signal, move the antenna to
another location with a better reception.
No action is needed.
Wait.
No action needed.
No action needed.
No action needed.
- 9 -
CGW-T4 Installation and Programming Manual
Action
